2017 Indian Springfield on the Total Motorcycle Cool Wall

For MORE information and Photos click here: … gfield.htm



2017 Indian Springfield on


Your perfect road is out there. And there’s only one way to find it: on an Indian® Springfield™, a modern motorcycle equipped with all the touring essentials.

Named after the birthplace of Indian Motorcycle® and designed for a pure riding experience, the Indian Springfield™ features a traditional style, quick-release windshield, black leather rider and passenger saddles, and all-weather, remote-locking saddlebags.

It’s equipped with the most essential touring features but designed for ultimate versatility. It can be stripped down into a cruiser when the windshield and saddlebags are removed or become a fully loaded touring model with Genuine Indian Motorcycle® accessories.

The all-new purpose built trunkcompatible chassis delivers a 25-degree rake and 5.2-inch trail for unmatched handling and balance even when fully loaded.

Now available in two-tone color options, Steel Gray over Burgundy Metallic and Blue Sapphire over Star Silver, the Springfield™ is equipped with the most essential touring features but designed for ultimate versatility. While maintaining the style and luxury Indian Motorcycle is known for, the Indian® Springfield™ carves its own niche in the bagger and touring category.

Named after the birthplace of Indian Motorcycle, the Indian Springfield offers classic styling blended with thoroughly modern technology for a purist’s take on both touring comfort and urban versatility. The Springfield can be quickly converted into a cruiser with the quick-release windshield and saddlebags removed, or transformed into a high-capacity touring model with Genuine Indian Motorcycle accessories. Remote locking hard bags and adjustable passenger floorboards come standard along with genuine leather seating, ABS, TPMS, cruise control, and a powerful headlight and dual driving lights. Indian Springfield is offered in Thunder Black or Indian Motorcycle Red. New for 2017 are stunning Steel Gray/Burgundy Metallic and Blue Sapphire/Star Silver two-tone finishes. Starting at $20,999.


You. The road. Nothing else. That’s the definition of pure riding. And that’s exactly what you get with the Indian Springfield™, along with features like a keyless ignition. Quick-release windshield. And remote-locking saddlebags. Want more? Add a premium audio system, should you ever want a new soundtrack to go with the satisfying rumble of your Thunder Stroke 111 engine. Be legendary.

2017 Indian Springfield Key Features

Thunder Stroke 111

A nod to the engine designs of our past, with innovations to power us into the future. That’s the remarkable Thunder Stroke® 111 V-Twin. Air-cooled. With 119 ft.lbs of torque, And two massive pistons that produce the thunderous sound that earned its name. There’s always a high road, and with this award-winning powerplant, getting there couldn’t be more effortless – or more exhilarating.

Springfield is now available in two-tone colours for the first time – Steel Grey over Burgundy Metallic with Silver Stripe and Springfield Blue Metallic over Star Silver.

Indian Motorcycle Red
Thunder Black
Steel Grey over Burgundy Metallic with Silver Stripe NEW
Springfield Blue Metallic over Star Silver NEW

2017 Indian Springfield – USA Specifications/Technical Details
US MSRP Price: $20,999 USD
Canada MSRP Price: $26,299 CDN


Engine Type
Thunder Stroke® 111
111 cu in (1811 cc)
Bore x Stroke
3.976 in x 4.449 in (101 mm x 113 mm)
Compression Ratio
9.5 : 1
Electronic Fuel Injection System
Closed Loop Fuel Injection / 54 mm Bore


Primary Drive
Gear Drive Wet Clutch
Drive/Driven Clutch
Wet, Multi-Plate
Final Drive
2.2 : 1


Peak Torque
119.2 ft-lbs (161.6 Nm)
Peak Torque RPM
3000 rpm

Gear Ratio (Overall)

9.403 : 1
6.411 : 1
4.763 : 1
3.796 : 1
3.243 : 1
2.789 : 1


Suspension: Front – Type/Travel
Telescopic Fork / 4.7 in (119 mm)
Front Fork Tube Diameter
46 mm
Suspension: Rear – Type/Travel
Single Shock w/ Air Adjust / 4.5 in (114 mm)


Dual / 300 mm Floating Rotor / 4 Piston Caliper
Single / 300 mm Floating Rotor / 2 Piston Caliper
Cast 16 in x 3.5 in
Cast 16 in x 5 in
Dunlop® Elite 3 130/90B16 73H
Dunlop® Elite 3 Multi-Compound 180/60R16 80H
Split Dual Exhaust w/ Cross-Over


67.0 in (1701 mm)
Seat Height
26.0 in (660 mm)
Ground Clearance
5.6 in (142 mm)
Overall Height
56.8 in (1442 mm)
Overall Length
101.7 in (2583 mm)
Overall Width
39.0 in (990 mm)
5.2 in (133 mm)
Fuel Capacity
5.5 gallons (20.8 liters)
1385 lbs (630 kg)
Weight (Empty Tank / Full of Fuel)
830 lbs / 862 lbs (376 kg / 391 kg)


Standard Equipment
ABS; Cast Aluminum Frame with Integrated Air-Box; Cruise Control; Front and rear Highway Bars compatible with lower weather protection; Indian® Script Tank Badge; Keyless Start; Quick-Release Windshield; Quick-Release Hard Saddlebags, Tire Pressure Monitoring; Adjustable Passenger Floorboards;


Tank Mounted Electronic Speedometer with Odometer; Dual Tripmeters; Digital Tachometer; Ambient Air Temperature; Fuel Range; Average Fuel Economy; Battery Voltage; Gear Position Display; Real-Time Clock; Vehicle Trouble Code Read-Out; Heated Grip Level (If Heated Grips Installed); Low Engine Oil Pressure; 9 LED Telltale Indicators: High Beam, Chassis Fault, Turn signals (separate), ABS, Neutral, TPMS, Check Engine, Sidestand; Tank Mounted Electronic Fuel Gauge with Low Fuel LED Indicator
