2006 Ducati ST4S
Back to 2006 Ducati Motorcycle Index Page



Click photos to enlarge.
They make great desktop images.

2006 Ducati ST4S
2006 Ducati ST4S

2006 Ducati ST4S
2006 Ducati ST4S

2006 Ducati ST4S
2006 Ducati ST4S

2006 Ducati ST4S
2006 Ducati ST4S



– 2006 Ducati ST4S

2006 Ducati ST4S

The ST4S bristles with our best race-derived components combined with all-day riding comfort. The awesome Superbike 996 cc Desmoquattro engine ensures maximum power.
The ST family boasts the highest level of comfort in its category. The front fairing offers superior aerodynamic protection and when combined with the height-adjustable handlebars, adjustable brake and clutch levers, and advanced seat ergonomics the result is a bike that comfortably accommodates rider and passenger on even the longest of journeys.

Of course, a great engine can only reach its potential when matched with an equally advanced chassis and suspension.

Extend the versatility and comfort of your ST with our most popular Sport Touring accessories – colour matched saddlebags are INCLUDED with U.S. spec STs. Top bags and other accessories are available for the entire ST family, they will protect your gear from the weather and allow you to comfortably leave most full-face helmets in a safe place.

MSRP $14,995 USD


Chassis:

Frame: Tubular steel trellis
Wheelbase: 1430 mm / 56.3 in
Rake: 24°
Front Suspension: Showa 43 mm upside-down fully adjustable fork with TiN surface treatment
Front Wheel Travel: 130 mm / 5.1 in
Front Brake: 2 x 320 mm semi-floating discs, 4-piston caliper
Front Wheel: 5-spoke light alloy 3.50 x 17
Front Tire: 120/70 ZR 17
Rear Suspension: Progressive linkage with fully adjustable Öhlins monoshock with remote control preload adjustment. Aluminium swingarm
Rear Wheel Travel: 148 mm / 5.8 in
Rear Brake: 245 mm disc, 2-piston caliper
Rear Wheel: 5-spoke light alloy 5.50 x 17
Rear Tire: 180/55 ZR 17
Fuel Capacity: 21 L / 5.5 US gal (includes 6 L / 1.5 US gal reserve)
Weight * : 201 kg / 442.7 lbs
Seat Height: 820 mm / 32.3 in
Instruments: Electronic instrument panel using CAN communication protocol with CPU, multifunctional digital display (including speedometer, clock, water temperature, fuel gauge, instant/average consumption, consumed fuel, residual autonomy), analog rev counter, self-adjusting instrument lights (depending on outdoor light), headlight angle adjustment, immobilizer system
Warranty: 2 years unlimited mileage
Tank and Fairing Colours: Red, Glossy Black
Frame and Wheel Colours: Metallic Grey (on Red) – Black w/Metallic Grey wheels (on Black)
Versions: Two Seats
*=* = The weight excludes battery, lubricants and, where applicable, cooling liquid.


ENGINE
Type: L twin cylinder, 4 valves per cylinder Desmodromic; liquid cooled
Displacement: 996 cc
Bore and stroke: 98 x 66 mm
Compression Ratio: 11.5:1
Power: 89.1 kw – 121 hp @ 8750 rpm
Torque: 10.5 kgm – 76 ft-lbs @ 7250 rpm
Fuel system: Marelli electronic fuel injection, 50 mm throttle body
Exhaust: 2 aluminum mufflers with catalytic converter (non-catalytic on USA version)
Emissions: Euro2 (except USA version)
Transmission
Gearbox: 6 speed
Ratio: 1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28
Primary drive: Straight cut gears; ratio 1.84
Final drive: Chain; Front sprocket 15; Rear sprocket 38
Clutch: Wet multiplate with hydraulic control




Colors:

Model Tank/Fairing Frame Color Wheels Color
SUPERBIKE
749 Dark Matte BlackMetallic GreyMetallic Grey
749Red, YellowRed, Metallic GreyBlack (on Red fairing), Metallic Grey (on Yellow Fairing)
749S RedRedBlack
749R RedRedBlack
999Red, Yellow, Gloss BlackRed (on Red fairing), Metallic Grey (on Yellow fairing), Black (on Black fairing)Black (on Red and Black fairing), Metallic Grey (on Yellow fairing)
999S Red, Gloss Black (both with white number plates)Red, BlackBlack
999R Red (white number plates)RedBlack
MONSTER
620 Dark Matte BlackBlackBlack
620Red, BlackRed, BlackBlack
1000S Red, BlackRed, BlackBlack
S2R Dark Matte BlackBlackBlack
S2R Red w/White stripe, Yellow w/Black stripe, Black w/Tangerine Red stripeRed (on Red fairing), Black (on Yellow and Black fairing)White (on Red fairing), Black (on Yellow and Black fairing)
S4R Red w/White stripe, Blue w/White stripe, Gloss BlackRed, Blue, BlackWhite (on Red and Blue fairing), Black
SPORTTOURING
ST3 / ST3S Red, Silver, Gloss BlackMetallic Grey (on Red and Silver fairing), BlackMetallic Grey
ST4S Red, Gloss BlackMetallic Grey (on Red fairing), BlackMetallic Grey
ST4S ABS RedMetallic GreyMetallic Grey
SUPERSPORT
1000 DSMetallic GreyMetallic GreyRed
800Red, YellowMetallic GreyMetallic Grey
MULTISTRADA
620 Dark Matte BlackBlackBlack
620Red, YellowRed, BlackBlack
1000 DS Red, Silver, Gloss BlackRed, BlackMetallic Grey
1000S DS Red, BlackRed, BlackBlack
SPORTCLASSIC
GT1000GT Grey
Smart 1000LEClassic SilverSea GreenAluminum
Sport 1000Burnt Yellow, Red, BlackBlackAluminum
