Total Motorcycle Website – 2005 Yamaha FJR1300

– 2005 Yamaha FJR1300

No destination is out of reach

Light, quick and technologically advanced, the 2005 FJR1300 puts a serious dose of ”sport” in the sport-touring segment. Powered by a 145hp inline four-cylinder engine, running in a responsive aluminum chassis, the FJR1300 combines the agile handling of a sport bike with superb long-distance riding comfort. And for those riders who want the peace of mind that ABS braking offers, we have also added an ABS equipped FJR to our lineup.

Join An Exclusive Club
Combining near-superbike power and handling with touring-bike comfort and convenience seemed like such a natural idea, it’s almost surprising that the FJR1300 remains in a class of one. Oh well. “Supersport Touring” remains an exclusive Yamaha niche, and anyway, the critics seem to understand exactly where we’re going with the FJR1300.

The Awards Just Keep Stacking Up

The latest award the FJR1300 has garnered is Cycle World Magazine’s 2004 Best Sport-Touring Bike.

Here’s what they had to say – “…with superb luggage, superbike power, fine handling and great riding position, and nothing can touch it for eating all the pavement you care to feed it at a rate that will embarrass any other bike with saddlebags”.

For two years running (2004 & 2005), it has won the title of Motorcyclist Magazine’s Tourer of the Year, while it was labeled Rider Magazine’s Motorcycle of the Year for 2003. Not to mention, it was Cycle World’s 2002 Best Sport-Touring Bike, right out of the gate.

It might be confusing, at first, but soon you’ll understand –

A powerhouse 1298cc, DOHC, 16-valve, liquid-cooled in-line four-cylinder engine producing 145 horsepower and 99 foot-pounds of torque
Shaft drive
Standard hard sidebags
Electric-adjustable windshield
Optional ABS
Light weight, adjustable suspension
…can all coexist and result in a motorcycle that can attack corners with almost the nimbleness and precision of an all-out sportbike.
Downsides? The FJR1300 moves so well, it may leave less time for taking in the scenery. The 6.6-gallon fuel capacity means you might not discover as many quaint gas stations. And, you may attract more hangers-on, so accommodating are the broad and supportive dual-density seat, excellent grab handles and cavernous storage.

Life consists mainly of compromises. Some rare times, though, you really can have it all.

Features & Benefits

Engine:
Compact, lightweight 1298cc, DOHC, 16-valve, liquid-cooled in-line four-cylinder engine delivers massive power and torque (145 hp @ 8000 RPM and 99 ft.-lbs. of torque @ 7000 RPM, respectively) for an unequaled spread of muscle over a wide RPM range.


Engine is a fully stressed chassis member, allowing for a lightweight frame design.

Compact slant-block engine design uses stacked, tri-axis gearbox shafts that help minimize powerplant size while optimizing chassis geometry for a low center of gravity and balanced weight distribution.

Lightweight forged pistons with carburized connecting rods provide superb strength and reduced reciprocating mass for outstanding high-RPM durability.

Patented electroplated ceramic composite cylinder bores ensure greater heat dissipation and thus reduced frictional power loss.

High-compression four-valve cylinder heads are operated by compact, side-driven double-overhead camshafts, and for strong, dependable high-rpm performance the plated cylinders feature oversquare dimensions of 79 x 66.2mm.

Advanced fuel injection (FI) system is ideal for long-distance supersport-touring, delivering crisp, seamless throttle response in a variety of altitude/weather conditions and enhanced fuel efficiency and instant, choke-free starting.

FI system features TPS, which monitors throttle position and, with a battery of sensors (air intake temperature/pressure, atmospheric pressure, coolant temperature, crankshaft position and engine rpm), ensures precise injection intervals and timing for optimal performance.

Low-vibration crankshaft features two gear-driven secondary counterbalancers with built-in shock absorbers that help deliver a glass-smooth ride with reduced rider/passenger fatigue.

Constant-mesh 5-speed transmission utilizes wide ratios to deliver relaxed long-distance touring performance combined with seamless power and acceleration.

Light-action hydraulic multi-plate wet clutch provides smooth, effortless shifting, minimizing both rider fatigue and maintenance.

Gear shift shaft features a needle-roller bearing to reduce friction for silky-smooth shifting.

Shaft final drive system is super-durable and virtually maintenance-free, and uses mechanical cam dampers in its drive pinion for quiet, smooth power delivery to the rear wheel.


4-into-1-into-2 stainless steel exhaust optimizes engine performance across the powerband and features a three-way catalytic converter and Air Induction System, making this one of the cleanest-running large-capacity motorcycle engines ever built.

Wet-sump oil system uses an easy-access cartridge-type oil filter mounted on the engine’s left side.


Chassis/Suspension:
Hollow cast-aluminum frame, featuring massive, widely spaced twin spars, is incredibly light and extremely rigid, the perfect combination for sharp, sportbike-like handling.


Fully detachable aluminum subframe helps keep weight down while permitting easier rear shock access/maintenance.

Lightweight, cast-aluminum swingarm’s unique design incorporates the shaft drive into its left side, ensuring superb rigidity with reduced unsprung weight that delivers incredible handling and suspension performance.

Fully adjustable (preload, compression and rebound damping) 48mm Soqi front fork with 5.4″ of travel provides quick, responsive steering with excellent rider feedback in a wide range of conditions.

Adjustable (preload and rebound damping) 46mm link-type rear shock with 4.8″ of travel features a handy, two-stage (hard/soft) preload adjustment lever that allows the rider to switch quickly between solo and two-up settings.

Dual 320mm front disc brakes with YZF-R1-derived one-piece 4-piston calipers and 282mm rear disc brake with a slide-type dual-piston caliper provide outstanding stopping power with exceptional feel.

Optional anti-lock braking system (ABS) allows for even greater wet-weather braking performance.


Cast-aluminum 3-spoke wheels wear sporty-spec 120/70-ZR17 front and 180-50-ZR17 rear Metzeler radials perfectly suited to both spirited solo riding and long-range trekking.

Adjustable, 5-position front brake lever.


Additional Features:
Highly aerodynamic full fairing is highlighted by an electrically adjustable windscreen that can be easily raised for greater wind protection or lowered for a sportier profile via a handlebar-mounted switch.


Equally sleek tail section helps reduce drag and features a sturdy rear luggage rack/passenger grabrail.

Subframe-fitted quick-release luggage mounts provide easy use of the standard accessory hard sidecases*, which are conveniently matched to the ignition key.

Long dual seat features two-part construction using different foam densities for the front and rear sections, ensuring plush comfort for both rider and passenger.


Ergonomically shaped, large-capacity, 6.6-gallon fuel tank offers excellent comfort and range and is constructed of steel allowing for the use of magnetic tankbags.

Integrated color matched front turn signals add to the FJR1300’s cutting-edge aerodynamic bodywork.


High-tech instrument panel delivers comprehensive display that includes an electronic analog speedometer and tachometer (both with a lightweight, R1-type step motor); LCD digital odometer, dual tripmeters, fuel and coolant temperature gauges, and clock; and lights for neutral, high beam, turn signals, low oil and engine warnings.


Sleek, R1-type cat-eye dual 12V 60/55-watt multi-reflector headlight throws an extremely broad beam for superb visibility.

Powerful dual-bulb taillight features integrated turn signals for a slick, one-piece look that’s as aerodynamic as it is conspicuous.


Fairing pocket (located in the forward fairing panel) is convenient for small storage.

Standard toolkit located in convenient storage compartment under passenger seat.

*Accessory saddlebags as standard equipment. Soft bag liners included.

Specifications:

MSRP
$11,799*
$12,899* ABS model
Available via Priority Delivery Program only. Deposits accepted Feb. 6 – Apr. 30, ’04. Esti. delivery to dealers: Jul. ’04 to Nov. ’04.

Engine

Type
1,298cc, liquid-cooled, 16-valve, DOHC, in-line four-cylinder

Bore x Stroke
79 x 66.2mm

Compression Ratio
10.8:1

Carburetion
Fuel Injection

Ignition
Digital TCI

Transmission
5-speed w/hydraulic, multi-plate clutch

Final Drive
Shaft

Chassis

Suspension/Front
48mm Soqi telescopic fork w/adjustable preload, compression and rebound damping; 5.4″ of travel

Suspension/Rear
Single shock, link-type, w/adjustable preload and rebound damping; 4.8″ of travel

Brakes/Front
Dual 320mm discs w/4-piston calipers

Brakes/Rear
282mm disc

Tires/Front
120/70-ZR17

Tires/Rear
180/55-ZR17

Dimensions

Length
87.8″

Width
30.3″

Height
56.5″

Seat Height
32.2″

Wheelbase
60.6″

Saddlebag Capacity
7.9 Gallons each

Fuel Capacity
6.6 Gallons

Ground Clearance
5.4″

Oil Capacity (with oil filter change)
4.55 qt.

Dry Weight
537 Lbs. (non-ABS model) / 553 Lbs. (ABS model)



Color
Galaxy Blue

Warranty
1 Year (Limited Factory Warranty)
