2009 KTM 990 Supermoto R

You are here: Home2009 Models — 2009 KTM Motorcycle Models

2009 KTM 990 Supermoto R
Back to 2009 KTM Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2009 KTM 990 Supermoto R
2009 KTM 990 Supermoto R

2009 KTM 990 Supermoto R
2009 KTM 990 Supermoto R

2009 KTM 990 Supermoto R
2009 KTM 990 Supermoto R

2009 KTM 990 Supermoto R
2009 KTM 990 Supermoto R


– 2009 KTM 990 Supermoto R

2009 KTM 990 Supermoto R

The 990 Supermoto R combines irrepressible power and effortless handling. The KTM engineers did their utmost to develop a “machine” that would exploit to the fullest every last inch of leeway in road traffic certification: Fully adjustable 48 WP chassis, ultralight chromium molybdenum tubular trellis frame, enhanced seat ergonomics for perfect drifts as well as “R”adial brake performance from Bembo all ensure pure pleasure in the curves. Out of the rut and into the race.




2009 KTM 990 Supermoto R – Specifications

Engine type Twin cylinder, 4-stroke, V 75°
Displacement 999 cc
Bore x stroke 101 x 62.4 mm (3.98/2.46)
Performance (homologated) 85 kW @ 9000 rpm
Max. torque 97 Nm @ 7000 rpm
Compression ratio 11,5:1
Starter/Battery E-Starter/12 V 11.2 Ah
Transmission 6 gears, dog clutch engagement
Fuel Mixture Generation Keihin EFI
Control 4 V/DOHC
Lubrication Pressure lubrication with 2 oil pumps
Engine lubrication Motorex, SAE 10W-50
Primary drive 35:67
Final drive 17:41
Cooling Liquid cooled
Clutch Wet multi-disc clutch, hydraulically operated
Motor Management Keihin EMS


Frame Chromium-Molybdenum trellis frame, powder-coated
Subframe Aluminium
Handlebar Aluminium Ø 28/22 mm (1.89″), tapered
Front suspension WP USD Ø 48 mm (1.89″)
Rear suspension WP mono shock
Suspension travel front/rear 160/180 mm (6.3/7.09″)
Front brake 2 x Brembo four piston fixed-caliper, radial bolted, brake disc Ø 305 mm (12.0″), floating
Rear brake Brembo two piston, floating caliper, brake disc Ø 240 mm (9.45″)
Rims, front/rear Forged aluminium wheels 3.5 x 17”; 5.5 x 17”
Tires, front/rear 120/70 ZR 17 – 180/55 ZR 17
Chain X-Ring 5/8 x 5/16″
Main silencer Twin stainless-steel silencer with catalytic converters
Steering head angle 65,6°
Trail 109 mm (4.29″)
Wheel base 1510 ± 15 mm (59.45 ± 0.95″)
Ground clearance (unloaded) 195 mm (7.68″)
Seat height 875 mm (34.45″)
Tank capacity approx. 15 litres/3.7 liters reserve (3.96/0.98 gal)
Weight (no fuel) approx. 189 kg
