2010 KTM 1190 RC8

Back to 2010 KTM Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2010 KTM 1190 RC8
2010 KTM 1190 RC8

2010 KTM 1190 RC8
2010 KTM 1190 RC8

2010 KTM 1190 RC8
2010 KTM 1190 RC8

2010 KTM 1190 RC8
2010 KTM 1190 RC8

2010 KTM 1190 RC8
2010 KTM 1190 RC8



– 2010 KTM 1190 RC8

2010 KTM 1190 RC8

Sharper and lighter than anything that calls itself competition: 120 Nm torque, 155 HP at 10,000 rpm and withs less than 200 kilos fully tanked.

Nonetheless, thanks to innovative solutions and meticulous detail work, we’ve achieved unsurpassed rideability – on the street and on the racetrack, in every situation – of life or riding.

The latest generation LC8 two-cylinder, dry sump lubrication, displacement: 1148 cc, power: 155 HP (113.8 kW)
– Underfloor exhaust system, regulated catalytic converter
– Lightweight steel trellis frame with light alloy subframe
– Premium-quality, fully adjustable WP suspension components
– Radially-mounted Brembo four-piston monoblock brake callipers with 320 millimetre brake discs
– Adjustable vehicle and seat ergonomics
– Available ex factory: PowerParts accessories range

2008 marked a milestone in KTM’s history as this was the year in which the company launched the first Superbike to be designed and manufactured in Austria: the fascinating 1190 RC8. This highly stylised machine highlighted KTM’s sporty abilities on asphalt. The latest generation LC8 twocylinder motorcycle was designed from scratch. The high-tech drive has a displacement of 1148 cc and generates 155 HP and a 120 Nm torque. The carburetion is made possible by a fuel injection system with 52 mm throttle valves. The engineers positioned the silencer by centralising the masses beneath the engine, further optimising the nimble handling of the Superbike that weighs less than 200 kg with a full tank. The ultra-light frame also makes it possible to perfectly position the powerful yet highly compact engine and is equipped with premium-quality, fully adjustable WP chassis components. The subframe, footrests and clip-on handlebars are height-adjustable. A powerful Brembo brake system with four-piston monoblock brake callipers with 320 millimetre brake discs is used for superior deceleration.

ENGINE TYPE 2-CYLINDER, 4-STROKE, V 75° · DISPLACEMENT 1,148 CC · STARTER ELECTRIC STARTER · TRANSMISSION 6 GEARS · TANK CAPACITY APPROX. 16.5 L · WEIGHT (READY TO RACE) APPROX. 184 KG (WITHOUT FUEL)







2010 KTM 1190 RC8 – Specifications
MSRP: See Dealer

Engine type 2-cylinder, 4-stroke, V 75°
Displacement 1148 cc
Bore x stroke 103 x 69 mm (4.06 x 2.72″)
Performance (homologated) 113.8 kW @ 10000 rpm
Max. torque 120 Nm @ 8000 rpm
Compression ratio 12.5:1
Starter/Battery Electric Starter/12 V 11.2 Ah
Transmission 6 gears, dog clutch engagement
Fuel Mixture Generation Keihin EFI (throttle body 52 mm (2.05″))
Control 4 V/DOHC
Lubrication Pressure lubrication with 2 Eaton pumps
Engine lubrication Motorex, fully synthetic, SAE 10W-50
Primary drive 40:76
Final drive 17:37
Cooling Liquid cooled
Clutch Wet multi-disc clutch, operated hydraulically
Motor Management Keihin EMS


Frame Chromium-Molybdenum trellis frame, powder-coated
Subframe Aluminium 7020
Handlebar Aluminium stump handlebar
Front suspension WP-USD Ø 43 mm
Rear suspension WP-Monoshock
Suspension travel front/rear 120/125 mm (4.7/4.9″)
Front brake 2 x Brembo four piston, radially bolted caliper, brake disc 320 mm (12.6″)
Rear brake Brembo two piston, fixed caliper, brake disc 220 mm (8.66″)
Rims, front/rear Cast aluminium wheels 3.5 x 17″; 6 x 17″
Tires, front/rear 120/70 ZR 17; 190/55 ZR 17
Chain X-ring 5/8 x 5/16″
Main silencer Stainless steel underfloor silencer with regulated catalytic converter
Steering head angle 66.7°
Trail 90/92 mm (3.54 / 3.62″)
Wheel base 1430 mm (56.30″)
Ground clearance (unloaded) 110 mm (4.33″)
Seat height 805/825 mm (31.69/32.48″)
Tank capacity approx. 16.5 liters/3.5 liters reserve (4.36/0.92 gal)
Weight (no fuel) approx. 184 kg (405.6 lbs)
