2023 KTM 1290 Super Duke RR Guide

2023 KTM 1290 Super Duke RR
ReviewKey FeaturesFeatures & BenefitsSpecifications

2023 KTM 1290 Super Duke RR 2023 KTM 1290 Super Duke RR 2023 KTM 1290 Super Duke RR 2023 KTM 1290 Super Duke RR 2023 KTM 1290 Super Duke RR

2023 KTM 1290 Super Duke RR: LIMITED NUMBERS, UNLIMITED FURY.

Introducing the 2023 KTM 1290 Super Duke RR…

Following the roaring success of the KTM 1290 SUPER DUKE RR in 2021, 500 units of the 2023 KTM 1290 SUPER DUKE RR will go into production, promising the same levels of ferocity but with a meaner, darker look.

The KTM 1290 SUPER DUKE RR will once again rip into the tarmac, leaving a deep, lasting impression as the ultimate numbers-limited Hyper Naked motorcycle in the KTM stable. The numbers tell the story – 1,301 cc, 180 hp, 180 kg, and 140 Nm, with a phenomenal 1:1 power-to-weight ratio, making it every bit as beastly as its predecessor, but with a darker shadow.

Sporting a gloss black and matt carbon base, contrasting white graphics, and striking orange accents, the 2023 KTM 1290 SUPER DUKE RR casts an ominous shadow with menacing intentions. This is further exaggerated with a collection of unique custom-made components, which are specific to the RR, adding more aggression and attitude.

With the KTM 1290 SUPER DUKE RR being 11 kg lighter than a standard KTM 1290 SUPER DUKE R EVO, it is equally at home decimating lap times as it is carving up mountain roads, providing riders with the ultimate Hyper Naked package.

However, it’s the KTM 1290 SUPER DUKE RR’s collection of WP Suspension’s finest components that take it from a backroad brawler to an accomplished track day terror. Upfront, a fully adjustable WP APEX PRO 7548 Close cartridge fork has been tailored specifically for the RR, while a custom-made WP APEX PRO 7746 Shock takes charge of the rear. The WP APEX PRO 7117 steering damper keeps things in check and offers 30 clicks to dial it into your specification.

Carbon fiber is used extensively, with the subframe also receiving the lightweight carbon treatment, creating a unique single-seat unit. The LED taillights are incorporated into LED turn signals, as well as KTM’s adaptive brake light as standard.

As an added extra to enforce the KTM 1290 SUPER DUKE RR exclusivity, owners will be presented with a bespoke carbon fiber box containing the keys to their new BEAST.

For the absolute power-hungry, a full system Akrapovič EVO line exhaust system is available as an optional extra, which adds even more bite to THE BEAST.

Sporting an all-new, darker look, the 2023 KTM 1290 SUPER DUKE RR once again emerges as the ultimate hyper-Naked machine on the planet. Weighing in at a massive 9 kilograms lighter than the standard KTM 1290 SUPER DUKE, and boasting a 1:1 power-to-weight ratio, the KTM 1290 SUPER DUKE RR tears into the tarmac with unmatched aggression. Welcome to the ultimate BEAST.





2023 KTM 1290 Super Duke RR Totalmotorcycle.com Key Features

  • 1:1 power-to-weight ratio
  • WP APEX PRO COMPONENTS Suspension
  • Akrapovič Slip-on exhaust
  • Exclusive carbon fiber bodywork
  • Lightweight lithium ion battery
  • Ultra-lightweight forged wheel
  • Carbon fiber subframe with a single seat
  • New, black CTG
  • Limited to only 500 units
  • Unique, branded carbon key box
  • Factory triple clamp
  • Adjustable CNC-machined rearset





2023 KTM 1290 Super Duke RR Totalmotorcycle.com Features and Benefits

Not only impressive when it comes to hardware, the KTM 1290 SUPER DUKE RR boasts the most complete track-orientated electronics pack ever seen on a KTM motorcycle – as standard, adding advanced TRACK and PERFORMANCE MODE. While the KTM 1290 SUPER DUKE RR already boasts a full range of exclusive components and bodywork, riders looking for more ferocity can browse a full range of specially developed KTM PowerParts, along with a dedicated range of KTM PowerWear. This includes a custom leather race suit, specifically completed with unique KTM 1290 SUPER DUKE RR branding and matching design.



SHHH, THE BEAST IS SLEEPING

Adjustability

The KTM 1290 SUPER DUKE RR boasts multi-adjustability. From its exceptional suspension, right down to the hand levers, almost all elements of this BEAST can be tailored to the rider’s liking. And if that’s not enough, you can make it even meaner with a dedicated selected of KTM POWERPARTS.

KTM RACE ON System

Ignition keys are old news. The KTM 1290 SUPER DUKE RR has a “keyless” transponder. No more forgetting your key in your pocket after you’ve put your gloves on. All you need is to have the key in close proximity to your bike, and you can start up, and hit the road.

Bodywork

The KTM 1290 SUPER DUKE RR has taken the Naked bike ethos and stripped it down even more. Even the thickness of the panels was carefully scrutinized to ensure optimal weight saving. But, these aren’t merely for saving weight – they add additional stiffness to the overall package and present a more muscular, imposing look.

CARBON CLAD

Carbon Fiber

In an unrelenting hunt to save grams, almost every single body panel is made from carbon fiber. From the rear carbon fiber undertray – that incorporates the license plate holder and taillight assembly – to the ultra-stiff and READY TO RACE carbon front fender, the KTM 1290 SUPER DUKE RR is serious when it comes to weight saving.

Graphics

You would be mistaken for thinking the 2023 KTM 1290 SUPER DUKE RR casts fear into its own shadow. Boasting a blend of gloss black, muted grey carbon, and striking orange tones, it stamps its own authority with an all-new signature look. And let’s not forget its RR credentials emblazoned across its flanks in white graphics.



IT’S AWAKE

Engine

Boasting 180 hp and 140 Nm, the 1,301 cc LC8, V-Twin, this beating heart of the BEAST deserves little introduction. However, due to the times, this engine is EURO5 homologated, but most importantly, and thanks to an overall weight reduction of 9 kg – the KTM 1290 SUPER DUKE RR has an incredible power to weight ratio of 1:1.

Exhaust

The KTM 1290 SUPER DUKE RR is fitted with an Akrapovic Slip-On as standard. And as you’d expect from the best in the business, the muffler outer sleeve is made of lightweight titanium, while the end cap is made of carbon fiber. But for those wanting a bit more bite, the optional AKRAPOVIC “EVOLUTION LINE” is a full-titanium, MotoGP™-derived masterpiece. But take heed – this is a racetrack only option and is not street-legal.

Air Intake

To perform like a BEAST, the KTM 1290 SUPER DUKE RR needs to breath like a BEAST. Thanks to a ram air intake positioned in headlight mask, this rip snorting arrangement maximizes air flow by forcing oxygen into the combustion chambers. This reduces the chance of low air pressure and increases the fuel burn rate for optimum performance.

LIGHTING UP THE DARKNESS

LED Lighting

The KTM 1290 SUPER DUKE RR features LED lighting at all ends. Upfront, LED daytime running lights provide a friendly warning to sportbikes, while the ultra-bright LED headlight burns a hole into any darkness ahead of you. Oh, and as a common courtesy, LED indicators let anyone brave enough to follow know which way you’ve gone.



TAMING THE BEAST

Ergonomics

The riding position of the KTM 1290 SUPER DUKE RR primarily aimed at performance riding. The tank has been angled slightly outwards, providing more support on the tank surface while braking and better contact with the bike when dragging elbows. This also means the handlebar is positioned lower for improved control without compromising comfort.

Seat

Track-slaying weaponry requires the appropriate seating. For that reason, the KTM 1290 SUPER DUKE RR has a dedicated seat, 10 mm taller than that of the standard KTM 1290 SUPER DUKE R. However, thanks to the rear shock adjustable length the seat height can drop down to 837 mm. Matching the seat height of the KTM 1290 SUPER DUKE R. The seat has been developed to provide riders with the absolute maximum grip, but still providing adequate movement and comfort. All of this is perfectly finished off with an “RR” logo.

Handlebar

Finding the optimal seating position is made easy with an adjustable 760 mm wide handlebar. Riders can tailor their preferred reach with 4 positions over 22 mm, front to back, making it easy to attack corners and crucial for hanging on down the straights.

Menu Switch

A great deal of testing was done to develop the robust and intuitive motorcycle switchgear on the KTM 1290 SUPER DUKE RR, which incidentally, pushes all the right buttons. Riders can now adjust the wheel slip easily via paddle buttons on the switchgear, while in TRACK or PERFORMANCE MODE, or can set two programmable switches for fast access to favored features or setting of their choosing.

Footpegs

Developed for track use and finished with carbon heel guards, these CNC-machined aluminum footpegs are adjustable to 12 different positions for any rider to find their perfect fit. They also allow for a higher lean angle and provide better foot grip than standard. What to switch things up and reverse your shifting pattern? No problem there either.

Rider Aids

Many traditionalists might frown at the sight of electronic rider aids, saying they interfere with the purity of the ride. However, when it comes to the KTM 1290 SUPER DUKE RR, all these electronic features are designed to enhance the riding experience, to be less intrusive, and ultimately, to help tame the BEAST.



REINING IT IN

Frame

The frame uses the engine to increase torsional rigidity, meaning the KTM 1290 SUPER DUKE RR is super stiff. This allows for an effortless, confidence-inspiring riding position, translating into a faster ride. This is achieved by maximizing the feedback from the chassis and the front tire. The frame also makes use of thick diameter tubes with thin walls for optimal stiffness and weight.

Suspension

Think of the suspension elements on the KTM 1290 SUPER DUKE RR as the muscles that work to get the power to the ground in best and most efficient way. Every component has been considered to improve the handling, adjustability, and performance of this track-shredding BEAST.

Fork

The KTM 1290 SUPER DUKE RR has taken things seriously upfront. Featuring WP APEX PRO 7548 Closed Cartridge forks, this is a different breed of BEAST. With improved performance and responsiveness of the front-end damping, and is made from high-quality CNC, lightweight materials, the WP APEX PRO 7548 guarantees the best performance for race-oriented motorcyclists and professional racers.

Rear Shock

Taking charge of the rear, the KTM 1290 SUPER DUKE RR employs the use of a WP APEX PRO 7746 Shock, which has been custom-made according to the unique specifications of the KTM 1290 SUPER DUKE RR. Developed in close co-operation with current World Championship and factory riders, the WP APEX PRO 7746 Shock delivers unparalleled performance on track and street thanks to the new SCS Big Valve Technology. The WP APEX PRO 7746 Shock allows for high and low speed compression as well as rebound and pre-load adjustment and even allows the pilot to adjust the shock length from 353 mm to 360 mm.

Wheels and Tires

Getting all that pent-up anger to the asphalt comes courtesy of 7-spoke ultra-lightweight forged wheels mated to Michelin Power Cup2 tires. Sharing the same design standards as those found on the KTM RC 16, these wheels tip the scales at a full 1,5 kgs less than the standard KTM 1290 SUPER DUKE R wheels. This means less unsprung mass, better braking performance, acceleration, and lightning-fast response when flicking through the bends. Meanwhile, the track-ready rubber warms up remarkably quickly due to its unique dual-compound architecture. The front tire size is 120/70 ZR17, and the rear is a massive 200/55/ZR17.

Steering Dampener

A race-derived WP APEX PRO 7117 steering damper has been fitted to the KTM 1290 SUPER DUKE RR, which is identical to that used by the WP racing teams. The WP APEX PRO 7117 allows riders to adjust the damping up to 30 clicks, helping them find the perfect setting for any condition.

STOPPING POWER

Brakes

Reining this BEAST comes courtesy of 4-piston BREMBO Stylema monobloc calipers clamping onto 320 mm floating discs up front, and a twin-piston floating caliper biting a 240 mm disc at the rear. Oh, and don’t forget about the just-as-potent ABS technology mated to the braking system.







2023 KTM 1290 Super Duke RR – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $ NA USD
Canada MSRP Price: $ NA CDN
Europe/UK MSRP Price: £ See Dealer (On The Road inc 20% Vat)

Engine
Torque 140Nm
Transmission 6-speed
Cooling Liquid cooled
Power in KW 132kW
Starter Electric starter
Stroke 71mm
Bore 108mm
Clutch PASC™ antihopping clutch, mechanically operated
Displacement 1301cm³
EMS Keihin EMS with RBW and cruise control, double ignition
Lubrication Forced oil lubrication with 3 oil pumps



Chassis
Tank capacity (approx.) 16l
ABS Bosch 9.1MP 2.0 (with cornering ABS and SUPERMOTO ABS)
Front brake disc diameter 320mm
Rear brake disc diameter 240mm
Front brake 2 x Brembo Stylema Monobloc four piston, radially mounted caliper
Rear brake Brembo twin-piston fixed calliper, brake disc
Chain 525 X-Ring
dry weight 189kg
Frame design Chrome-moly tubular space frame, powder-coated
Front suspension WP APEX PRO 7548 Closed Cartridge
Rear suspension WPAPEXPRO7746
Steering head angle 65.6°
Suspension travel (front) 130mm
Suspension travel (rear) 140mm



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
