2009 Suzuki Boulevard C90T

Key Features

– Custom-designed windshield provides classic styling and full wind protection – includes unique chrome garnish with Boulevard emblem

– Attractive studded seats, plus matching touring-style backrest with unique pivoting backrest pad for increased passenger comfort

– Large capacity, textured leather saddle bags with Boulevard emblems and convenient twist-lock fasteners

– Large white-faced speedometer

– Stylish white-wall tires – 150/80-16 front and 180/70-15 rear tire mounted on custom-styled machined aluminum wheels

Engine Features

– Fuel-injected, 90 cubic inch, 6-valve, air/oil-cooled engine designed for maximum low/mid-range torque and acceleration

– 45 degree phase, dual-pin crankshaft minimizes vibration, plus added flywheel mass enhances low/mid-range power

– Electronic fuel injection system features the Suzuki Dual Throttle Valve System (SDTV) – maintains optimum air velocity in the intake tract for smooth low-to-mid rpm throttle response and high torque output – includes Auto Fast Idle System (AFIS)

– 32-bit ECM provides precise control of ignition timing and multi-hole-type injectors ensuring quick startup and excellent drivability under all conditions

– SCEM (Suzuki Composite Electro-chemical Material) cylinder plating is durable, minimizes cylinder size & weight and improves heat dissipation

– Efficient SACS air/oil cooling system with additional piston-jet cooling and engine oil cooler

– Hydraulic valve lash adjusters eliminate valve adjustment maintenance and ensure quiet engine operation

– Silent operation cam chains with automatic tensioners reduce engine noise and maintenance

– Hydraulic clutch with back-torque limiter ensures smooth downshifts

– Smooth-shifting 5-speed transmission with-low maintenance, low-torque-reactive shaft final drive – gear ratios set for low engine rpm at cruising speed

– Right-side-mounted exhaust system with slash-cut-style mufflers tuned for low-rpm power and a throaty exhaust sound

– Pulsed-secondary air-injection system introduces air into the exhaust ports to ignite unburned hydrocarbons and reduce emissions – CA. spec. model is equipped with a catalyst for further emission reduction

Chassis Features

– Long 1700mm wheelbase chassis with 32? rake angle set-up for low seat height with comfortable seating and control positions

– Wide handlebar and seat design, plus wide/low fuel tank shape add to C90’s low-slung look

– Double-cradle steel frame is made of large diameter steel tubing for strength and rigidity – bolt-on sections use painted mounting bolts and caps for a detailed look

– Dual-disc front brake system and single disc rear with 4-piston caliper for strong braking
– performance

– Link-type rear suspension with preload adjustment combined with 41mm front forks provide a comfortable, compliant ride

– Fuel filler located below a locking cover to maintain sleek appearance with fuel tank mounted below the seat for a low center-of-gravity

– Electronic speedometer with LCD fuel gauge, odometer & twin tripmeters

– Powerful multi-reflector headlight housed in an attractive case with stylish headlight rim – headlight switches off during startup to reduce load on battery

– Standard 4-way emergency flasher and high beam passing switch

– Bright, multi-reflector turn signals designed for high visibility and attractive appearance

– Large floorboard-type footrests

Optional accessories

– All other Suzuki Boulevard Authentic Accessories will fit the C90T

2009 Suzuki Boulevard C90T – USA Specifications
MSRP: $11,699 USD

Model Number C90TK9
Type Cruiser
Warranty
Suggested Retail $11699
SEP $0
Engine 1462 cc (89.2 cu. in), 4-stroke, air-cooled, OHC, 45? V-twin
Bore & Stroke 96.0 mm (3.780 in) x 101.0 mm (3.976 in)
Compression Ratio 8.5 : 1
Fuel System Fuel injection
Lubrication Wet sump
Ignition Electronic ignition (Transistorized)
Starter Electric
Transmission 5-speed constant mesh
Final Drive Shaft Drive
Overall Length 2525 mm (99.4 in)
Overall Width 1000 mm (39.4 in)
Overall Height 1422 mm (56.0 in)
Seat Height 700 mm (27.6 in)
Ground Clearance 140 mm ( 5.5 in)
Wheelbase 1700 mm (66.9 in)
Curb Weight 339 kg (747 lbs)
Suspension Front Telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Brakes Front Disc brake, twin
Brakes Rear Disc brake
Tires Front 150/80-16M/C 71H, tubeless
Tires Rear 180/70-15M/C 76H, tubeless
Fuel Tank Capacity 14.0 L (3.7/3.1 US/Imp gal)
Color Black/Gray, Orange/Black

2009 Suzuki Boulevard C90T – Canada Specifications
MSRP: $14,699 CDN

Chassis:
Brakes Front Disc brake, twin
Brakes Rear Disc brake
Color Black/Gray, Orange/Black
i Curb Weight 345 kg (760 lbs)
Final Drive Shaft Drive
Fuel Tank Capacity 14.0 L (3.7/3.1 US/Imp gal)
Ground Clearance 140 mm ( 5.5 in)
Overall Length 2525 mm (99.4 in)
Overall Width 1000 mm (39.4 in)
Seat Height 700 mm (27.6 in)
Suspension Front Telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Tires Front 150/80-16M/C 71H, tubeless
Tires Rear 180/70-15M/C 76H, tubeless
Transmission 5-speed constant mesh
Wheelbase 1700 mm (66.9 in)

Engine:
Bore Stroke 96.0 mm (3.780 in) x 101.0 mm (3.976 in)
Compression Ratio 8.5 : 1
Engine 1462 cc (89.2 cu. in), 4-stroke, air-cooled, OHC, 45-degree V-twin
Fuel System Fuel injection
Ignition Electronic ignition (Transistorized)
Lubrication Wet sump
Starter Electric

Warranty:
Warranty 12 Month unlimited mileage limited warranty

Prices and specifications subject to change without notice.
