2022 Honda Rebel 500 ABS SE Guide

2022 Honda Rebel 500 ABS SE

2022 Honda Rebel 500 ABS SE 2022 Honda Rebel 500 ABS SE

2022 Honda Rebel 500 ABS SE: HEAD-TURNING PERFORMANCE.

Introducing the 2022 Honda Rebel 500 ABS SE…

Go all-in on performance, agility, and style, with the 2022 Rebel 500. The lean 471cc twin-cylinder engine and user-friendly powerband deliver enjoyment through city streets and wide-open straightaways. The wide front wheel and blacked-out engine gives it head-turning style to go with the modern innovations every rider should demand. Like optional ABS brakes. Full LED lighting package. And Honda’s slipper/assist clutch that helps make every ride more fun. The low-seat height lets you flat foot it at stoplights, while new colors for this year make it even more irresistible. Back by popular demand, the Rebel 500 ABS SE comes with some of our most popular accessories like a Black Diamond-Stitch Seat, Black Fork Boots and Covers, and a color-matched Headlight Cowl. Yes, the Rebel 500 is a no-compromises modern cruiser. And we’ve got one waiting for you.



Premium Features

Anti-lock brakes ABS

Factory installed custom accessory package

Standard Features

471cc liquid-cooled parallel-twin engine

Fuel injection

Low 27.2-inch seat height

Blacked-out style

Wide 16-inch rear tire

Electric starter

Slipper/assist clutch

Accessory passenger seat and footpeg kit available





2022 Honda Rebel 500 ABS SE Totalmotorcycle.com Key Features

STYLE
BLACKED-OUT STYLE
The Rebel is a blank canvas for your self expression and customization. But unlike the canvas you buy at the art store, this one’s not boring white. As is, its blacked-out engine pieces, frame, and bodywork elements look great during the day and even better at night.

BLACKED-OUT MUFFLER
Forget about having to polish chrome—the Rebel’s blacked-out exhaust system blends perfectly with the bike’s overall look. And maybe the biggest plus? The awesome sound that’s so important to the riding experience.

CLASSIC INSTRUMENT SHAPE
Another iconic element combining traditional and new, the Rebel’s instruments take a classic shape and fill it with totally up-to-date digital LCD information. The instruments include a gear-position indicator and a fuel-consumption display.

FOUR-BULB HEADLIGHT
Another critical item in motorcycle design is the headlight. With the Rebel you get the best of both worlds. The lamp is bright and precise, while the round nacelle shape, aluminum cast headlight mount and glass lens give the Rebel a character that exudes class.

ALL LED LIGHTING PACKAGE
LED lighting is where it’s at now. LEDs can be lighter, brighter, and require fewer lifetime replacements than incandescent bulbs. That’s why the Rebel 500 features an all-LED lighting package—headlight, taillight, turn signals, even the license-plate light.

COLOR CHOICES
Ready for some awesome color choices for 2022? Check out what you can be riding: Matte Gray Metallic or Pearl Organic Green.

OPTIONAL Honda ACCESSORIES
Want to give your Rebel 500 some individual touches? We have an extensive selection of factory accessories. For example, check out the custom seat options, a backrest, saddlebags and rear carrier, passenger seat with footpegs kit, backrest, and much, much more.

LIMITED-EDITION REBEL 500 ABS SE
We’re offering a limited-edition of our Rebel 500 ABS, the SE version. It features some of our most popular accessories, installed at the factory. You get our Brown Diamond-Stich Seat, Black Fork Boots, Black Upper Fork Covers, and a color-matched Headlight Cowl—a knockout combination that takes your Rebel 500 to the next level.

STEEL REAR FENDER
Real steel never goes out of style. The Rebel has a steel rear fender that’s either color-matched to the tank or matte black. The paint looks great, and the steel fender helps provide solid support for the optional/removable passenger seat.

WIDE 41mm FORK
It’s what’s up front that counts most in style, and the Rebel knocks it out of the park. Of course, the front suspension offers precise steering and a plush ride, but the fat 41mm fork tubes give the bike a substantial presence too.

REFINED REAR SUSPENSION
The Rebel 500’s rear shocks are nitrogen filled, and have a special spring rate too. Just like the front suspension, it’s about adding both comfort and performance to your riding experience.

WIDE FRONT WHEEL
The Rebel’s wide 130/90-16 front tire not only looks great, but it helps provide superior handling and stopping power.

COMFORT
LOW SEAT HEIGHT
When it comes to seat heights, almost everyone likes them lower. At just 27.2 inches, the Rebel has one of the lowest seats in anyone’s lineup. It’s comfortable when you ride, and it makes it easier to flat-foot it at stoplights or in parking lots.

LIGHT WEIGHT
Starting at just 408 pounds with a full tank of fuel, the Rebel 500 is a lot more fun and friendly to ride than some bigger machines—perfect if you’re just getting started, or if you’re looking for a nimble bike. The light overall weight and a low center of gravity help performance, too.

NARROW
Super-narrow, especially at the critical tank/seat junction, the Rebel makes it easier to get on and off the bike, and to put your feet down at stops. Plus, the Rebel fits a wide variety of riders.

ROOMY RIDER TRIANGLE
A rider makes contact with the bike at three points: the seat, the handlebar, and the footpegs. The Rebel’s rider triangle strikes the perfect balance between laid-back cruiser and more active sport riding. You ride with a commanding presence, and the minute you sit on a Rebel in your dealership, you’ll know it.

SINGLE SEAT WITH AVAILABLE ACCESSORY PASSENGER SEAT AND FOOTPEG KIT
Travelling light and on your own? Want to take a friend along? Like the clean look of a solo seat? Like the versatility of a passenger seat? With the Rebel you can easily have it both ways, since the accessory passenger seat, passenger footpegs and footpeg hangers are all simple, bolt-on parts.

ENGINEERING
SLIPPER/ASSIST CLUTCH
This technology was first developed and perfected in Honda’s racing machines. The slipper/assist clutch means you get a lighter clutch pull at the lever, but a solid lockup when you release the lever and apply power. It’s technology that reduces clutch effort at the bar by about 30 percent.

SUPERIOR HANDLING
A lot of today’s motorcycles look great standing still, but disappoint once the road gets twisty. At Honda, we set high standards for the way all our bikes handle and feel, and the Rebel is a perfect example—we’ve paid just as much attention to the way this bike corners and handles as we have its knockout styling.

2.9-GALLON FUEL TANK
One of the key items in motorcycle design is the fuel tank. Holding 2.9 gallons, the Rebel’s iconic fuel-tank shape is timeless, but functionally it also teams up with the bike’s great fuel efficiency to give you plenty of range.

DIE-CAST ALUMINUM REAR SUBFRAME
Here’s a chance for Honda designers to take a functional part of the motorcycle and make it look extra cool. The aluminum subframe/fender mounts are strong, subtle, light, and provide a solid foundation for the optional/removable passenger seat.

WIDE REAR TIRE
The Rebel’s low, fat 16-inch rear tire gives you plenty of grip, and helps lower the bike’s overall seat height and stance. And it looks tough, too.

PERFORMANCE
SPORTY ENGINE
Twin-cylinder engines are a great choice for a machine like the Rebel 500. Honda twins are famous for their versatility, and the 471cc Rebel 500’s engine is one of our best ever. The parallel-twin engine is narrow, which helps reduce overall bike size. Plus, it offers lots of low-rpm torque, but plenty of higher-rpm performance.

CAST ALUMINUM WHEELS
Cast wheels front and rear are light, practical, easy to keep clean, and give the Rebel a look that tells you this is not built like a retro machine. The wide rims and tires add to the bikes appearance, too.

FEEL FREE
The CMX500 Rebel is all about freedom for all motorcyclists, particularly A2 licence holders. With a strong, liquid-cooled, parallel twin-cylinder engine cradled in low chassis and updated suspension, lighting, comfort and instruments, it’s a stunning looking bike – a blank canvas – and one that’s ready for whatever your imagination has in store for it.

AN EASY RIDE
Powered by a proven parallel twin-cylinder engine, the response is friendly, smooth and linear – ideal if you’re stepping up from a smaller bike. Thanks to a new exhaust, it’s also now EURO5 compliant, while the addition of an assist-and-slipper clutch aids gearchanges with a 30% lighter lever feel. The riding position is relaxed as you sit, arms outstretched, into the low seat height, ready for the highway. Even at low speed, the Rebel remains comfortable and easy to manage.

SPECIFICATIONS
Rear three quarter shot of Honda CMX500 Rebel being ridden on street.Honda CMX500 Rebel parked outside workshop.
Woman seated on a Honda CMX500 Rebel.

LOW RIDER
A parallel twin tuned for cruising.
Slim enough to nip through town traffic with a low seat height for comfort and sure-footed control.
Moving away from the high rpm-focused performance of the CBR500R, a revised PGM-FI fuel injection map has given the Rebel’s engine a totally different character. It has beefy, bottom-end output with more muscular torque of [email protected] 6,000rpm and – combined with peak power of 34kW @ 8,500rpm – provides satisfying acceleration and strong cruising performance.

Sounding right
The 2-1 exhaust uses two resonator chambers along with a 120mm diameter ‘shotgun’ style muffler. An internal redesign and new LAF sensor help the engine gain EURO5 compliance while the sound produced has a deep pulse thanks to the 180° phased firing order. Take it through the 6-speed gearbox and you’ll be surprised at how strong this motor feels.

SPECIFICATIONS
Front three-quarter facing Honda CMX500 Rebel, street location.Front facing Honda CMX500 Rebel.
Free to ride where you want when you want. The CMX500 Rebel bridges the gap nicely between a smaller machine and a larger capacity motorcycle.

HONDA MOTORCYCLES EXPERIENCE
Make your favourite Honda your own through the Honda Motorcycles Europe app. It’s easy. Choose the bike you want and select a colour. Then, see how it looks sat in your garage through the AR feature. There’s an Integrated Accessories Catalogue, so you can add the parts you want. And the Honda Motorcycles Europe YouTube channel is now part of the app, with a gallery of videos to enjoy.





2022 Honda Rebel 500 ABS SE Totalmotorcycle.com Features and Benefits

CHASSIS / SUSPENSION

  • Both models’ riding positions are relaxed and neutral, with arms gently outstretched and feet dropping straight down to the mid-mounted pegs.
  • Good ground clearances allow sporty lean angles.
  • LED headlight, turn signals and taillight reinforce iconic look.
  • LCD meter with gear-position indicator and fuel consumption provides pertinent information to the rider.
  • To support the Rebel’s low-slung look, its attractive tubular-steel frame holds the engine in three places and is designed to be as narrow as possible around the rider’s inseam. Trail is set at 110 mm, with 28° rake.
  • The 41 mm fork stanchions are set wide at 230 mm apart, for rigidity, comfort and style, and the lower legs are blacked-out.
  • Fork features buffing on inner pipe for smooth action.
  • Fork angle is 30°, wheelbase is 58.7 in. wheelbase and seat height is 27.2 in., resulting in balanced, neutral steering.
  • Shock damper tube uses nitrogen gas to stabilize damping force.
  • Frame body has a narrow shape and includes an innovative rear loop that separates the seat from the stamped-metal rear fender.
  • Dunlop tires (size 130/90-16 front, 150/80-16 rear) are mounted to 16 inch cast-aluminum wheels.
  • Both the Rebel 500 and Rebel 300 are available in standard and ABS versions.
  • Iconic, peanut-shaped fuel tank, aggressively raked front end and fat tires on large-diameter wheels result in stripped forms that express offbeat individuality from every angle.
  • Blacked-out 45 mm tubular swingarm with twin conventional, side-mounted dual shocks that feature two-step preload adjusters.
  • Ignition is housed below the left side of the fuel tank.

ENGINE / DRIVETRAIN

  • Assist/slipper clutch results in reduced effort in stop-and-go situations and enhances controlled deceleration.
  • Rebel 500 is powered by a 471cc, eight-valve, liquid-cooled parallel-twin engine with strong bottom-end torque and a smooth, linear power delivery.
  • Rebel 500 cylinder head uses roller rocker arms; shim-type valve adjustment allows them to be light, for lower valve-spring load and reduced friction.
  • Rebel 500 has a silent (SV Chain) cam chain, with the surface of its pins treated with Vanadium to reduce friction through its increased protection against dust. Inlet-valve diameter is 26.0 mm with exhaust-valve diameter of 21.5 mm.
  • Rebel 500 has reduced friction through the inclusion of striations on the piston skirt (a finish that increases surface area, introducing gaps in which oil can flow for better lubrication). An AB 1 salt bath process, used after isonite nitriding, forms a protective oxidization membrane.
  • Rebel 500 crankshaft pins are phased at 180°, and a primary couple-balancer sits behind the cylinders, close to the bike’s center of gravity. The primary and balancer gears use scissor gears, reducing noise. The crank counterweight is specifically shaped for couple-balance and its light weight allows the engine to spin freely, with low inertia.
  • Rebel 500 crankcases use centrifugally cast thin-walled sleeves. Their internal design reduces the “pumping” losses that can occur with a 180° phased firing order. A deep oil sump holds 3.2 liters.
  • Rebel 300 is powered by a peppy 286cc single-cylinder engine.
  • Six-speed gearbox is designed to offer smooth gear changes.
  • Blacked-out mechanical components for a tough, minimalist look.
  • Specially designed muffler looks good and emits a pulsating exhaust note.

Honda Accessories

A full range of official Honda Accessories are available for the Rebel 500 and Rebel 300 and help create their own custom look. Available accessories include a stylish main seat, headlight cowl, meter visor, fork cover, and new saddlebag that can be removed without the use of tools and comes with shoulder straps for easy use when you leave the bike.

WARRANTY: Because we are so confident in the quality of each of our Honda Accessories, we are pleased to offer one of the best warranties in the industry. One-year warranty begins on the day accessories are purchased by the customer.

  • Meets current EPA and CARB standards
  • California version differs slightly due to emissions equipment







2022 Honda Rebel 500 ABS SE – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: from $6899 USD
Canada MSRP Price: $ NA CDN
Europe/UK MSRP Price: £6249 GBP (On The Road inc 20% Vat)

ENGINE
Engine Type 471cc liquid-cooled single-cylinder four-stroke
Bore And Stroke 67mm x 66.8mm
Induction PGM-FI
Ignition Full transistorized ignition
Compression Ratio 10.7:1
Valve Train DOHC; 4 valves per cylinder
DRIVE TRAIN
Transmission Six-Speed
Final Drive O-ring-sealed chain
CHASSIS SUSPENSION BRAKES
Front Suspension 41mm fork; 4.8 inches of travel
Rear Suspension Dual shocks with 3.8 inches of travel
Front Brake Hydraulic disc; ABS
Rear Brake Hydraulic disc; ABS
Front Tire 130/90-16
Rear Tire 150/80-16
DIMENSIONS
Rake (Caster Angle) 28° 0′
Trail 4.3 inches
Wheelbase 58.7 inches
Seat Height 27.2 inches
Curb Weight
414 pounds (Includes all standard equipment, required fluids and a full tank of fuelready to ride)
Fuel Capacity 2.9 gallons
Miles Per Gallon
67 MPG – Honda fuel economy estimates are based on EPA exhaust emission
measurement test procedures and are intended for comparison purposes only. Your
actual mileage will vary depending on how you ride, how you maintain your vehicle,
weather, road conditions, tire pressure, installation of accessories, cargo, rider and
passenger weight, and other factors.
OTHER
Model ID CMX500A2
Emissions Meets current EPA standards. California version meets current CARB standards and
may differ slightly due to emissions equipment.
Available Colors Matte Silver
FACTORY WARRANTY INFORMATION
One Year Transferable, unlimited-mileage limited warranty
Optional Extended Extended coverage available with a HondaCare Protection Plan®



2022 Honda Rebel 500 ABS SE – Totalmotorcycle.com Canada Specifications/Technical Details

NA







2022 Honda Rebel 500 ABS SE – Totalmotorcycle.com European Specifications/Technical Details

Engine

Bore × Stroke (mm) 67 x 66.8
Carburation PGM-FI
Compression Ratio 10.7:1
Engine Displacement (cc) 471cc
Engine Type Liquid-cooled, DOHC
Max. Power Output 34.0kW/8,500rpm
Max. Torque 43.3Nm/6,000rpm
Starter Electric
C02 Emissions (g/km) 86
Oil Capacity (Litres) 3.2 litres
Wheels

Suspension Front 41mm Telescopic forks
Suspension Rear Showa with pro-link system
Tyre Size Front 130/90-16M/C 67H
Tyre Size Rear 150/80-16M/C 71H
Wheels Front 16M/C x MT3.00
Wheels Rear 16M/C x MT3.00
Dimensions and Weights

Battery Capacity (VAh) 12V
Caster Angle 28°
Dimensions (L×W×H) (mm) 2,188 x 820 x 1,094
Fuel Tank Capacity (Litres) 11.2
Fuel Consumption 26km/litre
Ground Clearance (mm) 136mm
Kerb Weight (kg) 190kg
Seat Height (mm) 690mm
Trail (mm) 110
Wheelbase (mm) 1488mm
Transmission

Clutch Wet multiplate Hydraulic
Final Drive Chain
Transmission Type 6-speed
Instruments and Electrics

Headlights Bulb 55W
Instruments Digital
Tail Light Bulb 8.3W



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
