2010 KTM 990 Adventure R

Back to 2010 KTM Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2010 KTM 990 Adventure R

2010 KTM 990 Adventure R

2010 KTM 990 Adventure R

2010 KTM 990 Adventure R

– 2010 KTM 990 Adventure R

2010 KTM 990 Adventure R

With the 990 Adventure R, KTM presents the new spearhead of the Adventure family. Overwhelmingly superior, due to the reworked engine with approximately 20 % increase in power that delivers unrivalled performance. Outstanding, thanks to the amazingly sporty chassis and 265 mm suspension travel. Clearly laid out, with a new cockpit and modified front storage compartment.

Superior in appearance too – the most sport-oriented travel enduro sets new standards in styling and attractiveness with its typical R colour scheme and radical new design. The 990 Adventure R guarantees an unbeatable total package of pure power and exceptional riding pleasure, defi ning a clear direction: off to the next adventure!





2010 KTM 990 Adventure R – Specifications
MSRP: See Dealer

Engine type Twin cylinder, 4-stroke, V 75°
Displacement 999 cc
Bore x stroke 101 x 62.4 mm (3.98 x 2.46″)
Performance (homologated) 84,5 kW @ 8750 rpm
Max. torque 100 Nm @ 6750 rpm
Compression ratio 11.5:1
Starter/Battery E-Starter / 12 V 11.2 Ah
Transmission 6 gears, dog clutch engagement
Fuel Mixture Generation Keihin electronic fuel injection
Control 4 V/DOHC
Lubrication Pressure lubrication
Engine lubrication Motorex, SAE 10W-50
Primary drive 35:67
Final drive 16:42
Cooling Liquid cooled
Clutch Wet multi-disc clutch, operated hydraulically
Motor Management Keihin EMS


Frame Chromium-Molybdenum trellis frame, powder-coated
Subframe Aluminium
Handlebar Aluminium, Ø 28/22 mm (1.10/0.87″), tapered
Front suspension WP USD Ø 48 mm (1.89″)
Rear suspension WP mono shock PDS with hydr. spring preload
Suspension travel front/rear 265/265 mm (10.43/10.43″)
Front brake 2 x Brembo two piston, floating caliper, floating brake disc Ø 300 mm (11.81″)
Rear brake Brembo two piston, floating caliper, floating brake disc Ø 240 mm (9.45″)
Rims, front/rear 2.15 x 21″; 4.25 x 18″
Tires, front/rear 90/90-21″; 150/70 R 18
Chain X-Ring 5/8 x 5/16″
Main silencer Twin stainless steel silencer with regulated catalytic converter
Steering head angle 63.4°
Trail 119 mm (4.69″)
Wheel base 1570 ± 10 mm (61.81 ± 0.39″)
Ground clearance (unloaded) 316 mm (12.44″)
Seat height 915 mm (36.02″)
Tank capacity approx. 19,5 Liters/4 litres reserve (5.81/1.06 gal)
Weight (dry) approx. 207 kg (456.34 lbs)
