2009 Benelli BX570 Motard

You are here: Index2009 Models — 2009 Benelli Motorcycle Models

2009 Benelli BX570 Motard
Back to 2009 Benelli Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2009 Benelli BX570 Motard
2009 Benelli BX570 Motard

2009 Benelli BX570 Motard
2009 Benelli BX570 Motard

2009 Benelli BX570 Motard
2009 Benelli BX570 Motard

– 2009 Benelli BX570 Motard

2009 Benelli BX570 Motard





2009 Benelli BX570 Motard – USA Specifications
MSRP $0 USD

Model may not be available in the USA. Stay tuned.





2009 Benelli BX570 Motard – Canada Specifications
MSRP C$TBA CDN

Available in Canada, no Canadian specs, see EU specs below:

ENGINE
TYPE Single cylinder, 4 stroke, liquid cooled, 4 titanium valves, double overhead camshaft, with balancer shaft
DISPLACEMENT 569 cc
BORE x STROKE 104 x 67 mm
COMPRESSION RATIO 12,5:1
RATED OUTPUT n.d.
MAX. TORQUE n.d.
FUEL SUPPLY Electronic injection with throttle body ø48 mm
EXHAUST SYSTEM With catalytic converter and oxigen sensor
CERTIFICATION Euro 3
CLUTCH Wet clutch
GEARBOX 6 speed
FINAL DRIVE Chain drive, ratio n.d.
CHASSIS
FRAME Single tube cradle with forged, casted and extruded elements and carbon structural part patented. Light alloy rear subframe
FRONT SUSPENSION ø50 mm upside-down fork, with hydraulic extension and compression adjustments
FRONT SUSPENSION STROKE 272,5 mm
REAR SUSPENSION Aluminum casted swingarm, progressive rear dumper completely adjustable in extension, compression and spring preload
REAR SUSPENSION STROKE n.d.
FRONT BRAKE Single floating disk ø320 mm with 4 pistons radial caliper
REAR BRAKE Single disk ø220 mm with single piston floating caliper
FRONT RIM 3,5”x17”
REAR RIM 4.25”x17”
FRONT TYRE 120/70 R17
REAR TYRE 150/60 R17
SIZES
LENGHT n.d.
WIDHT EXCLUDING MIRRORS n.d.
HEIGHT EXCLUDING MIRRORS n.d.
SEAT HEIGHT n.d.
WHEELBASE n.d.
UNLADEN WEIGHT* n.d.
ROAD READY WEIGHT** n.d.
PERMITTED TOTAL WEIGHT n.d.
USABLE TANK VOLUME 8,5 lt
RESERVE n.d.

* without fluids
** According to guideline 93/93/CEE with all fluids, fuelled with at least 90% of usable tank volume









2009 Benelli BX570 Motard – Europe/UK Specifications
MSRP £TBA RRP OTR

ENGINE
TYPE Single cylinder, 4 stroke, liquid cooled, 4 titanium valves, double overhead camshaft, with balancer shaft
DISPLACEMENT 569 cc
BORE x STROKE 104 x 67 mm
COMPRESSION RATIO 12,5:1
RATED OUTPUT n.d.
MAX. TORQUE n.d.
FUEL SUPPLY Electronic injection with throttle body ø48 mm
EXHAUST SYSTEM With catalytic converter and oxigen sensor
CERTIFICATION Euro 3
CLUTCH Wet clutch
GEARBOX 6 speed
FINAL DRIVE Chain drive, ratio n.d.
CHASSIS
FRAME Single tube cradle with forged, casted and extruded elements and carbon structural part patented. Light alloy rear subframe
FRONT SUSPENSION ø50 mm upside-down fork, with hydraulic extension and compression adjustments
FRONT SUSPENSION STROKE 272,5 mm
REAR SUSPENSION Aluminum casted swingarm, progressive rear dumper completely adjustable in extension, compression and spring preload
REAR SUSPENSION STROKE n.d.
FRONT BRAKE Single floating disk ø320 mm with 4 pistons radial caliper
REAR BRAKE Single disk ø220 mm with single piston floating caliper
FRONT RIM 3,5”x17”
REAR RIM 4.25”x17”
FRONT TYRE 120/70 R17
REAR TYRE 150/60 R17
SIZES
LENGHT n.d.
WIDHT EXCLUDING MIRRORS n.d.
HEIGHT EXCLUDING MIRRORS n.d.
SEAT HEIGHT n.d.
WHEELBASE n.d.
UNLADEN WEIGHT* n.d.
ROAD READY WEIGHT** n.d.
PERMITTED TOTAL WEIGHT n.d.
USABLE TANK VOLUME 8,5 lt
RESERVE n.d.

* without fluids
** According to guideline 93/93/CEE with all fluids, fuelled with at least 90% of usable tank volume


(Benelli Q.J. reserves the right to change technical specifications, equipment, set ups, and colours without prior notice.)
