2022 Zero FXS: STEALTHY SUPERMOTO.
Introducing the 2022 Zero FXS…
Quick. Mean. Compact. With precise handling and blistering acceleration, the Zero FXS stealthily shreds any urban slalom or conquers your local track with tarmac carving fierceness. Combining off road ruggedness with on-road agility, the Zero FXS is the ultimate way to cut through the concrete jungle.
2022 Zero FXS Totalmotorcycle.com Key Features
STANDARD
ZF3.6
CITY RANGE 50 MILES
SEAT HEIGHT 32.90 IN
TOP SPEED (MAX) 85 MPH
4.6 HOURS Standard charge time
78 FT-LB Peak torque
100% ELECTRIC POWERTRAIN
Low maintenance CYPHER II Operating system
CLUTCHLESS DIRECT DRIVE Transmission
251 LB Curb weight
BOSCH Generation 9 ABS
5 YEARS/UNLIMITED MILES
2022 Zero FXS Totalmotorcycle.com Features and Benefits
PERFORMANCE PROFILE
Transform performance profiles with the press of a button to perfectly conquer city streets or your local supermoto track. The Zero FXS is pre-programmed with Eco or Sport modes. Connect using your mobile device to customize performance or get stats on your ride.
CHARGE. NO STATION NEEDED.
Standard outlet. Done. No special charging equipment required. Your household outlets just became “fueling” stations that deliver daily rides at a fraction of the cost of gasoline. Ride up to 100 miles a day in the city and plug in overnight to start the next day with a full “tank.”
Need a faster charging solution Use accessory Quick Chargers to cut charge times by over 60%. Learn more.
POWERFUL. MINIMALIST.
THE ZERO FXS DELIVERS UNFILTERED THRILL BY COMBINING OUR MOST COMPACT Z-FORCE® POWERTRAIN WITH PIRELLI DIABLO ROSSO II TIRES AND THE OFF-ROAD DNA OF THE ZERO FX. NO SHIFTING OR CLUNKINESS. DIRECTLY CONNECT YOUR DESIRE FOR SPEED WITH INSTANT, MASSIVE, SILENT, AND SEAMLESS ACCELERATION.
INSTANT “FULL TANK”
Ride. Swap batteries. Continue. The Zero FXS’s optional hot-swappable tech allows you to go from empty to full in seconds. Depleted additional batteries can be easily charged while you ride using off-board charging accessories.
PASS ON SERVICE.
Imagine savage performance delivered without tedious and greasy servicing regimes. Forget oil changes, spark plugs, clutches, filters, chain adjustments or expensive tune-ups. Instead, a carbon fiber belt cleanly connects the rear wheel to an air-cooled Z-Force® motor that uses a single moving part. Swap threadbare tires. Replace used-up brake pads. Ride.
Always advancing. Code for the Z-Force® powertrain is constantly refined to deliver improved performance. The Zero App easily delivers the upgrades using your mobile device.
GO THE DISTANCE.
The Zero FXS travels up to 100 mi when traversing city streets. At its core is Zero’s most compact and lightweight Z-Force® battery that, like rest of the lineup, boasts the highest power and energy density in the EV industry.
Don’t need the range and looking for Zero’s most economical model Drop some weight. The Zero FXS ZF3.6 cuts the battery’s weight and size by roughly 50 percent. Add a second battery module at any time to match the range and performance of the ZF7.2.
2022 Zero FXS – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $9495 USD
Canada MSRP Price: $ See Dealer CAD
Europe/UK MSRP Price: £ See Dealer GBP (On The Road inc 20% Vat)
Range
ZF3.6
City
50 miles (80 km)
Highway, 55 mph (89 km/h)
30 miles (48 km)
Combined
37 miles (60 km)
Highway, 70 mph (113 km/h)
20 miles (32 km)
Combined
29 miles (47 km)
Motor
ZF3.6
Peak torque
78 ft-lb (106 Nm)
Peak power
27 hp (20 kW) @ 4,300 rpm
Top speed (max)
85 mph (137 km/h)
Top speed (sustained)
75 mph (121 km/h)
Type
Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, interior permanent magnet, brushless motor
Controller
High efficiency, 550 amp, 3-phase brushless controller with regenerative deceleration
Power system
ZF3.6
Power pack
Z-Force® Li-Ion intelligent modular
Max capacity
3.6 kWh
Nominal capacity
3.2 kWh
Charger type
650 W, integrated
Charge time (standard)
5.1 hours (100% charged) / 4.6 hours (95% charged)
With one accessory charger
2.3 hours (100% charged) / 1.8 hours (95% charged)
With max accessory chargers
1.6 hours (100% charged) / 1.1 hours (95% charged)
Input
Standard 110 V or 220 V
Drivetrain
ZF3.6
Transmission
Clutchless direct drive
Final drive
90T / 18T, Poly Chain® HTD® Carbon™ belt
Chassis / Suspension / Brakes
ZF3.6
Front suspension
Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Rear suspension
Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Front suspension travel
7.00 in (178 mm)
Rear suspension travel
8.94 in (227 mm)
Front brakes
Bosch Gen 9 ABS, J-Juan asymmetric dual piston floating caliper, 320 x 5 mm disc
Rear brakes
Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4.5 mm disc
Front tire
Pirelli Diablo Rosso II 110/70-17
Rear tire
Pirelli Diablo Rosso II 140/70-17
Front wheel
3.00 x 17
Rear wheel
3.50 x 17
Dimensions
ZF3.6
Wheelbase
56.0 in (1,422 mm)
Seat height
32.9 in (836 mm)
Rake
24.4°
Trail
2.8 in (71 mm)
Weight
ZF3.6
Curb weight
251 lb (114 kg)
Carrying capacity
379 lb (172 kg)
Economy
ZF3.6
Equivalent fuel economy (city)
533 MPGe (0.44 l/100 km)
Equivalent fuel economy (highway)
213 MPGe (1.10 l/100 km)
Typical cost to recharge
$0.40
Pricing
ZF3.6
MSRP
$9,495
Warranty
ZF3.6
Standard motorcycle warranty*
2 years
Power pack warranty*
5 years/unlimited miles
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
