2017 BMW K1600B Review

2017 BMW K1600B
2017 BMW K1600B



2017 BMW K1600B
2017 BMW K1600B



2017 BMW K1600B
2017 BMW K1600B



2017 BMW K1600B
2017 BMW K1600B



2017 BMW K1600B
2017 BMW K1600B







2017 BMW K1600B Review



2017 BMW K1600B on www.Totalmotorcycle.com



The new K 1600 B: emotion and fascination with 6 cylinders in the exclusive Bagger style…



The presentation of the “Concept 101” concept study as part of the Concorso d’Eleganza Villa d’Este in spring 2015 was an impressive new chapter for BMW Motorrad in the history of BMW Motorrad Concept Bikes. This BMW Motorrad interpretation of motorcycling on endless highways, the dream of freedom and independence and the embodiment of “Grand American Touring” now becomes reality in form of a series version of the new K 1600 B bagger.



As a high-performance, highly emotional and exclusive motorcycle, the new K 1600 B with the familiar 6-cylinder in-line engine and supreme 118 kW (160 hp) output, like the “Concept 101” study that preceded it, already embodies the motto of the “Spirit of the Open Road”. It is synonymous with elegance, power and luxury on two wheels and transforms every road, every tour and every moment into a particularly intense experience.



The characteristic streamlining with a low rear section and masculine colour scheme make for relaxed dynamic elegance.


















2017 BMW K1600B www.Totalmotorcycle.com Key Features



In design terms, the new all-black (Blackstorm metallic / black for chassis parts and drivetrain) K 1600 B takes the form of a bagger, an exclusive custom bike type that is particularly popular in the USA. The characteristic properties of the bagger are its drop-shaped silhouette, whose highest point is the front fairing, the stretched drop-like silhouette in a “streamlining” style and the deep-set side cases with integrated US American style rear lights. New fully chrome-plated silencers run parallel to the road and are an organic fit for the visual appeal of the bagger.



Largely based on the technology used in the BMW 6-cylinder tourer K 1600 GT, the new K 1600 B implements its spectacular backward sloping linear design with a completely reconstructed rear section. This not only makes the bagger look particularly low-lying and slender, but also, thanks to the new rear frame, significantly reduces the height of the passenger seat.



Side cases with newly designed compartments and folding rear mudguard for easy dismantling of the wheel.



A re-design of the compartments in the side cases with slimmer covers and deeper body allows for particularly comfortable and effective loading of luggage. The rear mudguard has been designed to fold upward to make it easier to remove the rear wheel.



High visual impact and effective wind and weather protection.



The fairing of the new K 1600 B with its closely tailored dynamic windscreen makes the motorcycle look particularly powerful and impressive. For especially effective wind and weather protection, the side sections of the wind deflectors are stretched further back. Wind deflectors protect the rider’s hands. The two mirrors also match the design concept, ensuring a particularly good view of the following traffic thanks to the large mirror surfaces with an aspherical element.



Electronic suspension Dynamic ESA with automatic damping adaptation as standard.



With the electronically controlled Dynamic ESA chassis and its “Road” and “Cruise” modes, the new K 1600 B combines riding comfort, stability and dynamic performance ensuring an incomparable riding experience. In the standard “Road” setting, damping adaptation is fully automated, offering the very highest level of comfort and ultimate traction on virtually all surfaces. In contrast, the new K 1600 B offers very gentle damping in “Cruise” damping mode, ensuing a very high level of comfort at low speeds.



New reverse assist feature for comfortable manoeuvring and Shift Assistant Pro for shifting up and down without activating the clutch.



The new K 1600 B is particularly easy to manoeuvre thanks to the reverse assist feature. This is activated conveniently at the press of a button on the left-hand handlebar panel. Pressing the starter button initiates movement.



The Shift Assistant Pro available as an option allows the rider to shift up and down without activating the clutch in a large number of cases.



Comfortable foot rests for a “feet forward” position and optional exclusive forged wheels for individualisation.



A wide range of Original BMW Motorrad Accessories and options available ex works means that nothing is left to be desired in terms of the individualisation of the new K 1600 B. This includes the provision of comfortable foot rests for the passenger, while these elements can also be fitted to offer the rider a particularly relaxed “feet forward” position. Redesigned forged wheels with eleven double spokes each further enhance the exclusivity of the new K 1600 B.



An overview of highlights of the new BMW K 1600 B:
•6-cylinder in-line engine according to EU4 regulations with an output of 118 kW (160 hp) at 7 750 rpm and a maximum torque of 175 Nm at 5 250 rpm.
•Bagger design with eye-catching stretched streamline-style silhouette and low rear section.
•Low rear frame for reduced vehicle height, dropped passenger seat height (- 7 cm) and typical bagger look.
•Fixed side cases with a new compartment design, rear central cover and integrated light units in US-American styling.
•Chrome-plated parallel silencers with ribbed end caps.
•Folding rear mudguard for easy wheel removal.
•Effective wind and weather protection with wind deflectors stretched further back.
•Typical short bagger-style electrically adjustable windscreen.
•Electronic suspension Dynamic ESA with automatic damping adaptation and “Road” and “Cruise” damping modes as standard.
•Reverse assist for even simpler manoeuvrability as an optional equipment item ex works.
•Shift Assistant Pro for shifting up and down without clutch as an ex-works option.
•Intelligent Emergency Call as an ex works option for rapid assistance in the event of an accident or in emergency situations (only in European markets where ConnectedDrive is available).









2017 BMW K1600B www.Totalmotorcycle.com Features and Benefits



The new K 1600 B: luxury cruising and pure traveling pleasure in the all-American bagger style.



The new K 1600 B unites luxury, comfort and touring qualities with the unique design language of a bagger. Starting from the highest point on the front cladding, the flyline typically stretches downward to create a stretched drop-like silhouette in a “streamlining” style. The two side cases mounted on the vehicle form an integrated whole with the rear light units, which echo the style of US automobiles.



Whether on a relaxed ride after a hard day’s work, an enjoyable weekend cruise for two, or an extended holiday trip, the new K 1600 B unites supreme 6-cylinder performance and comfortable touring qualities with the casual relaxation and unique riding style of a bagger.



The characteristic streamlining with a low rear section and masculine colour scheme make for relaxed dynamic elegance. The new all-black (Blackstorm metallic / black for chassis components and the drivetrain) finish of the K 1600 B is largely based on the K 1600 GT Tourer. While long-distance riders will benefit from the superior comfort and consistent touring-style design of the K 1600 GT, the new K 1600 B sets completely new standards with regard to “Grand American Touring”.



Thus, the rear section of the new K 1600 B has been completely redesigned in order to significantly reduce the seat height for even more comfort and for even greater ease of access for passengers. With this special bagger style design, the passenger benefits from a rear section that is a full 70 millimetres lower than the 6-cylinder tourer, resulting in a correspondingly lower seat height. Two attractively shaped passenger seat handles ensure that passengers feel secure on the authentic backward sloping seat.



At the same time, the new rear frame allowed the deep recesses in the body design required for consistency with the design principles, so that the new K 1600 B looks particularly low, stretched and extraordinarily elegant and dynamic. Also redesigned are the fully chrome-plated silencers with additional chrome covers in the area of the catalytic converters, which consciously follow the parallelism of the design concept, fitting in organically with the bagger look.




Side cases with newly redesigned compartments for easy loading and folding rear mudguard for easy dismantling of the wheel. The standard side cases are bolted to the redesigned rear frame. In addition, the rear light units, consisting of a reverse light, side indicators and brake lights, are integrated in the side cases in the style of US “road cruisers”. All lights use LED technology and are therefore particularly economical and long-lived, as well as offering top-quality details.



The redesign of the side cases of the K 1600 GT tourer with slimmer covers and deeper body allows for particularly comfortable and effective loading of luggage on the K 1600 B. Two luggage nets in the lower part of the case provide practical storage for smaller travel equipment. The optional audio connection in the right hand case has an inner pocket that can also hold larger terminal devices, such as a tablet computer. The switch for the passenger seat heater has been handily positioned on the right hand case. The keyless seat bench release is easily accessible, not exposed to dirt and integrated in the left side case.



As part of this redesign of the rear section, the new K 1600 B has an additional rear middle cover. The rear mudguard has been designed to fold upward to make it easier to remove the rear wheel when changing the tire.



Dynamically designed fairing sections for effective wind and weather protection and an impressive visual presence. The lines of the front section of the new K 1600 B slope downward to the front and meet at a point in front of the front wheel. Together with the
redesigned rear section and its backward sloping lines, the K 1600 B creates very low, stretched impression, signalling its close ties to the road.



For the ultimate touring experience, the K 1600 B offers excellent wind and weather protection. To this end, the side sections of the fairing sweep downward and backward from the efficiently designed slipstream deflectors. Wind deflectors not only provide for even better protection for the riders hands, but also give the front section of the new K 1600 B even more presence. The two mirrors fit in perfectly with the overall design, the interchangeable mirror caps also offering an opportunity to individualise the bagger. The generously proportioned mirrors include an aspherical element and offer the best possible view of the following traffic.



The new K 1600 B also features an electrically adjustable, redesigned short windscreen with memory function. This not only effectively protects the rider from wind pressure and eddies, but also returns to home position as soon as the ignition is switched off. In this way it also functions as an anti-theft device




for the navigation system, which is available as an Original BMW Motorrad Accessory.



As you’d expect from the elegant look of the K 1600 B, the chrome-plated mounts for the BMW emblem and insignia and the stretched radiator fit perfectly with the overall design. An additional skid protector in the side area of the engine is intended to prevent damage.



Foot rests for a relaxed “feet forward” position available as an option. As part of the new design, the new K 1600 B follows the bagger look by doing away with the storage compartments on the left and right in the lower part of the engine in the series configuration. This means that it is an easy matter to equip the bagger with extremely comfortable foot rests that allow the rider to
adopt a “feet forward” position. However, the storage compartments are available as an ex works option.



The passenger position can also be upgraded respectively. Because the passenger foot rests close upwards rather than folding back, it is possible to install particularly comfortable foot rests for passengers from the Original BMW Motorrad Accessories Range.



Supreme engine expertise with 6 cylinders. With its 6-cylinder in-line engine, the new K 1600 B likewise conveys a particular fascination, offering not just perfect running smoothness but also supreme performance and abundant torque. Still the most compact 6-cylinder in-line power unit in motorcycle series production, the engine has an output of 118 kW (160 hp) at 7 750 rpm, generates a maximum torque of 175 Nm at 5 250 rpm and thus offers supreme forward thrust in all conditions.



With an engine weight of 102.6 kilograms, the 6-cylinder engine of the K 1600 B remains to this day not just the lightest series-production 6-cylinder engine for motorcycles in the category over 1000 cc: due its very narrow cylinder spacing, it is also significantly slimmer than all other serial production 6-cylinder in-line engines to date. Both are major contributing factors in
creating the active riding character of the K 1600 B.



The new K 1600 B has been designed to meet the requirements of the EU4 pollutant class. Among other things it has corresponding engine mapping, a fuel system with carbon canister for fuel tank ventilation and an exhaust system with altered catalytic converters as well as more dynamically designed end pieces whose horizontal ribbing lends great emphasis to the 6-cylinder theme.




Even more manoeuvring convenience due to the new reverse assist as an optional equipment item ex works. The bagger also makes a nod to luxury, relaxed motorcycling in the form of a reverse assist option. This is activated conveniently as required at the press of
a button on the left-hand handlebar panel. As a result the forward gear is blocked and the reverse gear is engaged. Movement itself is initiated by the rider pressing on the starter motor button, which establishes propulsion via a bendable shaft.



Three riding modes and Dynamic Traction Control DTC for maximum safety when accelerating as standard. Riders of the new K 1600 B have the riding modes “Rain”, “Road” and “Dynamic” directly available to them at the press of a button at the right-hand end of the handlebars so as to be able to adapt to different purposes such as road touring, riding on wet surfaces and sporty, dynamic riding. The traction control function DTC is combined individually with each of the different modes and is fully harmonised with them so as to ensure maximum riding safety.



Shift Assistant Pro for shifting up and down without clutch operation as an ex-works option. The Shift Assistant Pro is also available for the K 1600 B, enabling the rider to shift up and down without activating the clutch in the relevant load and engine speed ranges, which gives the rider not just greater comfort but also a bonus in terms of dynamic performance. Most shifting can be carried out using the shift assistant.



When accelerating, the throttle valve (throttle grip) no longer has to be closed for shifts using the throttle hand, so propulsion power is virtually constant without torque interrupt. When decelerating and shifting down (throttle grip/throttle valve closed), the engine speed is automatically adapted by means of double-declutching. Gears are engaged as usual by means of the gear pedal.



Shift time is significantly reduced as compared to a gearshift using the clutch. There is no shift support when the clutch is activated, when shifting up with the throttle grip closed (coasting) or when decelerating. Ideal concentration of masses, proven suspension technology for dynamic riding properties. The essential chassis elements of the new BMW K 1600 B are the light alloy
bridge-type frame familiar from the K 1600 GT and the well-proven BMW Motorrad Duolever and Paralever systems for wheel control at front and rear. The new K 1600 B also benefits from a low overall centre of gravity with a very favourable concentration of masses and a balanced wheel load distribution for excellent riding properties.



Electronic suspension adaptation Dynamic ESA with automatic damping adaptation as standard. The new K 1600 B offers a supreme combination of riding stability, dynamics and light handling in all riding and load states. The electronic suspension
Dynamic ESA with its “Road” and “Cruise” damping modes as standard safeguards a particularly active riding experience with the greatest possible comfort.



In the standard “Road” setting, damping adaptation is fully automated across the entire range, thereby offering the very highest level of comfort and traction over virtually all surfaces. This ensures the optimum damping force in all riding states and regardless of load.



Depending on customer preference, the spring preload can be adapted to the load state at the press of a button and independently of the damping. It is possible to switch to “Cruise” damping mode and thus to more gentle damping at lower speeds at the press of a button.



Using various parameters, the different riding states such as acceleration and deceleration of the new K 1600 B are precisely identified so that the damping forces on the front and rear spring strut can be adapted within milliseconds. As a result, superior damping comfort and a very stable ride response are ensured even in banking position.



Intelligent Emergency Call as an ex works option for swift assistance in the event of an accident or in emergency situations. Ensuring the fastest possible assistance in the event of an accident or in situations of emergency and danger can save people’s lives – something that particularly affects motorcyclists. For this reason, the new K 1600 B can be fitted with the e-call system “Intelligent Emergency Call” as part of an optional equipment item available ex works.



If an emergency situation or an accident occurs, the intelligent emergency call is activated automatically or manually, sending the position data of the motorcycle, and therefore the coordinates of the scene of the accident, setting the rescue chain in motion via the qualified BMW Call Center. However, the emergency call is not automatically triggered in situations which are not emergencies such as when the bike falls over when stationary, after single-vehicle accidents at low speeds, on impact caused by a pot-hole in the
road or when passing over an obstacle.



Sensors on the motorcycle identify what event has occurred. A crash sensor detects events such as collisions with another vehicle or crashing into an obstruction. A banking angle sensor detects high and low-siders, i.e. which position the motorcycle is in.



The operating unit of the optional equipment item “Intelligent Emergency Call” is located on the right-hand side of the handlebars and is compact and ergonomic in design. In addition to the cover-protected SOS button for triggering or interrupting the emergency call, there is also an integrated microphone and speaker.



The optional “Intelligent Emergency Call” function will be available in several European markets for the first time in 2018. It must be remembered that the functionality will only be available in ConnectedDrive enabled markets to start with.



Multifunctional instrument combination and integrated control concept with multi-controller and TUFT display. The instrument cluster of the new K 1600 B has two classic circular instruments for the speedometer and engine speed display. The information display on the 5.7-inch TFT colour screen allows attractive visualisation of text fields and graphics, among other things. Elements of the integrated operating concept include the multi-controller and a menu guidance system for controlling the comfort functions and the on-board computer.



Comprehensive standard equipment for pure bagger-style pleasure. The new K 1600 B has a very extensive range of standard equipment. This includes xenon headlamps, ABS Pro, heated grips and seat heating, a cruise control and the Multi-Controller.












2017 BMW K1600B – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ See dealer for pricing in USD



Engine
Capacity cc 1649
Bore/stroke mm 72/67.5
Output kW/hp 118/160
at engine speed rpm 7 750
Torque Nm 175
at engine speed rpm 5 250
Type Series
No. of cylinders 6
Compression/fuel 12.2:1 / Premium unleaded (95 RON)
Valve control Bucket tappets
Valves per cylinder 4
Ø intake/outlet mm 29/24.8
Throttle valve diameter mm 52
Engine control BMS-X
Homologation standard EU4
Electrical system
Alternator W 700
Battery V/Ah 12/19
Headlight Xenon low-beam headlamp
Halogen high-beam headlamp
Starter kW 0.7
Power transmission – gearbox
Clutch Multi-plate wet clutch, hydraulically activated
Gearbox Constant-mesh 6speed gearbox, helical cut
Primary ratio 1.617
Transmission ratios I 2.230
II 1.641
III 1.319
IV 1.101
V 0.926
VI 0.788
Rear wheel drive Bevel gear
Transmission ratio 2.75
Suspension
Frame construction type Aluminium bridge frame, load-bearing engine
Front wheel control BMW Motorrad Duolever
Rear wheel control BMW Motorrad Paralever, central spring strut
Spring travel, front/rear mm 115/125
Wheel castor mm 106.4
Wheelbase mm 1618
Steering head angle ° 62.2
Brakes front Twin disc brake, Ø 320 mm, 4-piston fixed callipers
rear Single disc brake, Ø 320 mm, 2-piston floating calliper
ABS BMW Motorrad ABS (partial integral)
Traction control Optional BMW Motorrad DTC
Wheels Aluminium cast wheels
front 3.50 x 17″
rear 6.00 x 17″
Tires front 120/70 ZR 17
rear 190/55 ZR 17
Dimensions and weights
Total length mm 2324
Total width with/without mirrors mm 1000/980
Seat height (without rider) mm 780
Unladen weight according to DIN, road ready, fully fuelled kg 336
Permitted total weight kg 560
Fuel tank capacity l 26.5
Performance figures
Fuel consumption (WMTC) l/100 km 5.7
Acceleration 0-100 km/h s 3.2
Top speed km/h > 200
















2017 BMW K1600B – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See dealer for pricing in CDN

Engine
Capacity cc 1649
Bore/stroke mm 72/67.5
Output kW/hp 118/160
at engine speed rpm 7 750
Torque Nm 175
at engine speed rpm 5 250
Type Series
No. of cylinders 6
Compression/fuel 12.2:1 / Premium unleaded (95 RON)
Valve control Bucket tappets
Valves per cylinder 4
Ø intake/outlet mm 29/24.8
Throttle valve diameter mm 52
Engine control BMS-X
Homologation standard EU4
Electrical system
Alternator W 700
Battery V/Ah 12/19
Headlight Xenon low-beam headlamp
Halogen high-beam headlamp
Starter kW 0.7
Power transmission – gearbox
Clutch Multi-plate wet clutch, hydraulically activated
Gearbox Constant-mesh 6speed gearbox, helical cut
Primary ratio 1.617
Transmission ratios I 2.230
II 1.641
III 1.319
IV 1.101
V 0.926
VI 0.788
Rear wheel drive Bevel gear
Transmission ratio 2.75
Suspension
Frame construction type Aluminium bridge frame, load-bearing engine
Front wheel control BMW Motorrad Duolever
Rear wheel control BMW Motorrad Paralever, central spring strut
Spring travel, front/rear mm 115/125
Wheel castor mm 106.4
Wheelbase mm 1618
Steering head angle ° 62.2
Brakes front Twin disc brake, Ø 320 mm, 4-piston fixed callipers
rear Single disc brake, Ø 320 mm, 2-piston floating calliper
ABS BMW Motorrad ABS (partial integral)
Traction control Optional BMW Motorrad DTC
Wheels Aluminium cast wheels
front 3.50 x 17″
rear 6.00 x 17″
Tires front 120/70 ZR 17
rear 190/55 ZR 17
Dimensions and weights
Total length mm 2324
Total width with/without mirrors mm 1000/980
Seat height (without rider) mm 780
Unladen weight according to DIN, road ready, fully fuelled kg 336
Permitted total weight kg 560
Fuel tank capacity l 26.5
Performance figures
Fuel consumption (WMTC) l/100 km 5.7
Acceleration 0-100 km/h s 3.2
Top speed km/h > 200






















2017 BMW K1600B – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)



Engine
Capacity cc 1649
Bore/stroke mm 72/67.5
Output kW/hp 118/160
at engine speed rpm 7 750
Torque Nm 175
at engine speed rpm 5 250
Type Series
No. of cylinders 6
Compression/fuel 12.2:1 / Premium unleaded (95 RON)
Valve control Bucket tappets
Valves per cylinder 4
Ø intake/outlet mm 29/24.8
Throttle valve diameter mm 52
Engine control BMS-X
Homologation standard EU4
Electrical system
Alternator W 700
Battery V/Ah 12/19
Headlight Xenon low-beam headlamp
Halogen high-beam headlamp
Starter kW 0.7
Power transmission – gearbox
Clutch Multi-plate wet clutch, hydraulically activated
Gearbox Constant-mesh 6speed gearbox, helical cut
Primary ratio 1.617
Transmission ratios I 2.230
II 1.641
III 1.319
IV 1.101
V 0.926
VI 0.788
Rear wheel drive Bevel gear
Transmission ratio 2.75
Suspension
Frame construction type Aluminium bridge frame, load-bearing engine
Front wheel control BMW Motorrad Duolever
Rear wheel control BMW Motorrad Paralever, central spring strut
Spring travel, front/rear mm 115/125
Wheel castor mm 106.4
Wheelbase mm 1618
Steering head angle ° 62.2
Brakes front Twin disc brake, Ø 320 mm, 4-piston fixed callipers
rear Single disc brake, Ø 320 mm, 2-piston floating calliper
ABS BMW Motorrad ABS (partial integral)
Traction control Optional BMW Motorrad DTC
Wheels Aluminium cast wheels
front 3.50 x 17″
rear 6.00 x 17″
Tires front 120/70 ZR 17
rear 190/55 ZR 17
Dimensions and weights
Total length mm 2324
Total width with/without mirrors mm 1000/980
Seat height (without rider) mm 780
Unladen weight according to DIN, road ready, fully fuelled kg 336
Permitted total weight kg 560
Fuel tank capacity l 26.5
Performance figures
Fuel consumption (WMTC) l/100 km 5.7
Acceleration 0-100 km/h s 3.2
Top speed km/h > 200







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).

About Michael Le Pard 10093 Articles
"Mr. Totalmotorcycle". Owner and Founder of Total Motorcycle, the World’s Largest Motorcycle Site with over 425 million readers since 1999. Total Motorcycle is my pride and joy and being able to reach 425 million people has been incredible and I could not have done it without the support of my visitors, readers and members...thank you so much! We are all making a difference to millions of riders worldwide.

Be the first to comment

Leave a Reply
