2007 Firebolt® XB12R Overview

A premium performance motorcycle, the Firebolt XB12R is powered by a 1203cc Buell Thunderstorm V-Twin engine that revs to 6,800 rpm with pounding out 103 peak horsepower and 84 ft. lbs. of torque, delivered in a powerband so broad that serious thrust is always on tap. The Buell InterActive Exhaust system utilizes a valve in the dual-chamber muffler that is controlled by the ECM and adjusts exhaust flow according to riding conditions to smooth torque delivery and optimize engine power. The XB12R has a Graphite Gray frame, and is available in Midnight Black with Translucent Cherry Bomb Red wheels and a Cherry Bomb Red Translucid windscreen, or in Sunfire Yellow with Designer Black wheels and a Kick Ash Translucid windscreen.



Buell Firebolt XB12R highlights:

Buell Thunderstorm 1203V-Twin engine
103 peak hp @ 6,800 rpm (per SAE J607)
84 ft. lbs. peak torque @ 6,800 rpm (per SAE J607)
Buell InterActive Exhaust
DDFI II Electronic Fuel Injection
Single-piece, 49mm intake throttle body
New Pirelli Diablo T tires
Revised functional airbox cover
New redesigned graphics
New wheel colors
New windscreen colors
Dry Weight: 395 pounds
Wheelbase: 52 inches
Fully adjustable 43mm Showa upside-down fork
Fully adjustable Showa rear shock absorber
Buell ZTL front brake
Goodyear Hibrex drive belt with Flexten Plus technology




SPECIFICATIONS:

Firebolt® XB12R
MSRP $10,495

Dimensions
Overall Length6
76.2 in. (1935 mm)
Overall Width8
28.2 in. (715 mm)
Seat Height7
30.5 in. (775 mm)
Ground Clearance6
4.35 in. (110 mm)
Rake (steering head)7
21°
Fork Angle7
21°
Lean Angle9:
Soft Contact, Right
Soft Contact, Left
Hard Contact, Right
Hard Contact, Left
47°
47°
50°
48°
Trail7
3.3 in. (83 mm)
Wheelbase6
52.0 in. (1320 mm)
Tires (Pirelli® Diablo T)4:
Front
Rear
120/70 ZR-17
180/55 ZR-17
Fuel Capacity
3.82 gal. (14.5 L)
Reserve Fuel Capacity
0.75 gal. (2.8 L) warning light
Fuel Economy2
(EPA urban/highway test)
48/65 mpg (4.9/3.6 L/100 km)
Weight:
As Shipped
395 lbs. (179 kg)
Gross Vehicle Weight Rating
850 lbs. (386 kg)
Load Capacity
388 lbs. (176 kg)

Engine
Engine
Air/oil/fan-cooled, 4-stroke, 45° V-Twin
Valve Train
OHV, two valves per cylinder, self-adjusting
Bore x Stroke
3.500 in. x 3.812 in. (88.90 mm x 96.82 mm)
Displacement
73.4 cu. in. (1203 cc)
Compression Ratio
10.0:1
Fuel Delivery
49 mm down draft DDFI II fuel injection
Air Cleaner
Zero-resistance airbox
Exhaust
Tuned, tri-pass resonance chamber with InterActive valve and mass-centralized mounting
Torque
(North America per SAE J607)
84 ft. lbs. @ 6000 rpm
(113 NM @ 6000 rpm)
Horsepower
(North America per SAE J607)
103 hp @ 6800 rpm
Lubrication
Dry-sump
Oil Capacity
2.5 qts. (2.4 L)
Oil Filtration
Screw-on disposable element



Drivetrain
Primary Drive
Chain, 1.500:1 (57/38) ratio
Final Drive3
Constant path, 14 mm pitch aramid-reinforced
Goodyear® Hibrex® belt with Flexten® Plus technology, 2.407:1 (65/27) ratio
Clutch
Wet, multi-plate, compensated, reduced lever effort
Transmission
5-speed, helical gear
Gear Ratios:
1st
2.648
2nd
1.892
3rd
1.407
4th
1.166
5th
1.000


Chassis
Frame
Aluminum frame with UniplanarTM powertrain vibration isolation system, fuel in frame
Front Fork
43 mm Showa® inverted forks with adjustable compression damping, rebound damping, and spring preload
Rear Shock
Showa coil-over monoshock with remote, under-seat reservoir and adjustable
compression damping, rebound damping,
and spring preload
Wheels:
Cherry Bomb Translucent (new) or
Designer Black Powdercoat (new)
Front
6-spoke, ZTLTM cast aluminum,
3.5 in. x 17 in.
(89 mm x 432 mm)
Rear
6-spoke, cast aluminum,
5.5 in. x 17 in.
(140 mm x 432 mm)
Brakes:
Front
ZTL-type brake, 6-piston, fixed caliper,
375 mm single-sided, inside-out,
stainless steel, floating rotor
Rear
Single-piston, floating caliper;
240 mm stainless steel, fixed rotor
Suspension Travel:
Front Wheel
Rear Wheel
4.72 in. (120 mm)
5.00 in. (127 mm)


Electric
Battery
(per Battery Council International Rating)
Sealed lead acid, maintenance-free, 12V,
12 amp/hour, 200 cca
Charging
38-amp, permanent magnet, 3-phase
alternator with solid-state regulator
(481W @ 3000 rpm, 494W peak)
Starting
1.2 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation):
Headlamps
(twin projector beam [H3])
Tail/Stop Lights
Turn Signal Lights
License Plate Light
55-watt low beam, 55-watt high beam
5W/21W
10W manual canceling
5W


Instruments
Electronic speedometer, tachometer, odometer; dual resettable tripmeter;
high beam, neutral, oil, low fuel (plus, odometer shows miles traveled on reserve),
turn signal and engine diagnostic indicator lamps; clock

Colors5
Midnight Black, Sunfire Yellow


Warranty
24 months (unlimited mileage)

1 Specifications for non-U.S. markets might differ. Buell reserves the right to discontinue models or change specifications at any time without incurring any obligation. Vehicle specifications may vary from country to country depending on local laws. Some models are not available in certain countries.
2 Based on tests conducted under lab conditions per U.S. E.P.A. test procedures. Mileage will vary
depending on personal riding habits, weather conditions, trip length, and vehicle condition.
3 Hibrex® and Flexten® are registered trademarks of the Goodyear Tire & Rubber Company.
4 Showa® and Pirelli® are registered trademarks of their respective owners.
5 Availability may vary from dealer to dealer, and is subject to change without notice.
6 Unladen, wet configuration (no rider, all fluids).
7 Laden, wet configuration (design rider, all fluids).
8 Without mirrors.
9 Bottomed-out configuration (100% suspension compression).
