2004 Ducati Monster 620

Back to 2004 Ducati Motorcycle Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2004 Ducati Monster 620
2004 Ducati Monster 620


2004 Ducati Monster 620 Review

2004 Ducati Monster 620



2004 Ducati Monster 620 Key Features








2004 Ducati Monster 620 – Specifications/Technical Details
USA MSRP Price: See dealer for pricing in USD
Canadian MSRP Price: See dealer for pricing in CDN


Engine
TYPE
L-Twin cylinder, 2 valve per cylinder Desmodromic, air cooled
DISPLACEMENT
618cc
BORE X STROKE
80×61.5mm
COMPRESSION RATIO
10.5:1
POWER
60hp – 44.3kw @ 9500rpm
TORQUE
5.4kgm – 53.3Nm @ 6750rpm
FUEL INJECTION
Marelli electronic fuel injection, 45mm throttle body
EXHAUST
2 aluminium mufflers with 3-way catalytic converter
Transmission
GEARBOX
6 speed (Dark version: 5 speed)
PRIMARY DRIVE
Straight cut gears, ratio 1.85
RATIO
1st 32/13, 2nd 30/18, 3rd 28/21, 4th 26/23, 5th 22/22 6th 24/26 (Dark version: 1st 40/16, 2nd 36/21, 3rd 32/24, 4th 29/27, 5th 28/29)
FINAL DRIVE
Chain; Front sprocket 15; Rear sprocket 48 (Dark version: 46)
CLUTCH
Wet multiplate with hydraulic control
Chassis
FRAME
Tubular steel trellis
FRONT SUSPENSION
43mm upside-down fork
FRONT WHEEL
3-spoke light alloy 3.50×17
FRONT TYRE
120/60 ZR17
REAR SUSPENSION
Progressive linkage with Sachs adjustable monoshock.
REAR WHEEL
3-spoke light alloy 5.50 x 17
REAR TYRE
160/60 ZR17
FRONT WHEEL TRAVEL
130mm / 5.1in
REAR WHEEL TRAVEL
148mm / 5.8in
FRONT BRAKE
2 x 320 mm discs, 4-piston caliper
REAR BRAKE
245mm disc, 2-piston caliper
INSTRUMENTATION
Electronic panel: Speedometer, rev counter, neutral light, oil pressure warning light, low fuel warning light, high beam indicator, turn signals, immobilizer, LCD oil temperature, LCD clock
Dimensions and weight
DRY WEIGHT
177kg / 390lb
SEAT HEIGHT
770mm / 30.3in
WHEELBASE
1440mm / 56.7in
RAKE
24°
FUEL TANK CAPACITY
15l (of which 3.5l reserve) / 3.9 US gal (of which 1 US gal reserve)
VERSIONS
620, 620 Dark, 620 Dark Single Disc
Warranty
WARRANTY
2 years unlimited mileage
Emissions and Consumption
STANDARD
Euro2


Suggested Starting Price shown does not include tax, title, or destination charge. Dealer prices may vary. Specifications subject to change without notice.
