2023 Ducati TK-01RR: OFF-ROAD AT ITS BEST.

Introducing the new 2023 Ducati TK-01RR…

The TK-01RR is an e-enduro that adopts the most modern technical solutions, with the aim of making every riding phase exciting and letting you experience off-road at its best, even on the most inaccessible routes.

The Shimano EP8 engine with which it is equipped is pure performance, with a weight of 2.6 kg which makes it one of the lightest and most compact engines in the segment and a maximum torque of 85Nm with a maximum servo assistance ratio of 400%. The torque is always delivered with maximum fluidity. Combined with the Shimano Etube Project App, the EP8 system allows advanced degrees of customization, to adapt the character of the engine to your needs. In fact, the application allows you to vary maximum torque, acceleration and assistance timing in real time, even using the smartphone wirelessly.

The aluminium frame of the TK-01 RR features a verticalized downtube that houses an integrated 630 Wh Shimano battery, thus ensuring good autonomy without sacrificing the handling given by a low centre of gravity. The geometries of the TK-01RR are geared towards more extreme e-enduro use, with a 64.5° head angle, an elongated top tube and a 75.5° verticalized seat tube. The standard 1.8″ tapered head tube provides solid stiffness in the steering area, particularly important for tackling the most difficult passages at high speeds.

The TK-01RR is fitted with high-end components, such as a 12-speed transmission and Shimano XT brakes. This four-piston system, in combination with the 203 mm discs with “Ice technologies” cooling function, always guarantees powerful and modular braking. The 180mm Öhlins RXF 38 fork is muscular and ensures steering precision and a wide range of customization options. In addition, the 170 mm rear suspension with fully adjustable
Öhlins TTX shock absorber offers excellent descent progressivity without compromising riding, allowing the TK01RR to tame any bumpy surface.

The new TK-01RR is an e-enduro that adopts the most modern technical solutions, with the aim of making every riding phase exciting and letting you experience off-road in its maximum expression, even on the most inaccessible routes





2023 Ducati TK-01RR Totalmotorcycle.com Key Features

Off road. At top speeds.
The TK-01RR is pure adrenaline. An E-Enduro model geared toward hardcore off-road riding, equipped with the Shimano EP8 motor with 85Nm of torque. Every element, from geometries to high-end components such as the 12-speed drivetrain and 4-piston Shimano XT brakes, 180mm Öhlins RXF38 fork and Öhlins TTX shock absorber, is geared to enhance performance in every situation, especially when the trails get tougher and more technical.

Also available in a Limited Edition version, an exclusive and sought-after model, produced in a limited number of units, which incorporates the main features of the TK-01RR and even more advanced components to enhance downhill performance, such as the Öhlins DH38 double-plate fork, a multiple Downhill MTB World Cup winner.

The TK-01RR is the top of the range Ducati E-MTB, an E-Enduro bike with components and technical solutions for even more extreme enduro riding.

E-bike model range
Our e-bikes are developed in partnership with THOK E-Bikes and are known for their innovative geometric solutions, advanced technology and Italian design. Choose your e-bike.

Ducati E-Bikes today reach the highest performance on every route and testify to the goal of offering unique and meaningful experiences. A journey that began together with partner Thok E-Bikes in 2019 and which in 2023 will further enrich the range of models available.









2023 Ducati TK-01RR Totalmotorcycle.com Features and Benefits

Shimano EP8 engine
A benchmark in the category thanks to its low weight of 2.6 kg, compact size and a Q factor of only 177 mm. With a maximum torque of 85 Nm and an assistance ratio of up to 400%, this drive unit ensures great pedalling power with always fluid, direct and natural delivery, for complete control of the vehicle. Combined with the Shimano E-tube Project App, the EP8 system allows advanced levels of customization to adapt the character of the engine to your needs. All our e-mtb come with two pre-set profiles: “long ride” to favour long distances and “fast ride” for greater engine responsiveness.

Aluminium frame
With hydroformed, forged and CNC machined parts, this frame features “enduro oriented” geometries characterized by a 75.5° seat tube and 64.5° head angle, which allow you to overcome any obstacle. The new standard 1.8″ tapered head tube gives a unique design and greater stiffness in the steering area, to tackle the most gruelling stretches at top speeds. The lowered 783mm standover and the verticalized down tube that houses the 630Wh battery, ensure excellent handling guaranteed by a low centre of gravity.

Öhlins suspension
Simply the best available on the market, the result of all Öhlins’ experience in racing. Öhlins RXF38 air fork, with 38mm stanchions and 180mm travel. The fork’s recalibrated dual-piston, three-chamber air spring system allows for quick, easy and complete adjustment. Öhlins TTX air custom tuned Ducati shock absorber, 170 mm travel with Horst quadrilateral TPS (Thok progressive system) linkage. Fork and shock absorber are adjustable in compression at high and low speeds.

630Wh battery
Thanks to a lowered 783mm standover and the verticalized down tube, the Shimano battery is integrated into the frame in such a way as to ensure great autonomy without sacrificing the handling given by a low centre of gravity.

Main components
Maximum performance and reliability in all conditions thanks to high-end components such as the KS dropper post with remote control, the Shimano XT 12-speed 10-51T rear derailleur transmission, the 4-piston Shimano XT brake system in combination with Shimano 203mm discs with “Ice technologies” system. The special Renthal carbon handlebar reduces vibrations offering an extra degree of comfort.

Tyres and rims
Crankbrothers Synthesis aluminium rims in different sizes (29″ x 31 mm front, 27.5″ x 35 mm rear) with Pirelli Scorpion Enduro S 29″ x 2.6 SmartGrip Hyperwall tyres at the front and Pirelli Scorpion E-MTB S 27.5″ x 2.6 at the rear. The differentiated wheel size allows you to overcome the most difficult obstacles with momentum and maximum rear traction.









2023 Ducati TK-01RR – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8295 USD
Canada MSRP Price: $10995 CDN
Europe/UK MSRP Price: £7490 GBP (On The Road inc 20% Vat)

FRAME
THOK 6061 T4 T6 Aluminum, Forged and CNC machined, headtube tapared 1.8, 29″/27,5″ geometry, integrated down tube battery, enclosed internal cable, fully sealed cartridge bearing , 170 mm travel
ENGINE
SHIMANO – EP8 (250W – 85Nm)
BATTERY
SHIMANO 630 Wh with on/off Easy Touch
SUSPENSIONS
Front fork: Öhlins – RXF38 Air TTX18, Boost – 29″, 15 x 110 mm, Offset 44, 38 mm chassis, 180 mm of travel, compression and rebound adjust Rear shock: Öhlins – TTX Air, metric 230 x 65 mm – custom tuned Ducati
REAR SUSPENSION LAYOUT
TPS Thok Progressive System (Horst Link)
BRAKE
SHIMANO – Deore XT 4 pistons caliper with Ice Technologies rotor ( increased performances) 203 mm diameter front and rear. Mineral oil.
WHEELS
Front: CRANKBROTHERS – Synthesis – Alloy 29″ x 31 mm Rear: CRANKBROTHERS – Synthesis – Alloy 27,5″ x 35 mm
TIRES
Front: PIRELLI – Scorpion E-MTB S , TR, SmartGrip, HyperWall 29″ x 2.6 Rear: PIRELLi – Scorpion E-MTB S , TR, SmartGrip, HyperWall, 27,5″ x 2.6
POST SEAT
KS – dropper post micro height adjustable, remote control (S:125 mm – M/150 L/XL:170 mm)
HANDLEBAR
RENTHAL . Carbon 35 mm, rise 20 mm , 800 mm width
WEIGHT
N/A
DISPLAY
SHIMANO – Display SC-E7000 LCD display with remote control E7000





2023 Ducati TK-01RR – Totalmotorcycle.com Canada Specifications/Technical Details

FRAME
THOK 6061 T4 T6 Aluminum, Forged and CNC machined, headtube tapared 1.8, 29″/27,5″ geometry, integrated down tube battery, enclosed internal cable, fully sealed cartridge bearing , 170 mm travel
ENGINE
SHIMANO – EP8 (250W – 85Nm)
BATTERY
SHIMANO 630 Wh with on/off Easy Touch
SUSPENSIONS
Front fork: Öhlins – RXF38 Air TTX18, Boost – 29″, 15 x 110 mm, Offset 44, 38 mm chassis, 180 mm of travel, compression and rebound adjust Rear shock: Öhlins – TTX Air, metric 230 x 65 mm – custom tuned Ducati
REAR SUSPENSION LAYOUT
TPS Thok Progressive System (Horst Link)
BRAKE
SHIMANO – Deore XT 4 pistons caliper with Ice Technologies rotor ( increased performances) 203 mm diameter front and rear. Mineral oil.
WHEELS
Front: CRANKBROTHERS – Synthesis – Alloy 29″ x 31 mm Rear: CRANKBROTHERS – Synthesis – Alloy 27,5″ x 35 mm
TIRES
Front: PIRELLI – Scorpion E-MTB S , TR, SmartGrip, HyperWall 29″ x 2.6 Rear: PIRELLi – Scorpion E-MTB S , TR, SmartGrip, HyperWall, 27,5″ x 2.6
POST SEAT
KS – dropper post micro height adjustable, remote control (S:125 mm – M/150 L/XL:170 mm)
HANDLEBAR
RENTHAL . Carbon 35 mm, rise 20 mm , 800 mm width
WEIGHT
N/A
DISPLAY
SHIMANO – Display SC-E7000 LCD display with remote control E7000





2023 Ducati TK-01RR – Totalmotorcycle.com European Specifications/Technical Details

Frame
Thok 6061 aluminium forged and CNC machined, headtube tapared 1.8”
Battery
Shimano – 630 Wh (integrated)
Fork
Öhlins – RXF38 Air TTX18, Boost – 29″, 180 mm of tr avel, HS/LS compression and rebound adjust
Rear shock
Öhlins – TTX Air- 170 mm travel, custom tuned Ducati
Brakes
Shimano – Deore XT – 4 pistons caliper with “Ice Technologies” rotor 203 mm diameter
Crank
FSA – 165 mm with chainring 34T
Stem
Ducati – CNC Alloy 35 mm, 45 mm length
Handlebar
Renthal Carbon 35 mm, rise 20 mm, 800 mm width
Wheels
Crankbrothers – Synthesis – Alloy 29″ x 31 mm, 27.5″ x 35 mm
Tyres
Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6
Seatpost
KS – Dropper post micro height adjustable with remote control
Saddle
Ducati Fit – hollow Cr.Mo rail
Pedals
Alloy pedals
Display
Shimano – Display SC-EM800 LCD display with remote control
Rear derailleur
Shimano – Deore XT 12 S
Shift lever
Shimano – 12 SLX
Size
S – M – L – XL





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
