2022 Zero DSR: ADVENTURE UNLEASHED.
Introducing the 2022 Zero DSR…
Churn out an incredible 116 ft-lb of torque while still being able to hear the crunch of your AT tires shredding the dirt. The DSR cranks the power up to 11 and transforms any road into the adventure of a lifetime. No shifting, vibration or fumes. The industry leading Z-Force® powertrain effortlessly drives your adventure as your motorcycle seems to silently disappear beneath you.
2022 Zero DSR Totalmotorcycle.com Key Features
STANDARD
ZF 14.4
TOP SPEED (MAX) 102 MPH
CITY RANGE 163 MILES
PEAK TORQUE 116 FT-LB
19-INCH FRONT WHEEL For better off-road handling
14.4 KWH Power pack
2 HOUR CHARGE TIME With Charge Tank
100% ELECTRIC POWERTRAIN
Low maintenance CYPHER II Operating system
CLUTCHLESS DIRECT DRIVE Transmission
419 LB Curb weight
BOSCH Generation 9 ABS
33.2 IN Seat height
POWER TANK
ZF 14.4 Power Tank
TOP SPEED (MAX) 102 MPH
CITY RANGE 163 MILES
PEAK TORQUE 116 FT-LB
19-INCH FRONT WHEEL For better off-road handling
14.4 KWH Power pack
2 HOUR CHARGE TIME With Charge Tank
100% ELECTRIC POWERTRAIN
Low maintenance CYPHER II Operating system
CLUTCHLESS DIRECT DRIVE Transmission
419 LB Curb weight
BOSCH Generation 9 ABS
33.2 IN Seat height
5 YEARS/UNLIMITED MILES
2022 Zero DSR Totalmotorcycle.com Features and Benefits
ALWAYS DIALED
Crossing from smooth asphalt to loose gravel fire roads All good. Change performance profiles at the press of a button to master any terrain. The Zero DSR is pre-programmed with Eco or Sport modes and performance can be fully customized using the Zero Motorcycles app where you can also see detailed ride stats.
CHARGE UP TO 6X FASTER
Grab lunch. Have a coffee. Recharge. Live your life while adding up to 94 miles of range for every hour you’re plugged in. The Charge Tank option is compatible with Level 2 charge stations and delivers roughly 6x faster charging than when compared to a standard wall outlet. Depending on the battery, a typical recharge can now take as little as an hour.
CHARGING. MEET HOUSEHOLD OUTLET.
No special equipment required: your standard household outlets can be used as fueling stations for a fraction of the cost of gasoline. Plug in at night and start the day with a full tank.
LONG RANGE BATTERY TECH
The Zero DSR carries the highest power and energy density battery in the EV industry. With over thirteen years of rigorous off-road experience, the Z-Force® battery confidently delivers you to your destination.
PULL THE PLUG ON MAINTENANCE
Blast down a fire road. Get dirty. Live in the moment. At the end of your adventure the Zero DSR only asks that you plug in. No need to replace clogged filters or dirty oil. The Z-Force® powertrain eliminates the fossil burner mess, trading oil, spark plugs, clutches and filters for a motor with a single moving part. The Zero DSR’s ripping acceleration is delivered through a carbon fiber belt that directly connects the motor to the rear wheel. Chain maintenance is a thing of the past. Learn more.
SWAPPABLE BATTERY CAPABILITY
Zero Motorcycles’ Z-Force® battery is the most power and energy dense in the EV industry. The Zero DSR comes with the ZF14.4 battery. Add a Power Tank accessory to expand battery capacity by 3.6 kWh.
The battery is designed to last and backed by a five-year, unlimited mileage warranty. The Zero DSR also features Long Term Storage Mode to optimize the battery’s state of charge and further improve long term battery health.
MOTOR
The impressive Z-Force® motor produces smooth power and up to 116 ft-lb with a design so efficient it only requires passive air-cooling. Roll on the throttle for massive acceleration. Roll off the throttle to progressively channel energy back into the battery.
No heavy, complicated or expensive liquid cooling. No fuss. No routine maintenance. This is the industry’s most efficient, powerful, and compact brushless motor.
CHASSIS
Featuring a twin-spar aircraft-grade aluminum chassis, the Zero DS’s frame offers superior torsional rigidity.
SUSPENSION
Custom-tuned for Zero by Showa, the Zero DSR suspension offers 7 inches of plush travel that enables you to tackle virtually any terrain thrown your way. The entire suspension system can be fully and easily adjusted to glide over any city street or rip down your favorite fire road.
DASH
The Zero DSR comes equipped with a full color display to project the specs you need: speed, state of charge, power output, selected riding mode and more. Sync with your smartphone to customize the information that is displayed on your dash.
ONBOARD CHARGER
No additional charging equipment required. The standard 1.3 kW onboard charger plugs into any household outlet. It can be operated in conjunction with the off-board Quick Charger accessory and/or the Charge Tank option to accelerate charge times.
TANK
The standard Zero DSR “tank” is equipped with spacious lockable storage—perfect for stowing personal items like cell phones, wallets, or gloves. Interested in faster charging or greater range Swap the standard tank for the Charge Tank option for 6x faster charging or the Power Tank accessory that adds an additional 3.6 kWh of battery.
BRAKES
The Bosch anti-lock brake system (ABS) delivers confident braking. Tested for just about any situation you can imagine, the system optimizes deceleration when you hit your brakes hard. Braking is actuated via levers that can be adjusted for improved ergonomics. ABS can be switched on or off by the rider.
DIRECT DRIVE
Strip away clutches, gears, shifting, chains and all their weighty complexities. Seamlessly rocket to speeds in excess of 95 mph with pure efficiency as energy quietly transforms into propulsion. The Zero DSR is direct drive. Its state-of-the-art motor connects directly to the rear wheel using a carbon fiber belt.
WHEELS AND TIRES
Shred confidently on anything from twisting tarmac to loose fire roads, the Zero DSR’s Pirelli MT-60 tires provide superior traction, excellent durability and road feel. The tires are mounted to durable cast alloy wheels and a hollow front axle shaves unsprung weight to improve han
2022 Zero DSR – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $15695 USD
Canada MSRP Price: $ See Dealer CAD
Europe/UK MSRP Price: £ See Dealer GBP (On The Road inc 20% Vat)
Range
ZF 14.4
ZF 14.4 POWER TANK
City
163 miles (262 km)
204 miles (328 km)
Highway, 55 mph (89 km/h)
98 miles (158 km)
122 miles (196 km)
Combined
122 miles (196 km)
153 miles (246 km)
Highway, 70 mph (113 km/h)
78 miles (126 km)
97 miles (156 km)
Combined
105 miles (169 km)
132 miles (212 km)
Motor
ZF 14.4
ZF 14.4 POWER TANK
Peak torque
116 ft-lb (157 Nm)
116 ft-lb (157 Nm)
Peak power
70 hp (52 kW) @ 3,500 rpm
70 hp (52 kW) @ 3,500 rpm
Top speed (max)
102 mph (163 km/h)
102 mph (163 km/h)
Top speed (sustained)
90 mph (145 km/h)
90 mph (145 km/h)
Type
Z-Force® 75-7R passively air-cooled, high efficiency, radial flux, interior permanent hi-temp magnet, brushless motor
Z-Force® 75-7R passively air-cooled, high efficiency, radial flux, interior permanent hi-temp magnet, brushless motor
Controller
High efficiency, 775 amp, 3-phase brushless controller with regenerative deceleration
High efficiency, 775 amp, 3-phase brushless controller with regenerative deceleration
Power system
ZF 14.4
ZF 14.4 POWER TANK
Power pack
Z-Force® Li-Ion intelligent integrated
Z-Force® Li-Ion intelligent integrated
Max capacity
14.4 kWh
18.0 kWh
Nominal capacity
12.6 kWh
15.8 kWh
Charger type
1.3 kW, integrated
1.3 kW, integrated
Charge time (standard)
9.8 hours (100% charged) / 9.3 hours (95% charged)
12.1 hours (100% charged) / 11.6 hours (95% charged)
With Charge Tank option
2.5 hours (100% charged) / 2.0 hours (95% charged)
N/A
With one accessory charger
5.7 hours (100% charged) / 5.2 hours (95% charged)
7.0 hours (100% charged) / 6.5 hours (95% charged)
With max accessory chargers
2.8 hours (100% charged) / 2.3 hours (95% charged)
3.3 hours (100% charged) / 2.8 hours (95% charged)
Input
Standard 110 V or 220 V
Standard 110 V or 220 V
Drivetrain
ZF 14.4
ZF 14.4 POWER TANK
Transmission
Clutchless direct drive
Clutchless direct drive
Final drive
90T / 20T, Poly Chain® HTD® Carbon™ belt
90T / 20T, Poly Chain® HTD® Carbon™ belt
Chassis / Suspension / Brakes
ZF 14.4
ZF 14.4 POWER TANK
Front suspension
Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Rear suspension
Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Front suspension travel
7.00 in (178 mm)
7.00 in (178 mm)
Rear suspension travel
7.03 in (179 mm)
7.03 in (179 mm)
Front brakes
Bosch Gen 9 ABS, J-Juan asymmetric dual piston floating caliper, 320 x 5 mm disc
Bosch Gen 9 ABS, J-Juan asymmetric dual piston floating caliper, 320 x 5 mm disc
Rear brakes
Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4.5 mm disc
Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4.5 mm disc
Front tire
Pirelli MT-60 100/90-19
Pirelli MT-60 100/90-19
Rear tire
Pirelli MT-60 130/80-17
Pirelli MT-60 130/80-17
Front wheel
2.50 x 19
2.50 x 19
Rear wheel
3.50 x 17
3.50 x 17
Dimensions
ZF 14.4
ZF 14.4 POWER TANK
Wheelbase
56.2 in (1,427 mm)
56.2 in (1,427 mm)
Seat height
33.2 in (843 mm)
33.2 in (843 mm)
Rake
26.5°
26.5°
Trail
4.6 in (117 mm)
4.6 in (117 mm)
Weight
ZF 14.4
ZF 14.4 POWER TANK
Curb weight
419 lb (190 kg)
463 lb (210 kg)
Carrying capacity
487 lb (221 kg)
443 lb (201 kg)
Economy
ZF 14.4
ZF 14.4 POWER TANK
Equivalent fuel economy (city)
435 MPGe (0.54 l/100 km)
435 MPGe (0.54 l/100 km)
Equivalent fuel economy (highway)
207 MPGe (1.13 l/100 km)
207 MPGe (1.13 l/100 km)
Typical cost to recharge
$1.61
$2.02
Pricing
ZF 14.4
ZF 14.4 POWER TANK
MSRP
$15,695
$18,590
Warranty
ZF 14.4
ZF 14.4 POWER TANK
Standard motorcycle warranty*
2 years
2 years
Power pack warranty*
5 years/unlimited miles
5 years/unlimited miles
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
