2023 Yamaha PW50: THE PERFECT FIRST STEP.
Introducing the new 2023 Yamaha PW50…
A fully automatic transmission and adjustable throttle control expands thrills along with skills. The world‑renowned PW50 ensures fun‑filled first ride experiences.
For over 40 years the PW50 mini motorcycle has introduced children and their parents to the joy and excitement that comes with riding off-road. And along the way this little Yamaha has helped to make some fantastic family memories that will last a lifetime – making the PW50 so much more than a kids’ fun bike.
The perfect first step.
Everything about the legendary PW50 is designed to make riding easy and enjoyable. There’s a throttle limiter that lets you adjust the top speed, and the compact chassis with plush suspension and low seat height ensure a comfortable ride with lightweight handling.
The zippy, fully-automatic 50cc engine delivers smooth acceleration – and the shaft drive and separate 2-stroke oil tank make maintenance simple. Designed to fit into the back of car or small van, the compact and lightweight PW50 is easy to transport. And with its Yamaha build quality this premium kids’ bike will give years of family fun!
Perfect for new riders.
They’re young only once, so you naturally want the very best for your child. And when you take a closer look at the Yamaha PW50 you’ll see that this high quality mini motorcycle comes with plenty of user-friendly features and uncomplicated technology, that make it the favourite choice of many parents all around the world.
Simplicity is the key, and everything about the PW50 is designed to make it fun to ride and easy to own. The 2- stroke 50cc engine features fully-automatic transmission for “twist-and-go” performance, and the handlebar-mounted brake levers – as well as a shaft drive and a low seat – make it the ideal rst bike for every child.
With many kids spending a lot of time playing inside on electronic devices, the Yamaha PW50 is the ideal way to encourage them to get involved in a physical outdoor activity and to build skills and con dence. Brothers and sisters can all share the PW50 through the years, and create numerous fun family memories.
2023 Yamaha PW50 Totalmotorcycle.com Key Features
- Fully Automatic Transmission
Fully automatic transmission means no shifting required. The PW50 is a twist-and-go package. - Entry-Level Two-Stroke Engine
Gutsy 49cc two-stroke is built to thrill without intimidating beginners. - Ultra-Low Seat Height
A seat only 18.7 inches high makes the PW50 the ideal choice for even the littlest riders in the group. - Adjustable Restrictor
An adjustable throttle stop screw keeps the adult in charge to gradually increase speed as skills improve. - Low Maintenance Requirements
Shaft final drive means no chain maintenance, while Yamaha’s exclusive autolube oil injection system eliminates the need for fuel/oil premixing. - Fully-automatic 50cc 2-stroke engine
- Easy-to-adjust throttle limiter
- Low seat height and user-friendly controls
- Lightweight handling and compact dimensions
- Easy to own, simple to maintain
- Separate 2-stroke oil tank
- Strong, 3-spoke, 10 inch steel wheels
- Light and strong motocross-style bodywork
- Yamaha design, quality and reliability
- High-level exhaust with heat shield
2023 Yamaha PW50 Totalmotorcycle.com Features and Benefits
ENGINE
- Entry-Level Two-Stroke Engine
The 49cc air-cooled, case-reed-inducted, two-stroke single is tuned to deliver predictable power that gently eases the new rider up the off-road learning curve. - Fully Automatic Transmission
Single-speed automatic transmission allows the rider to simply twist the throttle and go, allowing him/her to concentrate on the ride ahead. - Maintenance-Free Shaft Drive
The class-exclusive shaft drive system is virtually maintenance free and comes fully enclosed for added durability. - Convenient Oil Injection System
Exclusive autolube oil injection system eliminates the need for fuel/oil premixing.
CHASSIS/SUSPENSION
- Ultra-Low Seat Height
Low 18.7-inch seat height allows most kids to put both feet down for added confidence. - Robust Front Suspension
A large 26mm telescopic front fork with 2.4 inches of travel smooths out the bumps for responsive handling. - Dual Shocks
Dual rear shocks with 2 inches of travel smooth the trail to deliver confidence-inspiring ride quality. - Maintenance-Free Mag Wheels
Mag-style wheels mean there’s no need to tighten or replace spokes. - Enclosed Drum Brakes
Front and rear drum brakes provide smooth, predictable stopping power. - Durable Knobby Tires
Durable 10-inch front and rear knobby tires provide excellent traction and superior wear. - Quiet, Compact Exhaust
A quiet exhaust pipe, complete with a removable baffle, is routed away from the rider. - Simplified Servicing
The rear fender, seat and side panel unit remove quickly for easy maintenance.
ADDITIONAL FEATURES
- Comfortable Saddle
A thick seat enhances rider comfort. - Racy Styling
Team Yamaha-inspired colors, graphics and front and side number plates create styling just like the bigger off-roaders. - Grippy Foot Pegs
Large, folding foot pegs with rubber grips provide excellent footing.
2023 Yamaha PW50 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $1699 USD
Canada MSRP Price: $ CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Engine Type 49cc air-cooled 2-stroke; reed-valve induction
Bore x Stroke 40.0mm x 39.2mm
Compression Ratio 6.0:1
Fuel Delivery VM12 carburetor
Ignition CDI
Transmission Wet centrifugal automatic
Final Drive Shaft
Suspension / Front 26mm telescopic fork; 2.4-in travel
Suspension / Rear Unit swingarm; 2.0-in travel
Brakes / Front Drum
Brakes / Rear Drum
Tires / Front 2.50-10-4PR
Tires / Rear 2.50-10-4PR
L x W x H 49.0 in x 24.0 in x 27.8 in
Seat Height 18.7 in
Wheelbase 33.7 in
Rake (Caster Angle) 25.5°
Trail 2.0 in
Maximum Ground
Clearance
3.7 in
Fuel Capacity 0.5 gal
Wet Weight 90 lb
Warranty 90 Day (Limited Factory Warranty)
Color Team Yamaha Blue
2023 Yamaha PW50 – Totalmotorcycle.com Canada Specifications/Technical Details
2023 Yamaha PW50 – Totalmotorcycle.com European Specifications/Technical Details
Engine
Engine type Reed valve;Single cylinder;Air-cooled;2-stroke
Displacement 49cc
Bore x stroke 40.0 mm x 39.2 mm
Compression ratio 6.0 : 1
Maximum power –
Maximum torque –
Lubrication system Separate lubrication
Clutch type Wet;centrifugal automatic
Ignition system CDI
Starter system Kick
Transmission system automatic
Final transmission Shaft
Fuel system Mikuni VM12/1
Chassis
Frame Steel tube backbone
Caster angle 25°30′
Trail 50 mm
Front suspension system Telescopic forks
Rear suspension system Unit Swing
Front travel 60 mm
Rear travel 50 mm
Front brake Drum mm
Rear brake Drum mm
Front tyre 2.50-10 4PR
Rear tyre 2.50-10 4PR
Dimensions
Overall length 1,245 mm
Overall width 610 mm
Overall height 705 mm
Seat height 475 mm
Wheel base 855 mm
Minimum ground clearance 95 mm
Wet weight (including full oil and fuel tank) 41 kg
Fuel tank capacity 2.0 litres
Oil tank capacity 0.30 litres
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
