2003 Yamaha V-Max
2003 Yamaha V-Max



– 2003 Yamaha V-Max Review

2003 Yamaha V-Max

The Mad Max of Muscle Bikes…

The Mr. Olympia of power cruisers. A 1200cc, liquid-cooled V-4 beast that’s won more Best Musclebike awards than it knows what to do with.

The truth of the matter is that, for over 17 years now, Mad Max has been wiping the boulevard with pretty much every musclebike-come-lately in terms of pure, unadulterated acceleration.




2003 Yamaha V-Max Features and Benefits






2003 Yamaha V-Max – Specifications/Technical Details
USA MSRP Price: $10,899 USD
Canadian MSRP Price: See dealer for pricing in CDN

DIMENSIONS
Length 90.6 in.

Height 45.7 in.

Width 31.3 in.

Weight 580 lbs.

Wheelbase 62.6 in.

Seat Height 30.1 in.

ENGINE
Engine 1198cc, liquid-cooled, 16-valve, DOHC, 70° V-4

Displacement 1198cc

Bore x Stroke 76 X 66mm

Compression Ratio 10.5:1

Carburetion (4) 35mm Mikuni downdraft-type w/V-Boost

Fuel Capacity 4.0 gal.

Ignition Digital TCI

DRIVETRAIN
Transmission 5-speed w/hydraulically activated diaphragm-type clutch

Final Drive Shaft

BRAKES/WHEELS/TIRES
Brakes Front: Dual 298mm discs
Rear: 282mm disc

Tires Front: 110/90-V18
Rear: 150/90-V15

OPERATIONAL
Suspension Front: 40mm telescopic fork w/air-assist; 5.5″ travel
Rear: Dual shocks w/adjustable spring preload and rebound damping; 3.94″ travel

OTHER
Colors
Matte Black


Specifications are subject to change without notice, in accordance with national regulation and legislations. Suggested Starting Price shown does not include tax, title, or destination charge. Dealer prices may vary.
