2004 Honda XR650L
Back to 2004 Honda Motorcycle Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2004 Honda XR650L
2004 Honda XR650L

2004 Honda XR650L
2004 Honda XR650L

2004 Honda XR650L Review

2004 Honda XR650L

Do it All; Do it Well…

Headlight? Long-travel suspension? Electric start? Is this a dirt bike or a street bike? Luckily, with the incredibly versatile XR650L, it doesn’t matter. First and foremost a hardcore dirt machine, the street-legal XR is living proof that you can do it all. And do it well.

2004 Honda XR650L Key Features

California version differs slightly due to emissions equipment.



2004 Honda XR650L – Specifications/Technical Details
USA MSRP Price: $5,499 USD
Canadian MSRP Price: See dealer for pricing in CDN

Weight 324.0 lbs.

Ground Clearance 13.0 in.

Wheelbase 57.3 in.

Seat Height 37.0 in.

Engine Air-cooled, dry-sump, single-cylinder, four-stroke, SOHC; four-valve RFVC

Displacement 644cc

Bore x Stroke 100.0mm x 82.0mm

Compression Ratio 8.3:1

Carburetion 42.5mm diaphragm-type CV

Fuel Capacity 2.8 gal., including 0.6-gal. reserve

Ignition Solid-state CD with electronic advance

Transmission Five-speed

Final Drive #520 O-ring-sealed chain; 15T/45T

Brakes Front: Single disc with twin-piston caliper
Rear: Single disc

Tires Front: 3.00-21
Rear: 4.60-18

Suspension Front: 43mm air-adjustable leading-axle Showa cartridge fork; 11.6-inch travel
Rear: Pro-Link Showa single-shock with spring-preload; 11.0-inch travel


Suggested Starting Price shown does not include tax, title, or destination charge. Dealer prices may vary. All specifications can change without notice.
