MEET THE M70.

2018 Ural M70 Review on Total Motorcycle:

Standard Accessories
•Sidecar Power Outlet
•Sidecar Tonneau Cover

2018 Ural M70 Totalmotorcycle.com Key Features

Standard Paint Options

Military Green

Premium Paint (+$1,000)

Asphalt

Grey Metallic

Terracotta Metallic

Burgundy Metallic

Green Metallic

Bronze Metallic

Sahara

Forest Fog

Gloss Black

Camouflage Paint (+$1,500)

Woodland

Urban

Drivetrain Color Options

Silver (Standard)

Black (+$1,000)

New For 2017

• Electronic speedometer with built-in indicators.
• New wire harness with combination relay and fuse box under left side panel.
• Handlebar switch for sidecar spot-light.
• Handlebar parking brake lever, replaces rider side lever.
• Reverse / neutral foot pedal instead of lever.
• New stock 2/3 seat, replaces tractor seat.
• New sidecar seat with extra storage space under the cushion.
• Updated Tonneau covers.
• Numerous redesigned and improved internal components.
• New colors available in premium colors and finishes.

New For 2016

• New starter motor.
• Introduction of compressible fiber-aluminum gaskets to seal exhaust head pipes.
• Hydraulic brake switch.
• Modified wire harness.
• Modified throttle bodies and flanges.
• Gas tank with the fuel sensor baffle.
• Modified hydraulic dampener with increased stiffness and sealing.
• New trunk lid weather strip.
• New design of the oil deflector for the breather for 2WD models.
• Use of liquid paint on all body parts.

New For 2015

• Updated standard roller bearing used in the crankshaft.
• Updated welding for hydraulic damper mount.
• 3M Self adhesive kick start bumper.
• New rear brake hose and cable mounting bracket.
• Relocated master cylinder with universal link rods.
• Redesigned rear brake pedal that is higher and more comfortable.
• New H4 headlight with housing.
• New tonneau covers, standard Sunbrella and vinyl for cT model.
• Plastic wheel hub covers for front and sidecar wheels.
• Introduction of Universal spare wheel.

New For 2014

• Introduction of new EFI engine.
• Introduction of new cT model.
• New airbox with branch pipes.
• New hydraulic steering dampener.
• New aluminum triple clamps.
• Disk brakes on front, rear, and sidecar wheels.
• Redesigned wheel hubs.
• New final drive housing.
• Pre-formed fuel lines, breather, and brake reservoir hoses.
• New front brake reaction link.
• New Ural gas tank badges.
• New tank knee-grips with logo.
• Redesigned ignition key.
• New dashboard with updated indicator lamps.
• Front engine cover now featuring Ural logo.

New For 2013

• Improved clutch plates.
• New mirror design.
• New diamond sidecar step plate.
• New sidecar floor mats.
• New military hardware fasteners on all tonneau covers.
• Improved tire pump.
• 3M seam sealers for improved protection.

New For 2012

• New piston rings with tighter tolerances.
• New camshaft with improved materials and bearing surfaces.
• Improved 2 piece design for sidecar drive shaft yokes.
• New 2WD gear hubs for final drive and sidecar swing arm drive.
• New 1 piece intake branch pipes that eliminates center coupler and clamps.

New For 2011

• New paint options including more powder coated colors.
• New Aluminum rims on all models.
• Trunk locks standard all models.
• New Cordura (canvas) tonneau covers and aprons.
• New aluminum upper fork bolts.
• Improved high strength final drive ring gear bolts.

New For 2010

• Aluminum alloy rims for Patrol and Tourist models.
• Rocker arms with needle bearings.
• Bearing instead of bronze bushing on the camshaft.
• Polished ports of the cylinder head.
• Stainless steel on all tubular parts (bumpers, clips, handles etc.)
• 40mm Marzocchi forks for Retro model.

New For 2009

• Stainless steel exhaust pipes and mufflers
• Newly designed removable plate under the driver seat
• Standard (7/8′) handle bar size and removable risers.
• Bottom out travel limiter on sidecar swing arm.
• New NAK seals and SKF bearings.
• High quality 8.8 hardware used throughout.

2018 Ural M70 Totalmotorcycle.com Features and Benefits

Goodbye Backpack, Hello Trunk.

Every Ural comes standard with a lockable and water tight sidecar trunk. It’s the perfect size for extra gear, supplies, and whatever else your adventures may need.

2 Year Warranty

Every Ural comes with 2 year, unlimited mileage warranty. Our U.S. parts warehouse is located in Seattle, most orders ship within 24 hours.

Additional 3rd year warranty can be added for $850 USD.

749cc

Our bikes are happy cruising between 65 and 75 mph. Our 749cc engine combined with powerful low end torque is the perfect size to compliment the steering dynamics of our all steel sidecar.

Reverse Gear

In addition to a 4 speed transmission, every Ural comes with a mechanical reverse gear. Reverse can be engage by the foot pedal to the right of the rear brake.

2018 Ural M70 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $16,499 USD

Engine and Transmission

• Displacement, cc: 749
• Engine type: OHV air cooled 2 cylinder 4 stroke “boxer” (flat twin)
• Valve per cylinder: 2
• Bore and stroke (mm x mm): 78 x 78
• Max output (hp): 41 @ 5500 rpm
• Max torque (ft-lbs): 42 @ 4300 rpm
• Compression: 8.6:1
• Fuel system: Throttle body EFI
• Starting: Electric & Kickstart
• Clutch Double-disc dry
• Transmission type: Manual
• Speeds: 4 forward 1 reverse
• Primary drive (rear wheel): Driveshaft
• Final drive ratio: 4.62
• Engageable sidecar wheel drive: No

Physical Measurements

• Overall length, inch.: 94.6
• Overall heights, inch.: 53.4
• Overall width, inch.: 62.3
• Seat height, (unladen), inch.: 29.5
• Ground clearance (unladen),inch.: 4.9
• Dry weight, lbs: 710

Electrical

• Alternator: Denso, Peak Output 40 Amp @ 14vdc, 560 Wt
• Battery: FAYTX20HL (12V, 20Amp/h)
• Headlight: H4
• Spark plugs: NGK BPR6HS

Chassis

• Front suspension: 40mm Marzocchi telescopic forks
• Rear suspension: Double sided swing-arm with two Sachs hydraulic spring shock absorbers, 5x adjustable
• Sidecar suspension: Single sided swing-arm with Sachs hydraulic spring shock absorber, 5x adjustable
• Wheels: 2.15X18 Aluminum rims with steel spokes
• Tires: Heidenau, 4.0×18”
• Front brake: 4-piston fixed Brembo caliper with 295mm floating NG rotor
• Rear brake: HB big bore single piston integrated floating caliper with 256mm fixed NG rotor
• Sidecar brake: 2-piston fixed Brembo caliper with 245mm floating NG rotor

Misc.

• Fuel grade: 91 Octane, unleaded
• Fuel tank capacity, gallons: 5.5
• Reserve, gallons: app. 1
• Estimated fuel economy, mpg: 31-37
• Estimated range, miles: 170-200
• Recommended max cruising speed, mph: 70
• Max permissible weight, lbs:1140
• Trunk volume, cubic ft.: 2.9

Warranty

• 2-years parts and labor unlimited mileage.

2018 Ural M70 – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $18,999 CDN

Engine and Transmission

• Displacement, cc: 749
• Engine type: OHV air cooled 2 cylinder 4 stroke “boxer” (flat twin)
• Valve per cylinder: 2
• Bore and stroke (mm x mm): 78 x 78
• Max output (hp): 41 @ 5500 rpm
• Max torque (ft-lbs): 42 @ 4300 rpm
• Compression: 8.6:1
• Fuel system: Throttle body EFI
• Starting: Electric & Kickstart
• Clutch Double-disc dry
• Transmission type: Manual
• Speeds: 4 forward 1 reverse
• Primary drive (rear wheel): Driveshaft
• Final drive ratio: 4.62
• Engageable sidecar wheel drive: No

Physical Measurements

• Overall length, inch.: 94.6
• Overall heights, inch.: 53.4
• Overall width, inch.: 62.3
• Seat height, (unladen), inch.: 29.5
• Ground clearance (unladen),inch.: 4.9
• Dry weight, lbs: 710

Electrical

• Alternator: Denso, Peak Output 40 Amp @ 14vdc, 560 Wt
• Battery: FAYTX20HL (12V, 20Amp/h)
• Headlight: H4
• Spark plugs: NGK BPR6HS

Chassis

• Front suspension: 40mm Marzocchi telescopic forks
• Rear suspension: Double sided swing-arm with two Sachs hydraulic spring shock absorbers, 5x adjustable
• Sidecar suspension: Single sided swing-arm with Sachs hydraulic spring shock absorber, 5x adjustable
• Wheels: 2.15X18 Aluminum rims with steel spokes
• Tires: Heidenau, 4.0×18”
• Front brake: 4-piston fixed Brembo caliper with 295mm floating NG rotor
• Rear brake: HB big bore single piston integrated floating caliper with 256mm fixed NG rotor
• Sidecar brake: 2-piston fixed Brembo caliper with 245mm floating NG rotor

Misc.

• Fuel grade: 91 Octane, unleaded
• Fuel tank capacity, gallons: 5.5
• Reserve, gallons: app. 1
• Estimated fuel economy, mpg: 31-37
• Estimated range, miles: 170-200
• Recommended max cruising speed, mph: 70
• Max permissible weight, lbs:1140
• Trunk volume, cubic ft.: 2.9

Warranty

• 2-years parts and labor unlimited mileage.

2018 Ural M70 – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ See dealer for pricing in GBP (On The Road inc 20% Vat)

Engine and Transmission

• Displacement, cc: 749
• Engine type: OHV air cooled 2 cylinder 4 stroke “boxer” (flat twin)
• Valve per cylinder: 2
• Bore and stroke (mm x mm): 78 x 78
• Max output (hp): 41 @ 5500 rpm
• Max torque (ft-lbs): 42 @ 4300 rpm
• Compression: 8.6:1
• Fuel system: Throttle body EFI
• Starting: Electric & Kickstart
• Clutch Double-disc dry
• Transmission type: Manual
• Speeds: 4 forward 1 reverse
• Primary drive (rear wheel): Driveshaft
• Final drive ratio: 4.62
• Engageable sidecar wheel drive: No

Physical Measurements

• Overall length, inch.: 94.6
• Overall heights, inch.: 53.4
• Overall width, inch.: 62.3
• Seat height, (unladen), inch.: 29.5
• Ground clearance (unladen),inch.: 4.9
• Dry weight, lbs: 710

Electrical

• Alternator: Denso, Peak Output 40 Amp @ 14vdc, 560 Wt
• Battery: FAYTX20HL (12V, 20Amp/h)
• Headlight: H4
• Spark plugs: NGK BPR6HS

Chassis

• Front suspension: 40mm Marzocchi telescopic forks
• Rear suspension: Double sided swing-arm with two Sachs hydraulic spring shock absorbers, 5x adjustable
• Sidecar suspension: Single sided swing-arm with Sachs hydraulic spring shock absorber, 5x adjustable
• Wheels: 2.15X18 Aluminum rims with steel spokes
• Tires: Heidenau, 4.0×18”
• Front brake: 4-piston fixed Brembo caliper with 295mm floating NG rotor
• Rear brake: HB big bore single piston integrated floating caliper with 256mm fixed NG rotor
• Sidecar brake: 2-piston fixed Brembo caliper with 245mm floating NG rotor

Misc.

• Fuel grade: 91 Octane, unleaded
• Fuel tank capacity, gallons: 5.5
• Reserve, gallons: app. 1
• Estimated fuel economy, mpg: 31-37
• Estimated range, miles: 170-200
• Recommended max cruising speed, mph: 70
• Max permissible weight, lbs:1140
• Trunk volume, cubic ft.: 2.9

Warranty

• 2-years parts and labor unlimited mileage.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
