2024 BMW S1000RR Guide

2023 BMW S1000RR
ReviewKey FeaturesFeatures & BenefitsSpecifications

2023 BMW S1000RR

2024 BMW S1000RR: DYNAMIC RIDING EXPERIENCE.

Introducing the 2024 BMW S1000RR…

At the end of 2018, BMW Motorrad introduced the successful M Motorsport automobile range strategy to its motorcycle brand and has since been offering M special equipment and M Performance Parts on various BMW models. The new 2023 BMW M 1000 R – M R for short – is the second M model from BMW Motorrad to celebrate its world premiere, following the M 1000 RR superbike.

During the 50th birthday of BMW M GmbH, BMW Motorrad is adhering to the M brand philosophy of the most powerful letter in the world with the new M R: M is synonymous with racing success as well as high-performance street BMW models and is aimed at customers with particularly high demands for performance, exclusivity and individuality. With an engine output of 205 hp, a weight of 438.7 pounds, and suspension technology and aerodynamics designed for both high-performance street track use, the new M R delivers a dynamic riding experience in the roadster segment previously reserved for superbikes.

Based on the current S 1000 R and S 1000 RR, the product substance of the M 1000 R – M R for short – has been tuned to meet the specific requirements of a supersport roadster. The riding dynamics speak for themselves both on the country road and on the track.” Ralf Mölleken, Project Manager 4-cylinder models





2024 BMW S1000RR Totalmotorcycle.com Key Features

Colors

Black Storm Metallic (standard / unchanged)
Style Sport: Bluestone Metallic (optional / unchanged)
M Motorsport: Light White. Updated graphics. (optional)



Intelligent Emergency Call is available as standard or as an option for the following models and series in the USA and Canada for model year 2024: F 900 R and XR (optional) K 1600x (standard), R 1250x (standard), R 18 B and Transcontinental (standard), S 1000 R / RR (standard), CE 04 (standard). Intelligent Emergency Call adds a covered SOS button, loudspeaker and microphone to the right-side handlebar controls.

The eCall system uses BMW Motorrad Connected Services which can be activated during new vehicle delivery to the customer. When pressed, the SOS button connects the rider to an agent who can be advised verbally of the general situation, of the level of injury, if one exists and who can contact emergency services, if required. If a motorcycle fall or crash is detected, an eCall is automatically placed.

For model year 2024, all new BMW M motorcycles include the 600-mile Ultimate Care Break-In Service. The BMW Ultimate Care service programs were launched in 2021.











2024 BMW S1000RR Totalmotorcycle.com Features and Benefits

Options and Packages

No changes



Standard Equipment

Intelligent Emergency Call has been added.







2024 BMW S1000RR – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $14,295 USD
Canada MSRP Price: $ CDN
Europe/UK MSRP Price: £ GBP (total selling price)

Engine Liquid-cooled inline 4-cylinder
Capacity cc 999
Bore x stroke mm 80.0 x 49.7
Power hp 205 @ 13,000 rpm
Torque lb-ft. 83 @ 11,000 rpm
Max. engine speed rpm 14,600
Compression ratio 13.3:1
Fuel Power rated at 98 RON. 95-98 RON knock control
Valvetrain DOHC, valve actuation via single cam followers

BMW ShiftCam variable intake cam control

Valves per cylinder 4
Intake / Exhaust valve diameter mm 33.5 / 27.2
Throttle body diameter mm 48
Engine control BMS-0
Emission control Closed-loop three-way catalytic converter
Alternator watts 450
Battery Volta / Ah M lightweight battery 12v / 5 Ah
Headlamp LED free-form twin low-beam, LED free-form high-beam
Starter kW 0.8
Clutch Self-reinforcing multi-plate anti-hopping oil bath clutch,

mechanically operated

Gearbox 6-speed, constant-mesh
Primary ratio 1.652
Transmission gear ratios I 2.647
II 2.091
III 1.727
IV 1.500
V 1.360
VI 1.261
Secondary ratio 2.706
Rear wheel drive type Chain
Frame construction type Aluminum composite bridge frame, engine self-supporting
Front suspension Upside-down telescopic fork, 45 mm slide tube diameter

Spring preload, rebound and compression adjustable

Optional DDC electronically adjustable damping

Rear suspension Aluminum underslung double-sided swingarm

Central spring and shock absorber

Spring preload, rebound and compression adjustable

Optional DDC electronically adjustable damping

Suspension travel front / rear inches 4.7 / 4.6
Wheel castor inches 3.9
Steering head angle degrees 23.6
Brakes, front Twin 320 mm / 12.6-inch floating disks

4-piston fixed calipers

Brakes, rear Single 220 mm / 8.7-inch, single-piston floating caliper
ABS BMW Motorrad ABS Pro, partially integral, disengageable
Traction control BMW Motorrad DTC
Wheels Standard die-cast aluminum wheels

Optional M forged aluminum or M Carbon wheels

Wheels, front / rear inches 3.50 x 17 / 6.00 x 17
Tires, front / rear 120/70 ZR17 / 190/55 ZR17

200/55 ZR17 rear with M wheels

Length x width x height inches 81.6 x 33.3 x 47.4
Wheelbase inches 57.4
Seat height inches 32.8 at curb weight
Curb weight lbs. 434.3 standard trim, 426.6 with M Package
Dry weight lbs. 385.8 standard trim, 382.0 with M Package (no battery)
Permitted total weight lbs. 897
Fuel tank capacity gallons 4.35
Acceleration, 0-60 mph seconds 3.1
Top speed mph 188







2024 BMW S1000RR – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Type

4-cylinder, 4-stroke in-line engine (BMW ShiftCam)

Bore x stroke

80 mm x 49.7 mm

Capacity

999 ccm

Rated output

210 hp at 13,750 rpm

Max. torque

113 Nm at 11,000 rpm

Compression ratio

13.3 : 1

Mixture control

Electronic injection, variable intake pibe

Emission control

Closed-loop 3-way catalytic converter

Performance / fuel consumption

Maximum speed

303 km/h

Fuel consumption per 100 km based on WMTC

6.4 l

CO2 emission based on WMTC

149 g/km

Fuel type

Premium unleaded (max. 5 % ethanol, E5), 98 ROZ/RON, 93 AKI

Electrical system

Alternator

450 W

Batterie

12 V / 5 Ah, lithium-ion

Power transmission

Clutch

Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement

Gearbox

Claw-shifted 6-speed gearbox with straight cut gears

Drive

Chain 525 17/46

Traction control

DTC, slide control

Chassis / brakes

Rahmen

Bridge-type frame, cast aluminium, co-supporting engine

Front wheel location / suspension

Upside-down telescopic fork, diameter 45 mm, spring preload, rebound and compression stages adjustable

Rear wheel location / suspension

Aluminium swing arm, full floater pro, compression and rebound damping adjustable, adjustable spring preload

Suspension travel, front / rear

120 mm / 117 mm

Wheelbase

1,457 mm

Castor

99.8 mm

Steering head angle

66.2°

Wheels

Aluminium cast wheels

Rim, front

3.50 x 17″

Rim, rear

6.00 x 17″

Tyre, front

120/70 ZR17

Tyre, rear

190/55 ZR17 (with M wheels: 200/55 ZR17)

Brake, front

Twin disc brake, diameter 320 mm, 4.5 mm, 4-piston fixed caliper (5 mm M wheels)

Breake, rear

Single disc brake, diameter 220 mm, 1-piston floating caliper

ABS

BMW Motorrad Race ABS (partial integral), Brake-Slide-Assist

ABS Pro

BMW Motorrad ABS Pro (settings for RAIN, ROAD, DYNAMIC, RACE mode)

Dimensions / weights

Seat height at unladen weight

824 mm

Inner leg curve at unladen weight

1,845 mm

Usable tank volume

16.5 l

Reserve

approx. 4 l

Length

2,073 mm

Height

1,205 mm

Width

848 mm

Dry weight

175 kg (M Package 173.3 kg) without battery

Unladen weight, road ready, fully fuelled

197 kg (M Package 193.5 kg)

1)

Permitted total weight

407 kg

Payload (with standard equipment)

210 kg

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable fuel tank capacity.











2024 BMW S1000RR – Totalmotorcycle.com European Specifications/Technical Details

Engine

Type

4-cylinder, 4-stroke in-line engine (BMW ShiftCam)

Bore x stroke

80 mm x 49.7 mm

Capacity

999 ccm

Rated output

154 kW (210 hp) at 13,500 rpm

Max. torque

113 Nm at 11,000 rpm

Compression ratio

13.3 : 1

Mixture control

Electronic injection, variable intake pibe

Emission control

Closed-loop 3-way catalytic converter

Performance / fuel consumption

Maximum speed

303 km/h

Fuel consumption per 100 km based on WMTC

6.4 l

CO2 emission based on WMTC

149 g/km

Fuel type

Premium unleaded (max. 5 % ethanol, E5), 98 ROZ/RON, 93 AKI

Electrical system

Alternator

450 W

Battery

12 V / 5 Ah, lithium-ion

Power transmission

Clutch

Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement

Gearbox

Claw-shifted 6-speed gearbox with straight cut gears

Drive

Chain 525 17/46

Traction control

DTC, slide control

Chassis / brakes

Frame

Bridge-type frame, cast aluminium, co-supporting engine

Front wheel location / suspension

Upside-down telescopic fork, diameter 45 mm, spring preload, rebound and compression stages adjustable

Rear wheel location / suspension

Aluminium swing arm, full floater pro, compression and rebound damping adjustable, adjustable spring preload

Suspension travel, front / rear

120 mm / 118 mm

Wheelbase

1,456 mm

Castor

101.4 mm

Steering head angle

66.2°

Wheels

Aluminium cast wheels

Rim, front

3.50 x 17″

Rim, rear

6.00 x 17″

Tyre, front

120/70 ZR17

Tyre, rear

190/55 ZR17 (with M wheels: 200/55 ZR17)

Brake, front

Twin disc brake, diameter 320 mm, 4.5 mm, 4-piston fixed caliper (5 mm M wheels)

Breake, rear

Single disc brake, diameter 220 mm, 1-piston floating caliper

ABS

BMW Motorrad Race ABS (partial integral), Brake-Slide-Assist

ABS Pro

BMW Motorrad ABS Pro (settings for RAIN, ROAD, DYNAMIC, RACE mode)

Dimensions / weights

Seat height at unladen weight

832 mm

Inner leg curve at unladen weight

1,845 mm

Usable tank volume

16.5 l

Reserve

approx. 4 l

Length

2,073 mm

Height

1,205 mm

Width

848 mm

Dry weight

175 kg (M Package 173.3 kg) without battery

Unladen weight, road ready, fully fuelled

197 kg (M Package 193.5 kg)

1)

Permitted total weight

407 kg

Payload (with standard equipment)

210 kg

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable fuel tank capacity.







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
