2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition Guide

2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition

2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition 2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition 2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition 2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition

2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition: RIDE LIKE THE REIGNING CHAMP.

Introducing the new 2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition…

Get the look & feel of a Yamaha factory ride with your own Monster Energy‑inspired, all‑new YZ450F.

YZ450F Monster Energy Yamaha Racing Edition
From MXGP to US Supercross and Motocross Yamaha Official riders give 100% every race, pushing the limits. So if you’re searching for the ultimate factory style race bike you need to take a look at the YZ450F Monster Energy Racing Edition.

Ride like the reigning champ.
Built on its best-in-class power delivery and suspension performance, the all-new 2023 YZ450F boasts even more power, better handling, less weight, a new more narrow body with improved ergonomics and next-generation Power Tuner app—all while maintaining its renowned ease-of-use that makes fast riders even faster. This has got to be one of the best-looking production motocross bikes we’ve ever built.

A new lightweight aluminium frame and updated KYB suspension deliver the cornering precision and straight-line stability you need stay ahead – and the compact new seamless bodywork combined with revised ergonomics give the ultimate rider mobility for maximum control when accelerating, braking and cornering.

Lighter, more compact with increased power across the entire rev range, the all-new 450cc engine maintains the YZ450F’s exceptional pulling power and renowned ease-of-use, all while boosting the rev limit by 500 rpm for even more top-end power. With exclusive black bodywork and factory style graphics the YZ450F Monster Energy Racing Edition is the ultimate motocross bike.







2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition Totalmotorcycle.com Key Features
  • Monster Energy Yamaha Racing Edition bodywork
  • Reduced weight and increased durability
  • Lighter, slimmer and more powerful engine
  • Increased air intake capacity
  • New disc spring clutch
  • Newly designed transmission
  • Redesigned aluminium bilateral beam frame
  • Seamless ergonomic bodywork
  • Updated KYB suspension
  • Adjustable traction control system
  • Refined launch control system
  • Extensively revised Power Tuner app
  • Revised rider triangle
  • Monster Energy® Yamaha Racing Edition
    Inspired by the reigning Motocross & Supercross champion YZ450F raced by the Monster Energy® Star Yamaha Racing team, the Monster Energy® Yamaha Racing Edition features a striking color and graphics package that stands out at the track or on the trail.
  • New 450cc Four-Stroke Engine
    The completely redesigned 450cc liquid-cooled DOHC four-stroke engine is lighter, more compact and features stronger pulling power across the entire rev range. The rev limit is also increased by 500 rpm for longer over-rev while still maintaining the YZ450F’s broad power character.
  • New Yamaha Power Tuner App
    Yamaha’s industry-leading Power Tuner App has been extensively updated, retaining the full functionality of the previous version but now even easier to understand, easier to use, with more functionality. Engine mapping can now be made using an intuitive new slide bar. There is also a new lap timer, Traction and Launch Control tuning, and bike set-up guides. Best of all, it’s free-of-charge.
  • New Traction Control & Updated Launch Control
    The all-new Traction Control System communicates wheel slip to the ECU, tuning the engine to maintain ideal rear wheel traction. Three levels can be selected: HIGH, LOW or OFF. The updated Launch Control System now features an rpm limiter which can be adjusted in 500 rpm increments between 6,000 rpm and 11,000 rpm for optimized launches when the gate drops. Both systems are controlled through the Yamaha Power Tuner App.
  • All-New Aluminum Bilateral Beam Frame
    A completely redesigned aluminum bilateral beam frame provides just the right amount of strength and flex for the perfect balance of stability and cornering performance. The result is a better handling machine with lighter feel, more agility and increased traction allowing the rider to enter corners with greater confidence and more line choices.
  • Class-Leading Suspension
    High-spec fully adjustable Speed Sensitive System KYB® coil spring-type fork provides exceptional bump absorption. New for 2023, the front fork now features toolless compression clickers for easy adjustment. The linkage-type rear suspension features a KYB® shock with revised damping characteristics to match the new YZ450F’s chassis.
  • High Performance Braking System
    A large 270mm front brake rotor is coupled with a Nissin caliper to provide excellent braking performance. Out back, rear brake feel is improved by reducing the rigidity of the brake hose providing a wider range of control at the pedal.
  • Slimmer Body & Improved Ergos
    A new slimmer, flatter and more compact body eases rider movement for improved control, including more seamless, rounded features from seat edges and side covers to a more narrow fuel tank and front shroud. The rider triangle is also improved with increased legroom between the seat and footpegs, and revised handlebar position for a more natural posture and enhanced rider comfort.





Yamaha Announces New 2023 Off-Road YZ Lineup
Including the Lighter, Slimmer, Faster & More Fun All-New YZ450F

MARIETTA, Ga. – August 10, 2022 – Yamaha Motor Corporation, USA, is excited to introduce the new 2023 lineup of advanced, industry-leading YZ off-road motorcycles. Conceived for competition and extensively developed through knowledge gained at the highest levels of professional motorsports, the 2023 lineup of Yamaha YZ Motocross and Cross Country machines offer cutting-edge performance along with a level of refinement and rideability that instills confidence in every rider. Highlights for 2023 include an all-new flagship YZ450F Motocross model, along with an all-new YZ125X and extensively updated YZ250X two-stroke Cross Country models.

Fresh off back-to-back professional Motocross and Supercross titles, Yamaha introduces an all-new YZ450F for 2023 designed to push capabilities even further. Building on the class-leading power delivery, suspension performance and usability of the previous model, the new YZ450F raises the bar with more power, less weight, a slimmer design and improved handling in an even more usable package. The new 2023 YZ125X offers a completely new, more powerful 125cc two-stroke engine, revised suspension damping, improved brakes, enhanced ergonomics and a sharp new look making it the perfect option for young enthusiasts looking to move up to a full-size competition-ready two-stroke cross country bike. For riders looking for big 250cc two-stroke power in the ultimate cross country racer, the new 2023 YZ250X is now better than ever with updated brakes, revised suspension, race-inspired ergonomics and aggressive new styling. Continuing across the entire 2023 range of Yamaha YZ models, a superior level of off-road performance and unmatched reliability remain a constant.

“What really stands out about the new YZ450F is just how light and balanced it feels when riding hard,” said Derek Brooks, Yamaha Motorsports Motorcycle Product Line Manager. “This new platform builds on the legendary YZ suspension and handling with an even more powerful, yet controllable engine character that will offer expert riders everything they need to compete and win at the highest level. At the same time its revised ergonomics and tuneability with the free engine mapping Power Tuner makes it easier to ride fast for all rider skill levels. I’m pumped to see it hit the tracks soon!”

Welcome to the victorYZone
Yamaha’s off-road competition bikes offer the very latest in technology with performance features designed to help racing enthusiasts reach their maximum potential, win races and stand on top of the podium.









2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition Totalmotorcycle.com Features and Benefits

ENGINE

  • All-New 450cc Four-Stroke Engine
    The new 2023 YZ450F’s engine has been completely redesigned, now with a 500 rpm higher rev limit. Among the changes are new exhaust and intake port shapes, larger diameter titanium intake valves, new piston, cylinder, crankshaft and balancer assembly, and a switch from wet sump to dry sump lubrication. The combined effect of these features is more power across the entire rev range in a lighter, more compact engine.
  • New Yamaha Power Tuner App
    The free-of-charge Yamaha Power Tuner App brings the power of the GYTR® Power Tuner to your iOS® or Android® device. Using wireless connectivity to talk to the bike’s onboard CAN-bus network, the app allows owners to adjust air/fuel mixture and ignition timing to tune engine performance for track conditions, record race log information and monitor a range of data such as maintenance and system diagnosis, engine run time and more. New for 2023, the app has been revised to be more user-friendly. New features include an intuitive “Simple Tuning” slide bar for engine mapping, Traction and Launch Control tuning, lap timer, along with engine and suspension tuning guides. Additionally, new lightweight handlebar-mounted switchgear allows on-the-fly selection of preloaded engine maps.
  • New Traction Control & Updated Launch Control
    An all-new Traction Control System communicates wheel slip to the ECU, tuning the engine to maintain ideal rear wheel traction. Three levels can be selected: HIGH, LOW or OFF. The updated Launch Control System continues to implement traction control and now features an rpm limiting setting, which can be adjusted in 500 rpm increments between 6,000 rpm and 11,000 rpm. Both systems are controlled through the new Yamaha Power Tuner App.
  • Advanced Fuel Injection
    The engine breathes through a 44mm Mikuni® throttle body fed by a high-pressure electric pump to ensure optimum fuel atomization and power for a wide range of riding conditions. The ultra-compact throttle body also saves weight and improves mass-centralization.
  • New Compact Lightweight Clutch
    The all-new clutch design replaces the coil springs of the previous model with a new disc spring and integrates primary gear and basket into a single steel unit. The result is a more compact, lightweight and durable assembly which yields smoother engagement and excellent feel. A new clutch cover employs a stylish geometric design that helps minimize scratching and lends a premium look.
  • New Five-Speed Transmission
    All new tri-shaft transmission layout vertically stacks the transmission shafts, raising the center shaft and forming a triangle between the crank, drive shaft and main shaft for a lighter, more compact transmission.
  • New Air Intake
    Optimized intake path draws air from under the side covers and seat allowing for a lighter, slimmer and more compact shroud area. This redesign allows the airbox cover to be lower and more narrow and radiator shrouds to be slimmer.
  • Electric Starter System
    The YZ450F features a compact electric starter system to minimize restart delays on track and add convenience everywhere else. Powered by a high-capacity and ultra-lightweight four-cell lithium-ion battery, the system adds minimal weight.



CHASSIS/SUSPENSION

  • All-New Aluminum Bilateral Beam Frame
    Striking the perfect balance of precise cornering performance and handling stability, the completely redesigned aluminum bilateral beam frame consists of more than 10 different aluminum components welded together. This provides the opportunity to carefully tune rigidity and flex characteristics of each component to ensure competition-level performance. The result is a better handling machine with lighter feel, improved bump absorption and increased traction, allowing the rider to enter corners with greater confidence and more line choices.
  • Revised Class-Leading Suspension
    High-spec fully adjustable Speed Sensitive System KYB® coil spring-type fork provides exceptional bump absorption. The linkage-type rear suspension features a KYB® shock with damping characteristics to match the new YZ450F’s chassis. Newly revised internal valving works in combination with the new frame and body to improve traction and increase cornering performance. Additionally, the front fork now features a new hand operated compression damping adjuster for simple, toolless adjustments.
  • High Performance Braking System
    A large 270mm front brake rotor is coupled with a Nissin caliper to provide excellent braking performance. Out back, rear brake feel is improved by reducing the rigidity of the brake hose providing a wider range of control at the pedal.
  • Slimmer Body & Improved Ergos
    A new slimmer, flatter and more compact body eases rider movement for improved control, including more seamless, rounded features from seat edges and side covers to a more narrow fuel tank and front shroud. The rider triangle is also improved with increased legroom between the seat and footpegs, and revised handlebar position for a more natural posture and enhanced rider comfort.
  • Strong, Lightweight Wheels
    Careful computer-aided design of each wheel’s cross-sectional profile shaves weight without sacrificing durability. The YZ450F’s rear wheel comes laced with a three-cross-spoke pattern for improved impact absorption and rider feel.
  • Triple Clamp with Adjustable Handlebar Mounts
    The top triple clamp design balances rigidity for improved steering feel while the four-position adjustable handlebar clamp is rubber-mounted for comfort, reduced handlebar vibration and easily tunable bar position.



ADDITIONAL FEATURES

  • Race-Winning Details
    The YZ450F boasts a wide range of top-spec details including 1-1/8-inch aluminum tapered handlebars, new compact PVC handlebar pad, new lightweight throttle cable, wide footpegs with new lightweight aluminum alloy brackets, a quick-adjust clutch perch, stylish blue rims and a lightweight gold drive chain with new YZ450F-specific chain guide.



NEW FOR 2023

  • The Ultimate Open Class YZ
    The reigning pro Motocross & Supercross champ now raises the bar even higher. Building on its best-in-class power delivery and suspension performance, the all-new 2023 YZ450F boasts even more power, better handling, less weight, a new more narrow body with improved ergonomics, next-generation Power Tuner app and sharp new YZ styling adorned in the exclusive Monster Energy® Yamaha Racing Edition color and graphics package—all while maintaining its renowned ease-of-use that makes fast riders even faster.
  • All-New 450cc Four-Stroke Engine
    Lighter, more compact with increased power across the entire rev range, the all-new 450cc engine maintains the YZ450F’s exceptional pulling power and renowned ease-of-use, all while boosting the rev limit by 500 rpm for even more top-end power.
  • All-New Aluminum Bilateral Beam Frame
    A completely redesigned aluminum bilateral beam frame provides just the right amount of strength and flex for the perfect balance of stability and cornering performance. The result is a better handling machine with lighter feel, more agility and increased traction allowing the rider to enter corners with greater confidence and more line choices.
  • New Yamaha Power Tuner App
    Like having factory team support in your pocket, Yamaha’s groundbreaking Power Tuner App is revised to be even more user-friendly. New features include an intuitive “Simple Tuning” slide bar for engine mapping, Traction and Launch Control tuning, lap timer, along with engine and suspension tuning guides.
  • New Traction Control & Updated Launch Control
    The all-new Traction Control System communicates wheel slip to the ECU, tuning the engine to maintain ideal rear wheel traction. Three levels can be selected: HIGH, LOW or OFF. The updated Launch Control System now features an rpm limiter which can be adjusted in 500 rpm increments between 6,000 rpm and 11,000 rpm for optimized launches when the gate drops. Both systems are controlled through the Yamaha Power Tuner App.
  • New Compact Lightweight Clutch
    The all-new clutch design replaces the coil springs of the previous model with a new disc spring and integrates primary gear and basket into a single steel unit. The result is a more compact, lightweight and durable assembly which yields smoother engagement and excellent feel. A new clutch cover employs a stylish geometric design that helps minimize scratching and lends a premium look.
  • New Five-Speed Transmission
    All new tri-shaft transmission layout vertically stacks the transmission shafts, raising the center shaft and forming a triangle between the crank, drive shaft and main shaft for a lighter, more compact transmission.
  • Slimmer Body & Improved Ergos
    A new slimmer, flatter and more compact body eases rider movement for improved control, including more seamless, rounded features from seat edges and side covers to a more narrow fuel tank and front shroud. The rider triangle is also improved with increased legroom between the seat and footpegs, and revised handlebar position for a more natural posture and enhanced rider comfort.
  • New Air Intake
    Optimized intake path draws air from under the side covers and seat allowing for a lighter, slimmer and more compact shroud area. This redesign allows the airbox cover to be lower and more narrow and radiator shrouds to be slimmer.
  • Updated Rear Brake
    Rear brake feel is improved by reducing the rigidity of the brake hose, providing a wider range of control at the pedal.
  • Revised Suspension with Toolless Fork Adjustment
    The YZ450F’s front fork now features a new hand operated compression clicker for simple, toolless adjustments. To match the new chassis, front fork and rear shock damping characteristics are tuned to optimize traction and bump absorption.







2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $10099 USD
Canada MSRP Price: $ NA CDN
Europe/UK MSRP Price: from £9000 GBP (On The Road inc 20% Vat)

Engine Type 450cc liquid-cooled DOHC 4-stroke; 4 titanium
valves
Bore x Stroke 97.0mm × 60.8mm
Compression Ratio 13.0:1
Fuel Delivery Mikuni® fuel injection, 44mm
Transmission 5-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front KYB® spring-type fork with speed sensitive
damping; fully adjustable, 12.2-in travel
Suspension / Rear KYB® single shock; fully adjustable, 12.4-in
travel
Brakes / Front Hydraulic disc, 270mm
Brakes / Rear Hydraulic disc, 240mm
Tires / Front 80/100-21 Dunlop® Geomax MX33F
Tires / Rear 120/80-19 Dunlop® Geomax MX33
L x W x H 85.8 in x 32.7 in x 50.2 in
Seat Height 38.0 in
Wheelbase 58.3 in
Rake (Caster Angle) 26.9°
Trail 4.7 in
Maximum Ground
Clearance
13.8 in
Fuel Capacity 1.6 gal
Wet Weight 240 lb
Warranty 30 Day (Limited Factory Warranty)
Color Monster Energy Yamaha Racing Edition









2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition – Totalmotorcycle.com Canada Specifications/Technical Details

NA







2023 Yamaha YZ450F Monster Energy Yamaha Racing Edition – Totalmotorcycle.com European Specifications/Technical Details

Engine Type 450cc liquid-cooled DOHC 4-stroke; 4 titanium
valves
Bore x Stroke 97.0mm × 60.8mm
Compression Ratio 13.0:1
Fuel Delivery Mikuni® fuel injection, 44mm
Transmission 5-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front KYB® spring-type fork with speed sensitive
damping; fully adjustable, 12.2-in travel
Suspension / Rear KYB® single shock; fully adjustable, 12.4-in
travel
Brakes / Front Hydraulic disc, 270mm
Brakes / Rear Hydraulic disc, 240mm
Tires / Front 80/100-21 Dunlop® Geomax MX33F
Tires / Rear 120/80-19 Dunlop® Geomax MX33
L x W x H 85.8 in x 32.7 in x 50.2 in
Seat Height 38.0 in
Wheelbase 58.3 in
Rake (Caster Angle) 26.9°
Trail 4.7 in
Maximum Ground
Clearance
13.8 in
Fuel Capacity 1.6 gal
Wet Weight 240 lb
Warranty 30 Day (Limited Factory Warranty)
Color Monster Energy Yamaha Racing Edition





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
