The far horizon is the Tiger’s destination, any vast expanse of wilderness its home. It thrives on an all-day riding challenge and lives for the journey. Whether crossing continents, countries, commuting or simply riding for the hell of it, the Tiger is always a willing accomplice. Its lusty power delivery, surefooted composure and excellent rider comfort see to that.

And it’s tauter, sharper and more usable than ever thanks to a honed, sharper chassis. The Tiger’s quick steering frame geometry has rake set at 25.8°, trail at 92mm with a wheelbase of 1515mm. The front forks employ single rate springs and revised rebound damping while rear shock performance has been enhanced with an increased spring rate and revised compression and rebound damping. The cast, 14-spoke, aluminium wheels take tubeless tyres – 110/80 V19 front and 150/70 V17 rear.

The Tiger is all about usability and its motor responds readily to any challenge, giving instant, accessible drive from any road speed. A seminal fuel-injected, 955cc, three-cylinder engine, with a solid 105PS peak power output matched by a walloping 92Nm torque powers the Tiger, a motor that’s the very definition of real-world drivability. Its character instantly involves the rider and its unflagging response can always be relied upon.

Total confidence, from sinuous switchback to four-lane black top, is what the Tiger exudes and the upright, comfortable riding position gives a great view of the road ahead and the scenery flashing by.
With practical touches like the large 24 litre (6.3 gallon US) fuel tank, hard cases fitted as standard* and the efficient, frame mounted fairing to keep the windblast and weather at bay the Tiger’s usability factor multiplies. And, as with all Triumphs, an extensive range of accessories is available – including hard and soft luggage, heated grips and mudguard extensions. Silver frame and wheels complement the three colour options of British Racing Green, Lucifer Orange and Aluminium Silver. The seat height also adjusts through a 20mm range.

Tens of thousands of miles’ experience make the Tiger a trusted travelling companion. And each comes with a guarantee of riding satisfaction, of distance covered, tales told and journeys won – and, of course, a helmet-filling grin. The world’s a big place. The Tiger has its measure.

*Not available in all markets


Specification changes for 2005:
– The 05MY Tiger was introduced in March 2004 with:
– Revised front and rear suspension, steering geometry and wheelbase
– Cast wheels with tubeless tyres
– Revised gear and rear brake pedals with weight relief slots



2005 Triumph Tiger Specifications


Type Liquid-cooled, DOHC, in-line 3-cylinder
Capacity 955cc
Bore/Stroke 79 x 65mm
Compression Ratio 11.65:1
Fuel System Multipoint sequential electronic fuel injection
Ignition Digital – inductive type – via electronic engine management system

Primary Drive Gear
Final Drive X ring chain
Clutch Wet, multi-plate
Gearbox 6-speed

Frame Tubular steel perimeter
Swingarm Twin-sided, aluminium alloy
Wheels Front Cast, 14-spoke, 19 x 2.5in
Rear Cast, 14-spoke, 17 x 4.25in
Tyres Front 110/80 V 19
Rear 150/70 V 17
Suspension Front 43mm forks
Rear Monoshock with remotely adjustable preload and rebound damping
Brakes Front Twin 310mm discs, 2 piston calipers
Rear Single 285mm disc, 2 piston caliper

Length 2250mm (88.6in)
Width (Handlebars) 860mm (33.8in)
Height 1390mm (54.7in)
Seat Height 840-860mm (33.1-33.8in)
Wheelbase 1515mm (59.6in)
Rake/Trail 25.8º/87.9mm
Weight (Dry) 215kg (474lbs)
Fuel Tank Capacity 24 litres (6.3 gal US)

Maximum Power 105PS (104bhp) at 9,500 rpm
Maximum Torque 92Nm (67ft.lbf) at 4,400 rpm
Colours Lucifer Orange, British Racing Green, Aluminium Silver

Specifications are subject to change without notice, in accordance with national regulation and legislations.
