RUN. TURN. STOP.

Completely redesigned for 2018, the RM-Z450 wraps a sleek, race-ready appearance around a stronger engine and a nimble chassis that continues the Suzuki tradition of extraordinarily precise handling. Developed using Suzuki’s RUN, TURN and STOP philosophy that creates a Winning Balance, the 2018 RM-Z450 has stronger brakes for better stopping power, a wider spread of engine muscle with higher peak power, and a chassis that is stronger, lighter and more nimble to raise the standard for cornering performance.

Enlist in the RM ARMY and enjoy Suzuki Amateur Racing Support! Suzuki’s RM Army and Amateur Racing Support is top notch, offering over $3.8 million in contingency, trackside support, and the opportunity to train with Ricky Carmichael at Suzuki’s exclusive Camp Carmichael. Want to see why champions choose Suzuki? Visit racesuzuki.com for more information on Suzuki’s Amateur Support Program and enlist in the RM ARMY!

THE WINNING BALANCE.

Completely redesigned for 2018, the RM-Z450 wraps a sleek, race-ready appearance around a stronger engine and a nimble chassis that continues the Suzuki tradition of extraordinarily precise handling. Developed using Suzuki’s RUN, TURN and STOP philosophy that creates a Winning Balance, the 2018 RM-Z450 has stronger brakes for better stopping power, a wider spread of engine muscle with higher peak power, and a chassis that is stronger, lighter and more nimble to raise the standard for cornering performance

2018 Suzuki RM-Z450 Totalmotorcycle.com Key Features

Increased Engine Performance – Improved Throttle Response with Higher Peak Power – Evolved Traction Management System Helps the Bike Hook Up – Updated Suzuki Holeshot Assist Control (S-HAC) Gets You Out Front

Advanced Cornering Performance
– New Frame and Swingarm are Lighter with Excellent Strength
– Refined Chassis Dimensions Blend Nimble Handling with Stability
– Improved Coil-spring Fork Provides Great Performance and Easy Tuning
– New Showa BFRC Rear Shock Delivers Remarkable Damping Response
– Bridgestone X30 Tires bring Outstanding Grip

Improved Braking Performance
– Larger Front Brake Increases Stopping Power and Feel
– New, Compact Rear Master Cylinder is out of the Way of Mud and Boots

Functional Styling
– Aggressive New Styling Blends Function with Suzuki Character
– Narrow Cockpit Lets Rider Move with Ease for Maximum Racing Performance

2018 Suzuki RM-Z450 Totalmotorcycle.com Features and Benefits

Engine Features
New 449cc liquid-cooled 4-stroke, 4-valve DOHC engine is the latest incarnation of Suzuki’s proven and reliable, fuel-injected powerplant

The engine has higher peak horsepower with more torque at lower engine speeds for improved throttle response through the entire rev-range

The cylinder head intake port shape is changed to tumble flow the fuel/air mixture by 25% to help increase power output

A 30% larger air cleaner opening is combined with a more direct air cleaner outlet tube path to the throttle body to increase air flow

Advanced fuel-injection system makes for extra-smooth power delivery, high fuel efficiency, and superb reliability

The RM-Z450 has a new, Suzuki-unique throttle body design with a relocated fuel injector fed by a new, higher-pressure fuel pump directly sprays fuel at the butterfly valve to improve atomization of the fuel/air charge

The new throttle body design eliminates complex control linkage so the rider feels a more direct connection to the engine

The intake camshaft profile is changed, including more valve lift that the prior model, increasing power at all engine speeds

The compact aluminum cylinder is finished with Suzuki Composite Electrochemical Material (SCEM) coating for durability, light weight and efficient heat transfer

The piston’s casting is ungraded to include strengthening ribs near the wrist pin bosses to match component reliability to the higher horsepower

Engine starting is simple and efficient due to a long kick starter lever, refined internal gears, larger air cleaner and breather system, plus an automatic decompression system that works precisely and efficiently (eliminating the need for a heavy and costly electric start system)

The high-flow exhaust system complies with AMA sound regulations

New engine protectors help guard the coolant pump (on the right) and the stator cover (on the left) from debris and stones

Advanced Electronic Features
The 2018 RM-Z450 features an evolved and faster traction management system. The Electronic Control Module (ECM) continually measures throttle opening, engine speed and gear position and then adjusts the ignition timing and fuel injector duration to fine-tune the engine output to deliver the best traction for the riding conditions.

The RM-Z450’s traction management system is different from a street-bike traction control system as it does not measure rear tire spin. Because the needs of a motocrosser are different than a street bike, this system offers constant adjustment that maximizes traction at all times.

The Suzuki Holeshot Assist Control (S-HAC) is a selectable launch system derived from the factory race bike to help riders’ takeoff from the starting gate for an early lead. There are three modes riders can choose for the best option per their skill level and starting conditions. There are three stages to A – Mode and B – Mode of the S-HAC system. This helps riders at the moment of launch, when crossing the gate, and through acceleration to the full-speed. The S-HAC settings for A – Mode on the 2018 RM-Z450 are updated to aid the rider’s throttle control during launches.

A – Mode: For hard surfaces or slippery conditions at the starting gate. In this mode, S-HAC alters ignition timing at the moment of launch and the ride over the gate to reduce wheel slip to deliver a smooth take off. It also advances ignition timing during this sequence for stronger acceleration. After 1.2 seconds or when you reach third gear, the system shuts off and returns to normal ignition timing.

– Benefit of A – Mode: For novice riders, and/or hard and slippery traction conditions, use A – Mode for a more controlled launch.

B – Mode: When conditions at the starting gate have better traction, and a more aggressive launch is desired. S-HAC will advance the ignition timing to allow increased throttle response and stronger acceleration off the line. The ignition timing alternation is in a similar sequence as A – Mode, but with increased overall timing. One of three conditions will return the ignition to normal operation (whichever happens first): After 4.5 seconds has passed since throttle opening, or when you shift to 4th gear, or when the throttle is closed.

– Benefit of B – Mode: For skilled riders, and/or good starting conditions, use B – Mode for a more aggressive launch.

Base Mode: Standard power launch, no action required on the S-HAC switch. Designed for motocross-use, the lightweight, battery-less, electronic fuel injection system is key to the engine delivering efficient power.

Easy-to-use Fuel Couplers are included to simplify EFI tuning.

For quick fuel adjustments to suit riding conditions, two couplers are provided. One is for rich and another for lean fuel setting compared to stock setting. Riders can change fuel settings in seconds by simply connecting either coupler to the wire harness.

Transmission Features
Refined 5-speed transmission enables precise gear shift operation. The transmission feel has been improved with a precisely machined shift cam for accurate gear selection. Specialized machining processes also increase the precision of the matching gears

The multi-plate, wet-clutch uses rack & pinion clutch release mechanism for precise feel of the engagement and disengagement points while riding

The new, lighter-weight chain guide is shaped to accurately route the drive chain smoothly

Chassis Features
The 2018 RM-Z450 features a new frame and swingarm design that continues the Suzuki’s reputation as the best handling motocrossers available

The new aluminum-alloy twin-spar frame combines cast and extruded sections to achieve superior front-and-rear weight distribution while balancing strength and weight

The new frame is 700 grams (1.32 lbs.) lighter to improve cornering performance and shock absorption while delivering stable handling

The new swingarm is assembled with thinner materials for 100 grams (0.25 lbs.) lower weight while cornering performance and handling stability is improved

The wheelbase is shorter and the frame head pipe is relocated to produce quick and nimble handling characteristics

New hexagonal aluminum rails are used on the sub-frame for lighter weight, a slimmer appearance and easier air-filter service

The sub-frame rails are moved inward to slim the bodywork, but are also raised to provide additional space for the larger air cleaner and the advanced BFRC shock absorber

Not only is the sub-frame thinner, but the all of the body work is slim to enable the RM-Z450 rider to move freely in the cockpit, especially during spirited riding

Inspired by the advanced suspension from the GSX-R1000R Superbike, the RM-Z450 has a new SHOWA Balance Free Rear Cushion (BFRC) shock absorber

The fully adjustable BFRC controls damping so well during minute suspension movements that ride comfort is increased at lower speeds while stability is enhanced at higher speeds

The BFRC uses a separate, external damping circuit that improves the responsiveness of damping force to deliver excellent traction and better absorption over bumps

To improve stopping performance and feel, a larger 270mm wave-style front brake rotor is used

A new, lighter upper fork bracket is used to complement the new front suspension and handlebars

Springs in each fork leg combine with larger, adjustable damping cylinders to deliver better response to the terrain and provide a strong feeling of control to the rider

The strong, RENTHAL aluminum tapered handlebar have a straighter bend that prior models to help aid the rider during aggressive maneuvering

New generation, improved SHOWA coil spring front fork has larger inner tubes and rod pipes for strength and durability. Front suspension tuning and maintenance is balanced and easy; a great benefit during frequent riding

A new design rear brake master cylinder hugs the frame beam to reduce dirt contamination and the chance of the rider’s boot touching it during riding

The wheels feature black-anodized rims with a new cross-section design that maintains strength while reducing un-sprung weight

To support the additional engine, braking and handling performance of the 2018 RM-Z450, the tires are updated to the race-track developed Bridgestone Battlecross X30 tires

Suzuki MXGP-inspired styling has a sharper front fender and radiator shrouds blending into side covers and an upswept tail to promote the impression of speed while reducing weight and easing service

A new plastic fuel tank weighs half-a-pound less than the prior model’s aluminum tank. Fuel capacity is raised to 1.7 US gallons

The functional styling and the motorcycle’s trim chassis permits a variety of rider positions that facilitate control and comfort

The seat base, inner fenders and side covers were developed to reduce moisture and dirt from getting to the air cleaner. This helps prevent debris from contaminating the air filter element

The new seat is slimmer, with revised foam density to aid the rider’s control of the motorcycle. The seat weighs half-a-pound less than the prior model and has a large, blue gripper panel that runs nose-to-tail on the cover

The Suzuki Championship Yellow bodywork is enhanced with distinctive blue and black striping and modern logo graphics

2018 Suzuki RM-Z450 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ See Dealer for Pricing in USD

Engine
Engine 449cc, 4-stroke, liquid-cooled, single cylinder, DOHC
Bore Stroke 96.0 x 62.1 mm (3.78 x 2.4 in)
Compression Ratio 12.5:1
Fuel System Fuel Injection, 44 mm throttle body
Starter Primary kick-start with automatic decompressor
Lubrication Semi-dry sump
Drive Train
Transmission 5-speed constant mesh
Clutch Wet multi-plate
Final Drive Chain, DID 520DMA2K, 114 links
Chassis
Suspension Front Inverted telescopic, coil spring, oil damped, adjustable damping force
Suspension Rear BFRC – link type, coil spring, oil damped, adjustable spring preload & damping force
Brakes Front Disc brake, single rotor
Brakes Rear Disc brake, single rotor
Tires Front 80/100-21 M/C 51M, tube typetype
Tires Rear 110/90-19 M/C 62M, tube type
Fuel Tank Capacity 6.3 L (1.6 US gallons)
Color Championship Yellow with black/blue accents
Electrical
Ignition Electronic Ignition (CDI)
Spark Plug NGK　DIMR8C10
Dimensions
Overall Length 2175 mm (85.6 in.)
Overall Width 835 mm (32.9 in.)
Overall Height 1260 mm (49.6 in.)
Wheelbase 1480 mm (58.3 in.)
Ground Clearance 330 mm (13.0 in.)
Seat Height 960 mm (37.8 in.)
Curb Weight 112 kg (247 lbs.)
Warranty
Not applicable No Warranty

2018 Suzuki RM-Z450 – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See Dealer for Pricing in CDN

Engine
Type 4-stroke, liquid-cooled, single cylinder, DOHC
Displacement 449cc
Bore x Stroke 96.0 x 62.1 mm (3.78 x 2.4 in)
Compression Ratio 12.5:1
Fuel System Fuel Injection, 44 mm throttle body
Starter Primary kick-start with automatic decompressor
Lubrication Semi-dry sump
Drivetrain
Transmission 5-speed constant mesh
Clutch Wet multi-plate
Final Drive Chain, DID 520DMA2K, 114 links
Chassis
Overall Length 2175 mm (85.6 in.)
Overall Width 835 mm (32.9 in.)
Overall Height 1260 mm (49.6 in.)
Wheelbase 1480 mm (58.3 in.)
Ground Clearance 330 mm (13.0 in.)
Seat Height 960 mm (37.8 in.)
Curb Mass 112 kg (247 lbs.)
Suspension Front Inverted telescopic, coil spring, oil damped, adjustable damping force
Suspension Rear BFRC – link type, coil spring, oil damped, adjustable spring preload & damping force
Brakes Front Disc brake, single rotor
Brakes Rear Disc brake, single rotor
Tires Front 80/100-21 M/C 51M, tube typetype
Tires Rear 110/90-18 M/C 62M, tube type
Fuel Tank 6.3 L (1.6 US gallons)
Warranty
Standard Warranty No Warranty

2018 Suzuki RM-Z450 – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)

NA

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
