2017 KTM 150 XC-W Review

2017 KTM 150 XC-W on www.Totalmotorcycle.com

Minimal Fuss, Maximum Fun…

‘XC’ means cross-country. ‘W’ represents its wide-ratio transmission. ‘KTM’ stands for winning. This model is a race-ready bike built for closed course enduro racing. With the agility of a 125 and enough muscle to take the fight to the 250 cc 4-Strokes, this bike punches well above its weight. That’s why when the going gets tough, the tough get an XC-W.

2017 KTM 150 XC-W www.Totalmotorcycle.com Key Features

A NEW GENERATION OF KTM ENDURO MACHINES IS HERE!

KTM once again underlines its commitment to its foundations in offroad, as its world-dominating, class-leading Enduro machines have been completely revised with a staggering 90 per cent of the model year 2017 line-up’s components being new. Notable weight reductions of up to five kilograms have been realized throughout the model range, with improved mass centralization resulting in increased performance and better handling.

For MY2017 the line-up has been changed to include the 125 XC-W and 150 XC-W (replacing the 125 and 200 EXC), which are specifically designed for closed course racing, as well as the more traditional, fully homologated powerhouses with the 250 EXC and 300 EXC in the 2-stroke range. In the 4-stroke range KTM continues with its completely updated versions of the 250 EXC-F, 350 EXC-F models, as well as modifying the name of the higher capacity models to fall in line with the typical 4-stroke name to 450 EXC-F and 500 EXC-F.

Not only does each machine receive a new chassis with new suspension including the WP XPlor 48 upside-down split fork by WP, the R&D team in Mattighofen, Austria combined with its network of test riders, factory racing teams and input from KTM North America R&D, has worked tirelessly to deliver new engines at the same time with improved performance, reduced weight and a more compact size to assist with better machine handling.

With refinements from the frame and bodywork, down to the smaller details in the dashboard of these READY TO RACE machines, KTM has utilized the latest technology to consider every improvement possible for the amateur rider right up-to the professional world championship racer.

Following a tried and tested tradition, the specially finished SIX DAYS models stand side by side with the legendary, new generation EXC bikes. Available as 2- and 4-stroke bikes and equipped with several performance-enhancing and useful technical parts, the new “Six Days Spain” bikes, designed with sophisticated special graphics, top the latest KTM EXC model range.

Joachim Sauer (KTM Offroad Product Manager): “As the saying goes, after the race is before the race. According to our understanding in state-of-the-art development, the brand new line-up of our offroad competition Enduros are proof of KTM`s ongoing commitment to our core discipline. We believe this Enduro sportmotorcycle range will push the excitement and satisfaction of any rider to a new level.”

The new KTM MY2017 Enduro range was unveiled yesterday evening at its launch in Les Comes, Spain and the new machines will begin to arrive in European dealers in June.

2017 KTM 150 XC-W www.Totalmotorcycle.com Features and Benefits

AGILE ATHLETE

WEIGHT REDUCTION
The main target for the KTM engineers when developing the XC-W models was a massive weight reduction compared to the previous generation. The result: the current XC-W’s are the slimmest, lightest bikes in the enduro segment.

FRAME
The high-tech, lightweight chrome-moly steel frame is engineered for excellent handling, precise cornering and supreme stability. You can also count on high torsional rigidity and low longitudinal stiffness for better absorption of the energy created by the front and rear suspension sucking up jumps and bumps. In short: more comfort and less rider fatigue. Laterally attached, lightweight engine head stays contribute to a reduced vibration level. Two threaded inserts in the lower cradle tubes allow for an optional skid plate. The engineers were able to pull off all that, while making the frame two pounds lighter than that of the lightest competitor on the market. In addition, the frame is easier to maintain, easier to work on and supplies more space for the tank and other components. The bike also features an extra-light aluminum subframe, which weighs in at less than 2 pounds.

FOOTPEGS
Sophisticated “No Dirt” footpegs prevent smudging up the pegs, even when digging in deep ruts. The pegs on the EXC models are 6mm higher than the ones used on SX models, which benefits ground clearance. But you can swap them at will.

SWINGARM
This updated design allows for an optimized mounting position of the PDS shock, providing more progressive action. Furthermore, the cast aluminum design guarantees lower weight and a perfect flex behavior. The single-component casting process also eliminates any inconsistencies and weak points.

REAR SUSPENSION
The WP XPlor PDS is a newly developed rear shock. The PDS, the KTM proven and successful progressive damping system is kind of a KTM trademark where the shock absorber is directly connected to the upper side of the swingarm. This set-up has now been reworked with the new frame and swingarm architecture in mind. It boasts the best possible mounting geometry, provides even more progressive damping and features an all-new body with a smaller piston and a larger reservoir. The piston diameter was reduced from 50 to 46mm for reduced weight, the total length is reduced by 2.5mm and the shock stroke has been reduced by 4mm. In addition, it is now mounted 5mm closer to the centerline, which means nearly symmetrical loads for the swingarm and frame and more space for the exhaust. A second piston works together with a closed cup (instead of a needle) towards the end of the stroke and is supported by a progressive shock spring for exceptional bottoming resistance. With this new design comes a weight savings of 1.4 pounds. Various machined and anodized components and a distinctive WP color trim make this a valuable, high-end product compared to the less refined shocks of the competition.

FRONT SUSPENSION
The all-new WP XPlor 48 upside-down fork is a split fork developed by WP in close collaboration with KTM. It is fitted with a spring on both sides but features separated functions for each fork leg: compression damping is fitted on the left side, while rebound is on the right. So the forks can easily be adjusted for compression and rebound with the twist of a dial on the top of the forks. In addition, a longer and sealed hydro-stop guarantees better resistance to bottoming-out. Due to high-quality materials and a state-of-the-art production process, the new XPlor 48 fork – with approx. 300mm of travel – has outstanding response and damping characteristics and is about a half of a pound lighter than its predecessor.

BRAKES
You can’t brake any harder, better, faster or stronger. High-tech Brembo calipers are combined with lightweight wave discs and feature a reduced piston diameter for better modulation. The rear brake now features a 10mm longer brake pedal, and less aggressive brake pads are fitted front and rear. The steel-flex front brake hose gets more efficient protection and there’s an integrated channel for the speedo cable. First you outrun them, then you outbrake them.

HANDLEBARS
KTM engineers know how to handle handlebars. This tapered unit, made of high-strength aluminum by NEKEN, features a newly developed throttle assembly with a robust aluminum body and easy free-play adjustment. An ODI volcanized grip sits on the right, while on the left side of the bar a comfortable ODI lock-on grip requires no glue or wire to secure it.

TRIPLE CLAMPS
The new generation is fitted with forged triple clamps with an offset of 22mm, ensuring a solid grip of the fork and precise handling. The handlebar is adjustable forwards and backwards over 4 positions, so the XC-W will fit you like your favorite gloves.

INTELLIGENT DESIGN

BODYWORK
KTM R&D, Kiska Design and the factory racers had their say in shaping the plastics with one goal: complete harmony between rider and bike. Perfect ergonomics and contact points provide maximum comfort in movement on the XC-W. The I-beam structures of the front and rear fenders guarantee maximum stability and a low weight thanks to well thought-out construction and mounting. They also stay cleaner for longer. Cleaver brake hose routing on the front number plate prevents wear and tear.

GRAPHICS
New graphics conveying the true READY TO RACE character of the 2017 XC-W model line.

LESS IS MORE

ENGINE

The new 150 XC-W engine is the most powerful and most competitive engine in its class, providing precisely the kind of power an Enduro rider wants. This 150 cc ripper has been developed with the latest KTM engineering know-how and the most advanced technology available. The results: whopping power and mountain conquering torque across the entire rev range, while being extremely compact and light.

CYLINDER AND CYLINDER HEAD
This compact cylinder with a 58 mm bore features a cutting-edge power valve unit with a sophisticated mechanism for the lateral support exhaust ports. Matched to a twin-component cylinder head, it is KTM’s secret to all-round grunt. The layout of the cylinder and head water jackets guarantee efficient heat dissipation when you’re riding at your limit.

ENGINE CASES
For the latest engine generation the KTM engineers designed lightweight die-cast engine cases featuring a high crankshaft and clutch shaft position, located close to the center of gravity, which results in optimal mass centralization and outstanding rideability. In addition, the entire engine is extremely lightweight and compact, while still able to house an electric starter. And because looks matter, newly designed engine covers feature an advanced surface structure in order to reduce the wear caused by the rider’s boots.

CARBURETOR
As of model year 2017, all KTM 2-stroke models are fitted with new MIKUNI TMX carburetors. These 38mm flat slide carbs provide smooth and controllable power all the way up to the limiter. And they’re less sensitive to altitudes and temperatures changes, so you can pin it wherever, whenever.

TRANSMISSION
A wide-ratio 6-speed enduro transmission was designed specifically for the small 2-stroke enduro engine, its gear ratios perfectly in sync with the 150 XC-W’s power band. The latest production technologies allow for compact dimensions and minimal weight. An advanced ´No Dirt´ gear lever design prevents mud or dirt build-up in the joint. Because even dirt lovers hate mud when it’s in the wrong places.

CLUTCH
The clutch of the new engine is activated by a new Brembo hydraulic system. The reliable and self-adjusting unit guarantees light operation and highly controllable modulation.

EXHAUST
The engineers meticulously tuned the expansion chamber for maximum power, so this little screamer is as tough as it is strong.

PISTON
The 150 XC-W’s piston is optimized for maximal reliability and the reworked shape fits brilliantly to the new cylinder layout.

CRANKSHAFT
A reliable piece of engineering that has been skillfully balanced to guarantee minimal vibrations. This new crankshaft allows the rider to change the displacement to125 cc just by replacing cylinder, piston and head. There’s no more need to change the crankshaft. Two-in-one in no time.

PERFORMANCE PERKS

ELECTRIC STARTER
The design of the new 150 cc engine features one of the best assets in the dirt bike world: an electric starter powered by a reliable lithium ion battery. This magic button’s benefits are clear, especially for those of you looking to compete on an extreme level.

AIRBOX
The airbox design, featuring new snorkels, offers maximum protection of the air filter against soiling, while ensuring maximum airflow in a quiet way. The new, large Twin Air filter is mounted in a stiff cage, which at the same time holds the system in place. This design is so simple, you can pop a fresh one in with a face full of mud – without tools and in seconds.

FUEL TANK
The lightweight polyethylene tank has a capacity of 2.5 gallons. You will always be able to see how much fuel remains at a glance, thanks to the see-through plastic. By pushing the orange release button in the center of the filler cap, the bayonet mechanism makes refueling quick and easy.

WHEELS
The XC-W’s wheels feature lightweight, CNC machined hubs and high-end Giant rims guaranteeing maximum stability at minimum weight. The wheels are fitted with the latest Dunlop Geomax AT81 tires for traction in any terrain.

COOLING SYSTEM
KTM’s proven cooling system routes the coolant from the cylinder head through the frame triangle, directly to aluminum radiators made by WP. A new filler cap system and are stiffer alloy construction increase the durability and reliability of the cooling system. Due to flow optimized internal circulation and CFD-calculated air ventilation, the system is superbly efficient. In addition, well thought-out radiator guards integrated in the front part of the shrouds provide protection in a crash.

SEAT
Tailored to meet the needs of the best off-road racers, this durable seat offers great comfort, while being 10mm lower to help you master the most challenging terrain.

BATTERY & WIRING HARNESS
These engines are fitted with KTM’s proven electric starter – a unique KTM feature and a major benefit at all levels of racing. A super compact 495g lithium ion starter battery breathes life into the engine, shaving off two pounds of excess weight while offering three times the starting energy of a conventional battery. The battery and wiring harness are centralized in a compartment above the airbox, allowing the mechanic to remove the subframe without having to remove the electronics. A happy mechanic is a good mechanic. .

2017 KTM 150 XC-W – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ See Dealer for Pricing in USD

Engine

Design

1-cylinder, 2-stroke engine

Displacement

143.99 cm³

Bore

58 mm

Stroke

54.5 mm

Starter

Kick and electric starter

Transmission

6-speed

Primary drive

1.009027778

Secondary gear ratio

13:50

Clutch

wet multi-disc clutch, Brembo hydraulics

EMS

Kokusan

Chassis

Frame design

25CrMo4 steel central-tube frame

Rear suspension

WP Xplor PDS shock absorber

Suspension travel (front)

300 mm

Suspension travel (rear)

310 mm

Front brake

Disc brake

Rear brake

Disc brake

Front brake disc diameter

260 mm

Rear brake disc diameter

220 mm

Chain

X-Ring 5/8 x 1/4″

Steering head angle

63.5 °

Wheelbase

1471 ± 10 mm

Ground clearance

370 mm

Seat height

960 mm

Tank capacity (approx.)

9.5 l

Weight READY TO RACE (without fuel)

91.5 kg

The illustrated vehicles may vary in selected details from the production models and some illustrations feature optional equipment available at additional cost.
All information concerning the scope of supply, appearance, services, dimensions and weights is non-binding and specified with the proviso that mistakes, printing, setting and typing errors may occur; such information is subject to change without notice.

2017 KTM 150 XC-W – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See Dealer for Pricing in CDN

Engine

Design

1-cylinder, 2-stroke engine

Displacement

143.99 cm³

Bore

58 mm

Stroke

54.5 mm

Starter

Kick and electric starter

Transmission

6-speed

Primary drive

1.009027778

Secondary gear ratio

13:50

Clutch

wet multi-disc clutch, Brembo hydraulics

EMS

Kokusan

Chassis

Frame design

25CrMo4 steel central-tube frame

Rear suspension

WP Xplor PDS shock absorber

Suspension travel (front)

300 mm

Suspension travel (rear)

310 mm

Front brake

Disc brake

Rear brake

Disc brake

Front brake disc diameter

260 mm

Rear brake disc diameter

220 mm

Chain

X-Ring 5/8 x 1/4″

Steering head angle

63.5 °

Wheelbase

1471 ± 10 mm

Ground clearance

370 mm

Seat height

960 mm

Tank capacity (approx.)

9.5 l

Weight READY TO RACE (without fuel)

91.5 kg

The illustrated vehicles may vary in selected details from the production models and some illustrations feature optional equipment available at additional cost.
All information concerning the scope of supply, appearance, services, dimensions and weights is non-binding and specified with the proviso that mistakes, printing, setting and typing errors may occur; such information is subject to change without notice.

2017 KTM 150 XC-W – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)

Engine

Design

1-cylinder, 2-stroke engine

Displacement

143.99 cm³

Bore

58 mm

Stroke

54.5 mm

Starter

Kick and electric starter

Transmission

6-speed

Primary drive

1.009027778

Secondary gear ratio

13:50

Clutch

wet multi-disc clutch, Brembo hydraulics

EMS

Kokusan

Chassis

Frame design

25CrMo4 steel central-tube frame

Rear suspension

WP Xplor PDS shock absorber

Suspension travel (front)

300 mm

Suspension travel (rear)

310 mm

Front brake

Disc brake

Rear brake

Disc brake

Front brake disc diameter

260 mm

Rear brake disc diameter

220 mm

Chain

X-Ring 5/8 x 1/4″

Steering head angle

63.5 °

Wheelbase

1471 ± 10 mm

Ground clearance

370 mm

Seat height

960 mm

Tank capacity (approx.)

9.5 l

Weight READY TO RACE (without fuel)

91.5 kg

The illustrated vehicles may vary in selected details from the production models and some illustrations feature optional equipment available at additional cost.
All information concerning the scope of supply, appearance, services, dimensions and weights is non-binding and specified with the proviso that mistakes, printing, setting and typing errors may occur; such information is subject to change without notice.
