2009 Suzuki Burgman 400 ABS

You are here: Home2009 Models — 2009 Suzuki Motorcycle Models

2009 Suzuki Burgman 400 ABS
Back to 2009 Suzuki Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2009 Suzuki Burgman 400 ABS
2009 Suzuki Burgman 400 ABS

2009 Suzuki Burgman 400 ABS
2009 Suzuki Burgman 400 ABS

2009 Suzuki Burgman 400 ABS
2009 Suzuki Burgman 400 ABS

– 2009 Suzuki Burgman 400 ABS

2009 Suzuki Burgman 400 ABS

Looking to turn some heads? You came to the right place.

The Burgman 400 not only combines exhilarating performance with a comfortable ride – it boasts a stylish design that’s guaranteed to capture the spotlight wherever you ride.

Around town or on longer rides, the Burgman 400 offers an impressively comfortable ride. It has plush suspension, matched by a sleek, aerodynamic fairing that provides excellent protection from the wind. A stepped seat and an easily adjustable backrest for the rider provides comfortable seating mile after mile. And concave floorboards offer you and your passenger plenty of legroom.

For exciting performance, its liquid-cooled engine offers strong acceleration, while an advanced fuel injection system provides crisp throttle response. It also has an automatic clutch and V-belt drive for smooth power delivery and standard ABS braking.

Have some cargo you need to stash? No problem. The Burgman 400 has a lighted underseat storage compartment that accommodates two full-coverage helmets, matched by three front compartments with lids that allow quick, easy access to smaller items.

So add some style – and excitement – to your life, with the 2009 Suzuki Burgman 400!


Chassis Features
– ABS assisted front and rear brakes
– High-tensile steel-tube frame designed for strength and rigidity
– Large 14 inch front wheel combined with ABS assisted dual hydraulic disc brakes up front for excellent stability and braking control
– Link-type rear suspension features a single shock absorber with 7 way adjustable spring preload
– Telescopic front fork with 41mm inner tubes for unmatched rider comfort and control

Engine Features
– Belt-drive, CVT transmission is fully automatic and easy-to-use
– Convenient electric starting system with maintenance-free battery
– Electronic fuel injection system provides easy engine starts, precise throttle response, reduced fuel consumption and low emissions
– Electronically controlled pulsed-air injection system (PAIR), helps reduce emissions
– High-efficiency liquid-cooling system includes thermostatically-controlled fan for consistent engine temperature under all operation conditions
– Injector is mounted directly in the intake pipe and aimed directly at the intake valves for more efficient combustion
– Liquid-cooled, 400cc DOHC 4-valve engine – designed to produce broad, usable power with smooth/quiet operation and low maintenance
– Oval section exhaust system meets Euro 3 emission regulations with a catalyzer and oxygen sensor

New Featuers
– Model equipped with ABS braking for 2009

Utility/Convenience Features
– Convenient parking brake with easy-to-use single lever operation
– Convenient front glovebox compartment with DC-electrical accessory outlet, plus two additional storage compartments above the glovebox
– Cut-away floorboards provide more space for rider’s legs when putting feet down
– Easy-to-read instrument panel with analog speedometer and tachometer combined with LCD odometer, twin tripmeters, clock and all new average fuel consumption readout
– Large 62 liter under-seat storage compartment is the largest in its class and can comfortably hold two full face helmets
– Large windshield for increased rider comfort and creates a smooth flow of air over the rider
– Tamper-resistant magnetic ignition switch cover for added security – ignition switch includes built-in seat latch operation


2009 Suzuki Burgman 400 ABS – USA Specifications
MSRP: $6,699 USD

Model Number AN400AK9
Type Scooters
Suggested Retail $6699
SEP $0
Engine 400cc (24.4 cu. in), 4-stroke, liquid-cooled, DOHC
Bore & Stroke 81.0 mm (3.189 in) x 77.6 mm (3.055 in)
Compression Ratio 10.6 : 1
Fuel System Fuel injection
Lubrication Wet Sump
Ignition Electronic ignition (Transistorized)
Starter Electric
Transmission Automatic
Final Drive V-belt drive
Overall Length 2270 mm (89.4 in)
Overall Width 760 mm (29.9 in)
Overall Height 1385 mm (54.5 in)
Seat Height 710 mm (28.0 in)
Ground Clearance 125 mm (4.9 in)
Wheelbase 1585 mm (62.4 in)
Curb Weight TBA
Suspension Front Telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Brakes Front Disc brake, twin
Brakes Rear Disc brake
Tires Front 120/80-14 M/C 58S, tubeless
Tires Rear 150/70-13 M/C, 64S tubeless
Fuel Tank Capacity TBD
Color Gray


2009 Suzuki Burgman 400 ABS – Canada Specifications
MSRP: $7,999 CDN

Brakes Front Double disc brake with ABS
Brakes Rear Disc brake with ABS
Color Gray, Black
Curb Weight 222 kg (489 lbs.)
Final Drive V-belt drive
Fuel Tank Capacity 14 L (3.08 imp gal.)
Ground Clearance 125 mm (4.9 in)
Overall Length 2265 mm (89.2 in)
Overall Width 760 mm (29.9 in)
Seat Height 710 mm (28.0 in)
Suspension Front 41mm telescopic forks, coil spring, oil damped
Suspension Rear Link type, coil spring, gas/oil damped, spring preload 7-way adjustable
Tires Front 120/80-14 M/C (58s)
Tires Rear 150/70-13M/C (64s)
Transmission Variable ration V-belt drive
Wheelbase 1590 mm (62.6 in)

Bore Stroke 81.0 mm x 77.6 mm
Compression Ratio 12.5 : 1
Engine 4-stroke, liquid-cooled, DOHC, single cylinder
Fuel System Fuel injection
Ignition Electronic ignition (Transistorized)
Lubrication Wet Sump
Starter Electric

Warranty 12 Month unlimited mileage limited warranty

Prices and specifications subject to change without notice.
