2009 Triumph Speed Triple

You are here: Home2009 Models — 2009 Triumph Motorcycle Models

2009 Triumph Speed Triple
Back to 2009 Triumph Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2009 Triumph Speed Triple
2009 Triumph Speed Triple

2009 Triumph Speed Triple
2009 Triumph Speed Triple

2009 Triumph Speed Triple
2009 Triumph Speed Triple

2009 Triumph Speed Triple
2009 Triumph Speed Triple

– 2009 Triumph Speed Triple

2009 Triumph Speed Triple

It all started because we liked the idea of it. Its success is proof we are not alone.

The sound, character and sheer power of the 1050cc triple engine delivering 130 bhp is at the heart of this stripped-for-action rebel.

Iconic twin headlamps, tapered aluminium Magura bars, black multi spoke alloy wheels, minimalist rear section with clear lens LED rear light and twin short exhaust cans.

Minimalist the styling may be, but when it comes to specification maximum is the more appropriate descriptor.

Twin Brembo 4-piston 4-pad radial calipers mounted on fully adjustable black anodised Showa USD forks. Fully adjustable Showa monoshock rear suspension. Single sided swing arm.

The Speed triple is tougher than ever and determined to defend its rightful position as the definitive factory streetfighter.


Features & Benefits

Engine
The Speed Triple’s 1050cc, three cylinder engine, with its unmistakable character and sound, pumps out a great surge of bottom-end torque, massive mid-range punch and an impressive level of overall power. Peak power is 132PS (131bhp) at 9250rpm while peak torque of 105Nm (77ft.lbf) arrives at 7550rpm. Triumph’s Keihin ECU offers sophisticated mapping for quicker starting, cleaner running and fuel economic engine.


Wheels

Multi-spoke alloy wheels add to the Speed Triple’s streetfighter attitude.


Suspension
The fully adjustable 43mm upside down forks and rear monoshock add superb levels of quality and control, while the new black anodised finished to the front forks amplify the Speed Triple’s rebellious look.


Brakes
High-spec, twin Brembo radial front caliper four pad, four piston units, with a radial master cylinder, supply outstanding braking performance.


Rear End
The Speed Triple’s rear-end has sharp, minimalist styling and features a new rear sub-frame, polished stainless steel heat shields and repositioned ball burnished aluminium pillion footrests to give the pillion rider more leg room. It also sports a new, clear-lens LED rear light.


Handlebars
Magura tapered, anodised aluminium handlebars are a sharp addition to the Speed Triple’s minimalist styling.







2009 Triumph Speed Triple – USA Specifications
MSRP $11,299 USD

Engine

Type
Liquid-cooled, DOHC, in-line 3-cylinder
Capacity
1050cc
Bore/Stroke
79 x 71.4mm
Compression Ratio
12.0:1
Fuel System
Multipoint sequential electronic fuel injection

Transmission

Final Drive
X ring chain
Clutch
Wet, multi-plate
Gearbox
6-speed

Cycle Parts

Frame
Tubular, fabricated aluminum alloy perimeter
Swingarm
Single-sided, aluminum alloy with eccentric chain adjuster
Front Wheel
Alloy 5-spoke, 17 x 3.5in
Rear Wheel
Alloy 5-spoke, 17 x 5.5in
Front Tyre
120/70 ZR 17
Rear Tyre
180/55 ZR 17
Front Suspension
43mm USD forks with dual rate springs and adjustable preload, rebound and compression damping
Rear Suspension
Monoshock with adjustable preload, compression and rebound damping
Front Brakes
Twin 320mm floating discs, 4 piston radial calipers
Rear Brakes
Single 220mm disc, 2 piston caliper

Dimensions

Length
83.3in
Width (Handlebars)
30.7in
Height
49.2in
Seat Height
32.1in
Wheelbase
56.2in
Rake/Trail
23.5 degree/84mm
Weight (Dry)
416lbs
Fuel Tank Capacity
4.6 gal

Performance (Measured at crankshaft to DIN 70020)

Maximum Power
130bhp at 9,250 rpm
Maximum Torque
77ft.lbf at 7,550 rpm

Colours



Jet Black, Fusion White, Blazing Orange, Matte Black

Price


$11,299





2009 Triumph Speed Triple – Canada Specifications
MSRP C$12,199 CDN

Engine
Type
Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Capacity
1050cc
Bore/Stroke
79.0 x 71.4mm
Compression Ratio
12.0:1
Fuel System
Multipoint sequential electronic fuel injection
Transmission
Final Drive
X ring chain
Clutch
Wet, multi-plate
Gearbox
6-speed

Cycle Parts
Frame
Aluminium beam twin spar
Swingarm
Single-sided, alumium alloy with eccentric chain adjuster
Front Wheel
Cast aluminium alloy , multi spoke, 17 x 3.5in
Rear Wheel
Cast aluminium alloy, multi spoke, 17 x 5.5in
Front Tyre
120/70 ZR 17
Rear Tyre
180/55 ZR 17
Front Suspension
Showa 43mm upside down forks with dual rate springs and adjustable preload, rebound and compression damping, 120mm travel
Rear Suspension
Showa Monoshock with adjustable preload and rebound and compression damping, 134mm travel
Front Brakes
Twin 320mm floating discs. Twin Brembo 4 piston 4 pad radial calipers. Radial master cylinder
Rear Brakes
Single 220mm disc, Nissin 2 piston sliding caliper


Dimensions

Length
2,115mm (83.3in)
Width (Handlebars)
780mm (30.7in)
Height
1,250mm (49.2in)
Seat Height
815mm (32.1in)
Wheelbase
1,429mm (56.2in)
Rake/Trail
23.5 degree/84mm
Weight (Dry)
189kg (416lbs)
Fuel Tank Capacity
18 liters (4.0 gal)
Performance (Measured at crankshaft to DIN 70020)
Maximum Power
132PS / 130bhp @ 9,250 rpm
Maximum Torque
105Nm / 77ft.lbf @ 7,550 rpm

Colours

Blazing Orange, Jet Black, Fusion White, Matte Black

Price

$12,199







Triumph 2009 Triumph Speed Triple Media/Press Release(s):

None as of yet.
