2016 Can-Am Spyder F3 Limited Review

2016 Can-Am Spyder F3 Limited on www.Totalmotorcycle.com

THE RIDE IS THE DESTINATION

A stunning appearance package with an audio system make this Spyder F3 road-trip ready.

Relax and stretch out as the open road appears in front of you for hours or days with the new bagger-style Spyder F3 Limited. There’s the comfort features and luggage of the F3-T, plus a full audio system for tunes, rider footboards and more chrome.



2016 Can-Am Spyder F3 Limited www.Totalmotorcycle.com Key Features

SPYDER F3 STANDARD FEATURES

Rotax 1330 ACE in-line 3 cylinders, high torque engine
Vehicle Stability System with ABS, traction control and stability control
High-performance Brembo† braking system
Gas-charged, aluminum, FOX† PODIUM† front shocks
ECO™ mode smart assist
UFit custom fitting system (rider footpegs and handlebars)
6-spoke, Metallic Silver front wheels
Anti-theft system
Dynamic Power Steering

TRANSMISSIONS AND COLOR AVAILABLE:
6-speed manual with reverse (SM6)
6-speed semi-automatic with reverse (SE6)

STEEL BLACK METALLIC

SPYDER F3-S

ALL SPYDER F3 FEATURES PLUS:
Cruise control
6-spoke, machined Deep Black high gloss front wheels
Refined front fenders with integrated LED lights
Black embossed suede seat with Red stitching and “S” tab
Deep Black high gloss rear wheel
Distinctive “S” trim signature

PEARL WHITE

CAN-AM RED
SOLID GLOSS
PURE MAGNESIUM METALLIC WITH CAN-AM RED FRAME

SPYDER F3-S SPECIAL SERIES

ALL SPYDER F3-S FEATURES PLUS:
6-spoke, Black Chrome front wheels
Black perforated seat with Black stitching
Exclusive Triple Black coloration and graphics
Unique Special Series signature trims
*Shown with optional Urban Rack

TRANSMISSIONS AND COLOR AVAILABLE:
ONLY 6-speed semi-automatic with reverse (SE6)

MONOLITH BLACK SATIN



2016 Can-Am Spyder F3 Limited www.Totalmotorcycle.com Features and Benefits

ROTAX 1330 ACE ENGINE



POWERFUL AND EFFICIENT



The Rotax 1330 ACE engine is an in-line triple-cylinder configuration for maximum torque in every gear, to deliver excellent roll-on acceleration and throttle response. It’s also efficient, with the ability to ride up to 252 miles (406 km) on a single tank*. Plus, it’s extremely low maintenance.

*Tested at constant speed. Fuel mileage may vary depending personal riding habits, weather conditions, trip length, vehicle condition, vehicle configuration and other conditions. Break-in mileage may vary.





6-SPEED TRANSMISSION



SMOOTH OPERATOR



This 6-speed transmission offers the perfect balance of comfort and fuel economy thanks to a sophisticated hydraulic clutch system. Cruise comfortably at low RPMs. Includes reverse. The semi-automatic version uses thumb and finger paddle shifting.





VEHICLE STABILITY SYSTEM



OPTIMUM CONTROL



Developed in partnership with BOSCH and inspired by automotive technologies, the Vehicle Stability System integrates anti-lock brakes, traction control, and stability control for confidence taking on the open road.





SACHS BIG-BORE SHOCKS



ENGINEERED FOR A SMOOTHER RIDE



These premium wide-diameter shocks ensure a plush ride even on bumpy backcountry roads and are quiet at all speeds.


UFIT SYSTEM



TAILOR YOUR
BIKE



The exclusive Spyder F3 UFit system lets you
easily position the footpegs according to your
height and choose the handlebar based on
your preferred riding style — ensuring a truly
customized riding experience.
*Custom handlebar sold as an accessory.





BREMBO BRAKING SYSTEM



SERIOUS STOPPING POWER



Higher-performance brakes specifically designed for Can-Am Spyder from the world leader in braking technology ensure excellent stopping power and consistent performance every time.





CARGO SPACE



BRING
MORE



In addition to the trademark Spyder front cargo area, there is a new glove box and two smartly-styled hard side luggage cases for a total of 21 gallons (78 L) of cargo capacity.





LIMITED LUXURY FEATURES



ALL-SEASON, ALL-RIDE COMFORT



Get added comfort with rider floorboards and heated handgrips.





AUDIO SYSTEM



ON-ROAD ENTERTAINMENT



Music and cruising were made for each other. AM/FM radio with USB and AUX inputs for cell and MP3 player, located in the glove box, drives four speakers up front.





PREMIUM WHEELS



CHROME SHAMROCK



Uniquely styled Shamrock chrome wheels, surrounded by premium front fenders with integrated LED light pipes.





RIDER FOOTBOARDS



VARY YOUR POSITION



You get more foot positions with these driver footboards, a real benefit on long rides.





CONVENIENT CONSOLE



SLEEK
PROTECTION




On long rides, you’ll appreciate the added wind protection and convenience from the low tinted windshield, integrated rear-view mirrors and glove box.





SEATING



LUXURIOUS STYLE, UNMATCHED COMFORT



Luxurious all-black suede saddle features color-matched stitching and metal LIMITED ingot. Delivers-all-day comfort and excellent lumbar support.




2016 Can-Am Spyder F3 Limited – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $27249 USD

/ ENGINE /
Type . Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled with
electronic fuel injection and electronic throttle control
Bore & stroke . 3.31 x 3.14 in. (84 x 80 mm)
Power 115 hp (86 kW) @ 7250 RPM
Torque 96 lb-ft. (130 Nm) @ 5000 RPM
/ CHASSIS /
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel SACHS† Big-Bore shock absorbers / 5.1 in. (129 mm)
Rear suspension . Swing-arm with basic monoshock
Rear shock type / Travel SACHS shock absorber with adjustable air preload
(manually) / 5.2 in. (132 mm)
Electronic brake Foot-operated, hydraulic 3-wheel brake
distribution system
Front brakes . 270 mm discs with Brembo† 4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper
with integrated parking brake
Parking brake . Electrically actuated
Front tires MC165 / 55R15 55H
Rear tire MC225 / 50R15 76H
Aluminum front rims ………. 6-spoke, Machined Deep Black high gloss front wheels,
15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Deep Black, 15 x 7 in. (381 mm x 178 mm)
/ FEATURES /
Instrumentation ………………Premium color digital gauge: Digital speedometer,
tachometer, odometer, trip & hour meters, gear position,
ECO™ mode smart assist, temperature, engine lights,
electronic fuel gauge, clock
Running lights 2 halogen headlamps (55 / 60-W)
Windshield Tinted
Cruise control Electronic
RT-622 and Freedom Towing capacity of 400 lb (181 kg)
trailer capability
Trims and parts ……………….. Chrome Satin and Carbon Black: Rear sprocket wheel,
front and rear shocks springs, exhaust tip and heat shield
/ SAFETY & SECURITY /
SCS Stability Control System
TCS Traction Control System
ABS Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security
System (D.E.S.S.™)
/ DIMENSIONS /
L x W x H …………………………102.2 x 58.9 x 48.9 in.
(2,596 x 1,497 x 1,241 mm)
Wheelbase 67.3 in. (1,709 mm)
Seat height 26.6 in. (675 mm)
Ground clearance 4.5 in. (115 mm)
Dry weight 948 lb (430 kg)
Storage capacity 20.6 gal (78 L)
Maximum vehicle load 439 lb (199 kg)
Fuel capacity 7.1 gal (27 L)
Reserve 1.2 gal (4.5 L) approx.
Fuel type Premium unleaded
/ WARRANTY /
Factory . 2-year BRP Limited Warranty
with 2-year roadside assistance
Extended . B.E.S.T. available from
12 to 36 months









2016 Can-Am Spyder F3 Limited – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $31299 CDN

/ ENGINE /
Type . Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled with
electronic fuel injection and electronic throttle control
Bore & stroke . 3.31 x 3.14 in. (84 x 80 mm)
Power 115 hp (86 kW) @ 7250 RPM
Torque 96 lb-ft. (130 Nm) @ 5000 RPM
/ CHASSIS /
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel SACHS† Big-Bore shock absorbers / 5.1 in. (129 mm)
Rear suspension . Swing-arm with basic monoshock
Rear shock type / Travel SACHS shock absorber with adjustable air preload
(manually) / 5.2 in. (132 mm)
Electronic brake Foot-operated, hydraulic 3-wheel brake
distribution system
Front brakes . 270 mm discs with Brembo† 4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper
with integrated parking brake
Parking brake . Electrically actuated
Front tires MC165 / 55R15 55H
Rear tire MC225 / 50R15 76H
Aluminum front rims ………. 6-spoke, Machined Deep Black high gloss front wheels,
15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Deep Black, 15 x 7 in. (381 mm x 178 mm)
/ FEATURES /
Instrumentation ………………Premium color digital gauge: Digital speedometer,
tachometer, odometer, trip & hour meters, gear position,
ECO™ mode smart assist, temperature, engine lights,
electronic fuel gauge, clock
Running lights 2 halogen headlamps (55 / 60-W)
Windshield Tinted
Cruise control Electronic
RT-622 and Freedom Towing capacity of 400 lb (181 kg)
trailer capability
Trims and parts ……………….. Chrome Satin and Carbon Black: Rear sprocket wheel,
front and rear shocks springs, exhaust tip and heat shield
/ SAFETY & SECURITY /
SCS Stability Control System
TCS Traction Control System
ABS Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security
System (D.E.S.S.™)
/ DIMENSIONS /
L x W x H …………………………102.2 x 58.9 x 48.9 in.
(2,596 x 1,497 x 1,241 mm)
Wheelbase 67.3 in. (1,709 mm)
Seat height 26.6 in. (675 mm)
Ground clearance 4.5 in. (115 mm)
Dry weight 948 lb (430 kg)
Storage capacity 20.6 gal (78 L)
Maximum vehicle load 439 lb (199 kg)
Fuel capacity 7.1 gal (27 L)
Reserve 1.2 gal (4.5 L) approx.
Fuel type Premium unleaded
/ WARRANTY /
Factory . 2-year BRP Limited Warranty
with 2-year roadside assistance
Extended . B.E.S.T. available from
12 to 36 months








2016 Can-Am Spyder F3 Limited – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: Starting from £21699 GBP (On The Road inc 20% Vat)

/ Engine /
Type . Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled with
electronic fuel injection and electronic throttle control
Bore & stroke . 3.31 x 3.14 in. (84 x 80 mm)
Power 115 hp (86 kW) @ 7250 RPM
Torque 96 lb-ft. (130 Nm) @ 5000 RPM
/ CHASSIS /
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel SACHS† Big-Bore shock absorbers / 5.1 in. (129 mm)
Rear suspension . Swing-arm with basic monoshock
Rear shock type / Travel SACHS shock absorber with adjustable air preload
(manually)/ 5.2 in. (132 mm)
Electronic brake Foot-operated, hydraulic 3-wheel brake distribution system
Front brakes . 270 mm discs with Brembo† 4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper
with integrated parking brake
Parking brake . Electrically actuated
Front tyres MC165 / 55R15 55H
Rear tyre MC225 / 50R15 76H
Aluminium front rims ……..6-spoke, Machined Deep Black high gloss front wheels,
15 x 5 in. (381 x 127 mm)
Aluminium rear rim Deep Black, 15 x 7 in. (381 mm x 178 mm)
/ FEATURES /
Instrumentation ………………Premium colour digital gauge: Digital speedometer,
tachometer, odometer, trip & hour meters, gear position,
ECO™ mode smart assist, temperature, engine lights,
electronic fuel gauge, clock
Running lights 2 halogen headlamps (55 / 60-W)
Windshield Tinted
Cruise control Electronic
Trims and parts ……………….. Chrome Satin and Carbon Black: Rear sprocket wheel,
front and rear shocks springs, exhaust tip and heat shield
/ SAFETY & SECURITY /
SCS Stability Control System
TCS Traction Control System
ABS Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security
System (D.E.S.S.™)
/ DIMENSIONS /
L x W x H …………………………102.2 x 58.9 x 48.9 in.
(2,596 x 1,497 x 1,241 mm)
Wheelbase 67.3 in. (1,709 mm)
Seat height 26.6 in. (675 mm)
Ground clearance 4.5 in. (115 mm)
Dry weight 948 lb (430 kg)
Storage capacity 20.6 US gal (78 L)
Maximum vehicle load 439 lb (199 kg)
Fuel capacity 7.1 US gal (27 L)
Reserve 1.2 US gal (4.5 L) approx.
Fuel type Premium unleaded
/ Warra nty /
Factory . 2-year BRP Limited Warranty
with 2-year roadside assistance

*Starting at MSRP is the manufactured suggested price and excludes delivery, setup, tax, title, license, and additional fees and expenses. Bikes may be shown with optional accessories. Final sale price determined by an authorized dealer. Specifications and MSRP are subject to change.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
