BUILT TO MAKE ANY RIDER FEEL ONE WITH THE ROAD.

2018 Harley-Davidson SuperLow:

The SuperLow® gives the confidence that comes from its low seat, well-balanced stance and low center of gravity. The handling is easy, and you’ve got the comfort to go all day. It also features adjustable suspension and the 883 Evolution® engine.

2018 Harley-Davidson SuperLow Totalmotorcycle.com Key Features

Harley-Davidson Sportster Story

Thriving on street-bred and track-based racing performance since being introduced in 1957, the nimble, fun-to-ride Sportster® family of motorcycles is an American legend. With its lightweight narrow profile, aggressive riding position, and a variety of styles from the Dark Custom motorcycle look of the Iron 883™ to the race stripe graphic and new attitude of the 1200 Custom, the Sportster® motorcycle appeals to a wide variety of riders.

2018 Harley-Davidson SuperLow Totalmotorcycle.com Features and Benefits

Comfortable Cockpit

The low bucket seat, longer travel rear suspension, and easy-grip handlebars creates a comfortable riding position for a wide range of riders. It’s ergonomically sound and helps build confidence in all aspects of your journey—from lifting it off its side stand to handling and turning.

883cc Air-Cooled Evolution® Engine

Authentic Harley-Davidson style through and through, dripping with power. The rubber-mounted 883cc Evolution® engine runs hard and rides smooth for thousands of miles so you can just worry about taking in the freedom of boulevards and back streets.

Low Seat Height

The low, ergonomic seat provides the ultimate in handling confidence. The combination of a 25.5 inch seat height plus a narrow frame makes it easy to maneuver your ride through turns and down straights at varying speeds.

Emulsion Rear Shock with Screw Adjuster

Features an Emulsion rear shock with a screw pre-load adjuster that soaks up every bump the street throws your way, and easily adjusts to fit your riding style.

Foundation Brake System

An innovative, high-performing system that gives riders more confidence on the road and more power and predictability when you squeeze the brakes.

Enhanced Low Speed Maneuverability

With an 18-inch wheel up front and a 17-inch wheel backing it up at the tail end, the light-weight wheels and radial tires make handling at low speeds a cinch.

2018 Harley-Davidson SuperLow – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8699 to 9249 USD

Pricing⁶

• Vivid Black $8,699
• Color $9,049
• Two-Tone $9,249

Engine

• Engine ¹ Air-cooled, Evolution^®
• Bore 3 in.
• Stroke 3.811 in.
• Displacement 53.9 cu in
• Compression Ratio 9:01
• Fuel System ³ Electronic Sequential Port Fuel Injection (ESPFI)
• Exhaust Chrome, staggered, shorty exhaust with dual mufflers

Dimensions

• Length 87.6 in.
• Seat Height, Laden ⁷ 25.5 in.
• Seat Height, Unladen 27.8 in.
• Ground Clearance 3.9 in.
• Rake (steering head) (deg) 31.1
• Trail 5.7 in.
• Wheelbase 59.1 in.
• Tires, Front Specification 120/70 ZR-18 59W
• Tires, Rear Specification 150/60 ZR-17 66W
• Fuel Capacity 4.5 gal.
• Oil Capacity (w/filter) 2.8 qt.
• Weight, As Shipped 545 lb.
• Weight, In Running Order 569 lb.

Performance

• Engine Torque Testing Method J1349
• Engine Torque ² 54.6 ft-lb
• Engine Torque (rpm) 3,750
• Lean Angle, Right (deg.) 24.7
• Lean Angle, Left (deg.) 24.4
• Fuel Economy: Estimated City/Hwy ⁵ 51 mpg

Drivetrain

• Primary Drive Chain, 34/57 ratio
• Gear Ratios (overall) 1st 10.41
• Gear Ratios (overall) 2nd 7.436
• Gear Ratios (overall) 3rd 5.531
• Gear Ratios (overall) 4th 4.584
• Gear Ratios (overall) 5th 3.931

Chassis

• Wheels, Front Type ⁹ Black, Split 5-Spoke with Machined Rim
• Wheels, Rear Type Black, Split 5-Spoke with Machined Rim
• Brakes, Caliper Type Dual-piston front, Dual-piston rear

Electric

• Lights (as per country regulation), Indicator Lamps ⁸ High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional)
• Gauges Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights

• 1. Recommended 91 octane or higher fuel (R+M)/2.
• 2. Values shown are nominal. Performance may vary by country and region.
• 3. Standard and optional fuel systems may vary by country.
• 4. See motorcycle owner’s manual for complete details.
• 5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
• 6. Prices listed are the Manufacturer’s Suggested Retail Prices for base models. Options such as color are available at additional cost. Prices exclude tax, title, licensing, registration fees, destination charges, added accessories, and additional dealer charges, if any, and are subject to change. Harley-Davidson reimburses dealers for performing manufacturer-specified pre-delivery inspection and setup tasks. Dealer prices may vary.
• 7. Measurement reflects 180 lb. (81.7 kg) operator weight.
• 8. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
• 9. Standard and optional wheels may vary by country and region.

2018 Harley-Davidson SuperLow – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $10999 to 11649 CDN

Pricing

• Vivid Black $ 10,999
• Color $ 11,399
• Two-Tone $ 11,649

Dimensions

• Length 2,225 mm
• Seat Height, Unladen 705 mm
• Ground Clearance 100 mm
• Rake (steering head) (deg) 31.1
• Trail 145 mm
• Wheelbase 1,500 mm
• Tires, Front Specification 120/70 ZR-18 59W
• Tires, Rear Specification 150/60 ZR-17 66W
• Fuel Capacity 17 l
• Oil Capacity (w/filter) 2.6 l
• Weight, As Shipped 247 kg
• Weight, In Running Order 258 kg

Engine

• Engine ¹ Air-cooled, Evolution™
• Bore 76.2 mm
• Stroke 96.8 mm
• Displacement 883 cc
• Compression Ratio 9:01
• Fuel System ³ Electronic Sequential Port Fuel Injection (ESPFI)
• Exhaust Chrome, staggered, shorty exhaust with dual mufflers

Drivetrain

• Primary Drive Chain, 34/57 ratio
• Gear Ratios (overall) 1st 10.41
• Gear Ratios (overall) 2nd 7.436
• Gear Ratios (overall) 3rd 5.531
• Gear Ratios (overall) 4th 4.584
• Gear Ratios (overall) 5th 3.931

Chassis

• Wheels, Front Type Black, Split 5-Spoke with Machined Rim
• Wheels, Rear Type ⁸ Black, Split 5-Spoke with Machined Rim
• Brakes, Caliper Type Dual-piston front, Dual-piston rear

Performance

• Engine Torque Testing Method J1349
• Engine Torque ² 74 Nm
• Engine Torque (rpm) 3,750
• Lean Angle, Right (deg.) 24.7
• Lean Angle, Left (deg.) 24.4
• Fuel Economy: Estimated City/Hwy ⁵ 4.6 l/100 km

Electric

• Lights (as per country regulation), Indicator Lamps ⁷ High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional)
• Gauges Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights

• 1. Recommended 91 octane or higher fuel (R+M)/2.
• 2. Values shown are nominal. Performance may vary by country and region.
• 3. Standard and optional fuel systems may vary by country.
• 4. See motorcycle owner’s manual for complete details.
• 5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
• 6. Measurement reflects 180 lb. (81.7 kg) operator weight.
• 7. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
• 8. Standard and optional wheels may vary by country and region.

2018 Harley-Davidson SuperLow – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £8145 to 8695 GBP (On The Road inc 20% Vat)

Pricing⁵

• Vivid Black £8,145
• Color £8,395
• Two-Tone £8,695

Engine

• Engine ² Air-cooled, Evolution™
• Bore 76.2 mm
• Stroke 96.8 mm
• Displacement 883 cc
• Compression Ratio 9:1
• Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
• Exhaust Chrome, staggered, shorty exhaust with dual mufflers

Dimensions

• Length 2,225 mm
• Seat Height, Unladen 705 mm
• Ground Clearance 100 mm
• Rake (steering head) (deg) 31.1
• Trail 145 mm
• Wheelbase 1,500 mm
• Tyres, Front Specification 120/70 ZR-18 59W
• Tyres, Rear Specification 150/60 ZR-17 66W
• Fuel Capacity 17 l
• Oil Capacity (w/filter) 2.6 l
• Weight, As Shipped 247 kg
• Weight, In Running Order 258 kg

Performance

• Engine Torque Testing Method EC 134/2014
• Engine Torque ³ 69 Nm
• Engine Torque (rpm) 4,750
• Lean Angle, Right (deg.) 24.7
• Lean Angle, Left (deg.) 24.4
• Fuel Economy Testing Method EC 134/2014
• Fuel Economy: Estimated Hwy/City 4.8 l/100 km
• CO2 Emissions Testing Method EC 134/2014
• CO2 Emissions 111 g/km

Drivetrain

• Primary Drive Chain, 38/57
• Gear Ratios (overall) 1st 9.315
• Gear Ratios (overall) 2nd 6.653
• Gear Ratios (overall) 3rd 4.948
• Gear Ratios (overall) 4th 4.102
• Gear Ratios (overall) 5th 3.517

Chassis

• Wheels, Front Type ⁷ Black, Split 5-Spoke with Machined Rim
• Wheels, Rear Type Black, Split 5-Spoke with Machined Rim
• Brakes, Caliper Type Dual-piston front, Dual-piston rear

Electric

• Lights (as per country regulation), Indicator Lamps ⁶ High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system, ABS
• Gauges Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights

• 1. Availability of colours may vary from dealer to dealer and is subject to change without further notice.
• 2. Recommended 95 octane or higher fuel (R+M)/2.
• 3. Values shown are nominal. Performance may vary by country and region.
• 4. See motorcycle owner’s manual for complete details.
• 5. Prices shown are suggested retail prices only. Please contact your nearest dealer for further details.
• 6. Security system includes immobiliser and siren.
• 7. Standard and optional wheels may vary by country and region.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
