2017 BMW R nineT Racer Review



2017 BMW R nineT Racer on www.Totalmotorcycle.com



Unwavering. Dynamic. Air-cooled…



The R nineT Racer lets you relive the era of legendary superbikes. Far removed from obsessive retro romanticism, but rather on a customisable bike with innovative technology and in customary BMW Motorrad quality.



Crouched behind the striking half fairing, both hands tight on the low-slung handlebar grips, you can feel the powerful boxer work, you hear its unmistakeable roar. And you already know: only a strong character can hold the racing line. On the road, as in life.



Style in the fast lane.



The design of the R nineT Racer unmistakably takes inspiration from the 70s motorsports. The elongated proportions extend through the entire design and promise pure acceleration. The distinctive half-shell fairing, the tank and the seat shape the slim silhouette. The long wheelbase and the low-slung handlebars positioned far to the front complete the low, sporty seating position. Then the high-set, far back footrests: as a rider, you literally lie on the bike. Surrounded by the white bodywork, which clearly stands out against the dark driving parts and technology. Even the tape that runs from the front to the rear in the BMW motorsport colours seems to constantly call for the next acceleration.



Powerful boxer for chasing the racing line.



The R nineT Racer’s technology is just as confident and strong as its design: the drive and the vehicle electrical system have thrilled since the BMW R nineT. Being state-of-the-art, the R nineT Racer also meets the EU-4 standard. The powerful air-cooled, two-cylinder boxer engine features a capacity of 1170 ccm and 81 kW (110 bhp) of output for a highly dynamic power delivery, even at low speeds. Simply a typical boxer. Thanks to the half fairing and the low seating position, you can even enjoy continuous high speeds. The standard ABS and optional ASC ensure that you are always safe when you bring the full power on the road. In addition, the 2-in-1 exhaust in the typical café racer design shows that the technology does not have to hide, either.



You ride like you sit.



Sporty and dynamic: the R nineT Racer’s handlebars are positioned low on the upper fork bridge. The moderate offset protects the wrists. The footrests, on the other hand, have made their way backwards and upwards to support the sporty seating position. In addition, the optional custom rider’s seat lowers the seat height from 805 mm to 795 mm. The cushion on the rider’s seat is slightly raised at the rear. This ensures perceptible relief for the back on long rides. Just like the dynamically designed half fairing – especially at speeds of over 90 km/h.



Customising with style.



The R nineT Racer takes inspiration from the motorsports of days gone by. That’s why, as standard, it only has room for you – completely solo and pure. It is focused – and it shows. The retrofittable pillion frame quickly makes it into a two-seater. Just one of many possibilities to make your bike look however you want. The custom range of optional equipment available ex-works contains, among other things: two aluminium tanks, spoked wheels or even lowered suspension. You can add original BMW Motorrad accessories such as HP carbon parts or an HP sports silencer. The R nineT Racer is also optimally prepared for specially manufactured mounted parts, such as the new Machined parts. Because it loves tinkering hands just as much as the confident rev on the gas.










2017 BMW R nineT Racer www.Totalmotorcycle.com Key Features



The new BMW R nineT Racer and R nineT Pure: purist roadster feeling and athletic dynamic performance based on classic concepts.



For a lot of motorcycle fans, less is very often more – which is why they opt for “pure motorcycling” and the kind of motorbike that credibly and authentically embodies this approach.



BMW Motorrad responded to this trend with the R nineT in 2013 – a model that has enjoyed ongoing success and popularity ever since. This was a good reason for the BMW Motorrad team to follow up with the R nineT Scrambler in 2015, another fascinating specimen of classic motorcycle design which once again received enthusiastic feedback.



Motivated by this positive response, BMW Motorrad now presents the R nine T Racer and R nineT Pure – two motorcycles that add two exciting new facets to the BMW Motorrad Heritage world of experience: the roadster reduced to the essentials and the classic, old-school half-faired sports motorcycle. These are both concepts that were popular in the 1960s and 1970s and continue to inspire nostalgia among many motorcycle enthusiasts to this day.



Both the new BMW Heritage models feature the potent, air/oil-cooled boxer engine with a capacity of 1 170 cc and an output of 81 kW (110 hp) combined with a 6-speed transmission. They are both designed to meet the requirements of the EU4 pollutant class. The design of the exhaust system in stainless steel with the rear silencer positioned on the left reflects classic styling.





Modular frame with individual scope for customising.



On the suspension side, the R nineT Racer and R nineT Pure make use of the modular steel tubular space frame familiar from the R nineT Scrambler consisting of the three components front main frame, rear main frame and removable passenger frame. The latter provides flexibility to change the appearance and character of the two BMW boxer models according to preference, for example by adding different seats from the range of Original BMW Motorrad Accessories. Front wheel control is taken care of by a conventional telescopic fork while at the rear the BMW Paralever comes into use in conjunction with a central spring strut. The five-spoke light alloy cast wheels in the sizes 3.5 x 17″ at the front and 5.5 x 17″ at the rear have tyres in the dimensions 120/70 ZR 17 and 180/55 ZR 17 respectively. 4-piston brake calipers at the front along with floating brake discs with a diameter of 320 millimetres and ABS ensure secure deceleration. In order to prevent the rear wheel from spinning on slippery roads, there is an ASC (Automatic Stability Control) option which is available ex works. Wire-spoked wheels are an option that further emphasise the classic appearance.





R nineT Pure: purist roadster for dynamic, classic riding pleasure on country roads.



The R nineT Pure embodies the essence of the purist, classic roadster – authentically designed, without frills and reduced to the absolute essentials. The design draws on a blend of both classic and modern stylistic elements of motorcycle construction combined with high-end details such as footrests and fork bridges in forged aluminium with a clear anodised finish.



The fuel tank and front mudguard of the BMW R nineT Pure are finished in the colour Catalano Grey non-metallic. In combination with black for the suspension and drivetrain, this colour emphasises the purist character of the R nineT Pure as a roadster for dynamic, classic riding pleasure on country roads.





R nineT Racer: classic 1970s sports motorcycle feeling.



The R nineT Racer deliberately arouses memories of the sports motorcycles popular in the early 1970s. Crouched, compact and elongated, it conveys a sense of old-school sporty aspiration with its strikingly short half-fairing, hump seat, stub handlebars and set-back footrests, combining this overall impression with modern technology.



In Lightwhite non-metallic combined with decor that is reminiscent of past BMW Motorsport colours, the R nineT Racer is particularly light and athletic in appearance. The frame finished in Aluminium Silver prominently presents an architectural contrast with the black drivetrain, underscoring the standing of the R nineT Racer as an old-school sports motorcycle designed for dynamic riding fun on winding roads.





The highlights of the BMW R nineT Racer and R nineT Pure:
• Potent boxer engine with a capacity of 1 170 cc and an output of 81 kW (110 hp) that meets EU4 requirements.
• Modular frame with scope for customising, allowing individualisation according to personal taste.
• Five-spoke light alloy cast wheels, 3.5 x 17″ at front and 5.5 x 17″ at rear (optional wire-spoked wheels).
• 320-millimetre twin disc brake at the front.
• ABS as standard.
• ASC (Automatic Stability Control) as an ex works option.
• 2-in-1 exhaust system made of stainless steel (polished in the Racer, brushed in the Pure).
• High-end details such as fork bridges and footrests in forged, clear anodised aluminium.
• R nineT Pure in Catalano Grey non-metallic as a classic, purist roadster.
• R nineT Racer with half-fairing, hump seat and set-back footrests in the style of a 1970s sports motorcycle.
• R nineT Racer in Lightwhite non-metallic combined with multi-coloured decor reminiscent of past BMW Motorsport colours, with the frame in Aluminium Silver.



















2017 BMW R nineT Racer www.Totalmotorcycle.com Features and Benefits



Distinctive, air-cooled boxer engine for classic motorcycle enjoyment and dynamic riding fun.



The longitudinally mounted 2-cylinder boxer engine with power transmission via universal-shaft drive has been synonymous with BMW motorcycles for more than 90 years. Like no other motorcycle engine, the air-cooled BMW Motorrad boxer power unit enthrals riders with its unmistakable, authentic design, powerful torque and unique, throaty sound.



The BMW R nineT Racer and the R nineT Pure both feature the familiar air/oil-cooled boxer engine with 101-millimetre bore and 73-millimetre stroke, creating a capacity of 1 170 cc. Its peak output is 81 kW (110 hp) at 7 750 rpm and the maximum torque of 116 Nm goes on stream at 6 000 rpm, with a maximum engine speed of 8 500 rpm.



Both new models of the BMW Motorrad Heritage world of experience are designed to meet the requirements of the EU4 pollutant class. This involved fitting the motorcycles with such features as a new engine mapping, a fuel system with carbon canister for fuel tank ventilation and an exhaust system with an altered catalytic converter that has a larger cross-section.



Control of the four valves is via two overhead chain-driven camshafts (DOHC) per cylinder. Valve activation is taken care of by very light and therefore speed-resistant rocker arms, and valve clearance compensation is by means of light hemispherical shims. Power transmission to the rear wheel is via the well-established 6-speed gearbox and the universal-shaft drive.



Exhaust system in sporty style for a classic boxer sound.



The stainless steel exhaust system with rear silencer positioned on the left-hand side also reflects the style of a classic motorcycle Рit is the type of feature that was not uncommon in caf̩ racers and roadsters of the 1960s and 1970s. Fitting snugly up against the wiry stature of the R nineT Racer and R nineT Pure, it underscores their slim appearance and perfectly captures the authentic styling of a bygone era. While the end piece of the rear silencer is finished in black silk matt in the R nineT Pure, in the R nineT Racer the finish is matted clear stainless steel.



The exhaust system has an electric servomotor and an acoustic valve controlled by opening and closing cables so as to meet the desire for a sonorous boxer sound while still complying with the noise emission regulation ECE R41-04. What is more, a large-size catalytic converter ensures even more effective exhaust gas cleaning.



The range of Original BMW Motorrad Accessories also gives customers a range of individualisation options relating to the exhaust concept so as to be able to adapt the character of the two R nineT variants of the Heritage world of experience entirely according to personal taste.



Distinctive frame concept with newly defined suspension geometry and variation options.



Like the R nineT and the R nineT Scrambler, the R nineT Racer and R nineT Pure also respond to the desire on the part of many motorcycle fans to be able to make technical and visual modifications – or customising for short – by providing a special frame concept. For this reason, the new models feature a modular steel tubular space frame like the R nineT Scrambler. This comprises
three components: a main front section, a rear section with integrated end piece and a passenger frame. These three frame components are bolted together. Due to the removable passenger frame, the two new R nineT models also offer plenty of scope to change the look and therefore also the character of the BMW boxers entirely according to personal taste.



The sporty aspirations of the R nineT Racer and the active riding character of the R nineT Pure are reflected in the suspension geometry, which in both cases is geared towards light-footed handling, a neutral cornering response, a high level of directional stability and above all riding fun on winding country roads. The wheelbase of the R nineT Pure is 1 493 millimetres, the castor



105.0 millimetres and the steering head angle 63.4 degrees. In the R nineT Racer the wheelbase is 1 491 millimetres, the castor 103.9 millimetres and the steering head angle 63.6 degrees. Purist motorcycle feeling that gets under the skin – solo or with a
passenger.



As supplied, the new BMW R nineT Pure also enables tours with a pillion passenger. The seat height for the rider is approx. 805 mm, which in conjunction with a narrow inside leg width provides pleasant seat comfort for both rider and passenger. If solo trips are planned, the Pure can be converted to the aluminium rider’s hump seat with the passenger frame dismounted, which makes the rear particularly light in appearance. This highlights the character of the R nineT Pure as an uncompromising riding machine reduced to the essentials in the style of the 1960s and 1970s. The range of Original



BMW Motorrad Accessories allows the R nineT Pure to be modified according to personal taste by means of various seat solutions.



Very much in the style of an early 1970s sports machine, the R nineT Racer is supplied with space for a rider only, who takes up a dynamic position on the one-man hump seat. The seat height is approximately 805 millimetres. However, BMW Motorrad has provided for all eventualities and allows a pillion passenger to be carried by means of an additional bolt-on passenger frame complete with passenger seat and footrests, all of which is available as part of the range of BMW Motorrad accessories.



Classic telescopic fork at front, Paralever at rear and five-spoke light alloy cast wheels.



Front wheel control in both models is decidedly classic in style with a conventionally designed telescopic fork featuring a fork tube diameter of 43 millimetres and 125 millimetres of spring travel. Rear wheel control is taken care of in well-proven fashion by means of a Paralever single-sided swinging arm, as used in other boxer models of the BMW Motorrad Heritage world of experience. A central spring strut with the spring in a white finish is responsible for suspension and damping, offering a spring travel of 120 millimetres. The spring rest is adjustable and rebound-stage damping can also be set to continuously variable levels.



Both models come with light alloy cast wheels in the sizes 3.5 x 17 inches at the front and 5.5 x 17 inches at the rear, with tyres of the dimensions 120/70 ZR 17 and 180/55 ZR 17 respectively. In order to enhance its classic appearance, the R nineT Pure can alternatively be fitted with wire-spoked wheels, which are optionally available as part of the range of Original BMW Motorrad Accessories. 4-piston brake calipers at the front along with floating brake discs with a diameter of 320 millimetres and ABS ensure
secure deceleration in both models. In order to prevent the rear wheel from spinning on slippery roads, there is an ASC (Automatic Stability Control) option which is available ex works.




BMW 3. Design and colour concept.



Die R nineT Pure: purist roadster reduced to the essentials. No frills, authentically designed and with all the attributes that make a classic motorcycle – this is how the R nineT Pure comes across not just in terms of technology but also from the point of view of its paint finishes and styling.



As was the case with the R nineT, one design objective was to give the purist character a powerful presence and express it stylishly using just a small number of skilfully designed elements. The Pure likewise blends both classical and modern elements of motorcycle styling, combining these with high-end surfaces.



These include the painted 17-litre sheet-steel fuel tank with an aluminium trim panel featuring an embossed R nineT inscription which runs across the air intake duct on the right-hand side. It has a clear anodised finish and creates a striking technical contrast due to its finely brushed surface. High-end classic details for a visual treat in technical style. The R nineT Pure conveys a sense of sophisticated workmanship in numerous details. For example the fork bridges and the footrests are high-quality aluminium forged parts with a surface which has been glass-bead blasted and then given a clear anodised finish. The likewise aluminium clamp of the double-butted aluminium handlebars for perfect roadster ergonomics bears the BMW Motorrad inscription, while boreholes are provided on the steering head that allow attachment of a type plate reminiscent of historical BMW motorcycles (Original BMW Motorrad Accessory).



The circular headlamp with sheet steel casing and the BMW emblem positioned centrally on the bulb cover also echo BMW Motorrad history that now stretches back more than 90 years. In corresponding style, the R nineT Pure is fitted with white turn indicators and an LED rear light. The range of ex works optional equipment and BMW Motorrad accessories allow it to be fitted with LED turn indicators, too.



The instrument cluster perfectly matches the classically reduced appearance of the R nineT Pure with a circular speedometer featuring an analog display and integrated indicator lamps. Housed in a high-quality metal casing, its straightforward functionality is very much in keeping with the reduced style of the classic BMW roadster. If desired, the range of BMW Motorrad special accessories allows the addition of a classic engine speed counter with analog display. In addition, the R nineT Pure is fitted with an LCD display that shows important information such as the time and trip distance.



Classic, purist appearance in Catalano Grey non-metallic.



The fuel tank and front mudguard of the BMW R nineT Pure are finished in the colour Catalano Grey non-metallic. Otherwise, black determines the classic, purist character of the Pure on the suspension, engine and seat. Meanwhile, numerous aluminium surfaces of varying structure create fascinating contrasts and a marked classic appearance.



The R nineT Racer: classic sports bike in a café racer look.



When BMW showcased the BMW Concept Ninety on 24 May 2013 at the Concorso d’Eleganza Villa d’Este, it also evoked memories of the legendary BMW R 90 S – a motorcycle that was synonymous with the desires of sports-oriented motorcyclists of its day: with short-cut handlebar fairing and a hump seat, it had sufficient power to reach a top speed of 200 kilometres per hour.



Today, the R nineT Racer brings to a serial production model what the BMW Concept Ninety captured as a design study: purist athletic flair, emotional design and uncompromising styling as a classic sports machine that not only inspires boundless motorcycling pleasure but also instils a desire to customise.



Frame-mounted half-fairing, hump seat and set-back footrests in the style of the sports bikes of the early 1970s.



Crouched, compact and elongated, the R nineT Racer conveys a sense of old-school sporty aspiration with its strikingly short, frame-mounted half-fairing on the steering head, and combines this impression skilfully with modern technology. In combination with the set-back footrests made of forged aluminium, the stub handlebars positioned deeply and mounted directly on the aluminium-forged, clear anodised upper fork bridge force the rider into a dynamic seating position. This is just what many motorcyclists in the early 1970s were looking for, resorting to the appropriate conversion parts at the time.



An absolute must in this type of conversion was the hump seat -just like the one featured on the R nineT Racer. Modelled on the racing machines of that era, the hump seat not only made for a very sporty style but was also designed to give the rider optimum support when accelerating dynamically.



This function is performed in the very same way today by the one-man hump seat of the R nineT Racer with its aluminium hump, and just as in bygone times it is combined with the low, narrowly shaped half-fairing and the elongated 17-litre fuel tank to create a particularly sporty line. What is more, the front view of the R nineT Racer is especially slim and squat in style, determined by the classic circular headlamp with the BMW emblem positioned centrally on the bulb cover.



The typical café racers of the 1970s always featured analog circular instruments, and this detail is faithfully reproduced in the R nineT Racer. In their simplicity, both circular instruments follow the classic principles while still making use of modern technology. For example the R nineT Racer has an on-board computer as standard which provides a large and clear display on a segmented screen of the most important information such as time, active gear, remaining range, trip distance, service interval and average speed and
fuel consumption.



Sporty lightness and dynamic performance in Lightwhite nonmetallic combined with multi-coloured decor.



The BMW R nineT Racer is finished in the colour Lightwhite non-metallic, which appears on the half-fairing, the fuel tank, the front mudguard and the seat hump. Enhanced by decor reminiscent of past BMW Motorsport colours, it conveys a sense of light, dynamic and sporty flair. The frame in Aluminium Silver is reserved exclusively for the R nineT Racer, prominently presenting an architectural contrast with the black drivetrain. The passenger frame for optional additional attachment is finished in black. Meanwhile, numerous aluminium forged parts create skilfully accentuated technical contrasts.












2017 BMW R nineT Racer – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ See dealer for pricing in USD



Engine
Type Air/oil-cooled 4-stroke flat twin engine with balancer shaft, four valves per cylinder, double overhead camshaft, wet sump lubrication
Bore x stroke 101 mm x 73 mm
Capacity 1,170 cc
Rated output 110 hp (81kW) at 7,750 rpm
Max. torque 85 lb-ft (116 Nm) at 6,000 rpm
Compression ratio 12.0:1
Mixture control / engine management Electronic intake injection
Emission control Closed-loop 3-way catalytic converter, emission standard EU-4
Performance / fuel consumption
Maximum speed Over 125 mph
Fuel type Premium Unleaded
Electrical system
Alternator three-phase alternator 720 W
Battery 12 V / 14 Ah, maintenance free
Power transmission
Clutch Single dry plate clutch, hydraulically operated
Gearbox Constant mesh 6-speed gearbox with helical gear teeth
Drive Shaft drive
Chassis / brakes
Frame three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, pillion frame mountable for pillion rider use (accessories)
Front wheel location / suspension Telescopic forks with 43 mm fixed-tube diameter
Rear wheel location / suspension Cast aluminum single swing arm with BMW Motorrad Paralever; central spring strut, spring preload steplessly adjustable by hook wrench, rebound-stage damping adjustable
Suspension travel front / rear 4.9″ / 4.7″ (125 mm / 120 mm)
Wheelbase 58.7″ (1,491 mm)
Castor 4.1″ (103.9 mm)
Steering head angle 63.6°
Wheels Cast aluminum wheels
Rim, front 3.00 x 17″
Rim, rear 5.50 x 17″
Tires, front 120/70 ZR 17
Tires, rear 180/55 ZR 17
Brake, front Twin-disc brakes, diameter 320 mm, 4-piston calipers
Brake, rear Single disc brake, diameter 265 mm, double-piston floating caliper
ABS BMW Motorrad ABS
Dimensions / weights
Length 82.9″ (2,175 mm)
Width (incl. mirrors) 36″ (880 mm)
Height (excl. mirrors) 43.5″ (1,330 mm)
Seat height, unladen weight 31.7″ (820 mm)
Inner leg curve, unladen weight 70.3″ (1,830 mm)
Unladen weight, road ready, fully fueled 1) 485 lbs (221 kg)
Permitted total weight 948 lbs (430 kg)
Payload (with standard equipment) 463 lbs (210 kg)
Usable tank volume 4.5 gal (17 l)
Reserve Approx. 1 gal (3.5 L)
















2017 BMW R nineT Racer – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See dealer for pricing in CDN

Engine
Type Air/oil-cooled flat twin (‘Boxer’) 4-stroke engine, two camshafts and four radially aligned valves
per cylinder, central balancer shaft
Bore x stroke 101 mm x 73 mm
Capacity 1,170 cc
Rated output 81 kW (110 hp) at 7,750 rpm
Max. torque 116 Nm at 6.000 rpm
Compression ratio 12.0 : 1
Mixture control / engine management Electronic intake pipe injection
Emission control Closed-loop 3-way catalytic converter, emission standard EU-4
Performance / fuel consumption
Maximum speed over 200 km/h
Fuel type Unleaded fuel, octane number 95-98 RON (rated output at 98 RON)
Electrical system
Alternator three-phase alternator 720 W
Battery 12 V / 14 Ah, maintenance-free
Power transmission
Clutch Single dry plate clutch, hydraulically operated
Gearbox Constant mesh 6-speed gearbox with helical gear teeth
Drive Shaft drive
Chassis / brakes
Frame three-section frame consisting of one front and two rear sections, load-bearing engine-
gearbox unit, pillion frame mountable for pillion rider use (accessories)
Front wheel location / suspension Telescopic forks with 43 mm fixed-tube diameter
Rear wheel location / suspension Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut,
spring preload steplessly adjustable by hook wrench, rebound-stage damping adjustable
Suspension travel front / rear 125 mm / 120 mm
Wheelbase 1.491 mm
Castor 103,9 mm
Steering head angle 63,6°
Wheels Cast wheels
Rim, front 3,50 x 17″
Rim, rear 5,50 x 17″
Tyres, front 120/70 ZR 17
Tyres, rear 180/55 ZR 17
Brake, front Twin-disc brakes, diameter 320 mm, 4-piston callipers
Brake, rear Single disc brake, diameter 265 mm, double-piston floating caliper
ABS BMW Motorrad ABS
Dimensions / weights
Length 2.105 mm
Width (incl. mirrors) 920 mm
Height (excl. mirrors) 1.105 mm
Seat height, unladen weight 805 mm
Inner leg curve, unladen weight 1.785 mm
Unladen weight, road ready, fully fuelled 1) 220 kg
Permitted total weight 430 kg
Payload (with standard equipment) 210 kg
Usable tank volume 17 l
Reserve app. 3,5 L




















2017 BMW R nineT Racer – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £10775 GBP (On The Road inc 20% Vat)



Engine
Type Air/oil-cooled flat twin (‘Boxer’) 4-stroke engine, two camshafts and four radially aligned valves
per cylinder, central balancer shaft
Bore x stroke 101 mm x 73 mm
Capacity 1,170 cc
Rated output 81 kW (110 hp) at 7,750 rpm
Max. torque 116 Nm at 6.000 rpm
Compression ratio 12.0 : 1
Mixture control / engine management Electronic intake pipe injection
Emission control Closed-loop 3-way catalytic converter, emission standard EU-4
Performance / fuel consumption
Maximum speed over 200 km/h
Consumption per 100 km based on the WMTC 5,3 l
Fuel type Unleaded fuel, octane number 95-98 RON (rated output at 98 RON)
Electrical system
Alternator three-phase alternator 720 W
Battery 12 V / 14 Ah, maintenance-free
Power transmission
Clutch Single dry plate clutch, hydraulically operated
Gearbox Constant mesh 6-speed gearbox with helical gear teeth
Drive Shaft drive
Chassis / brakes
Frame three-section frame consisting of one front and two rear sections, load-bearing engine-
gearbox unit, pillion frame mountable for pillion rider use (accessories)
Front wheel location / suspension Telescopic forks with 43 mm fixed-tube diameter
Rear wheel location / suspension Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut,
spring preload steplessly adjustable by hook wrench, rebound-stage damping adjustable
Suspension travel front / rear 125 mm / 120 mm
Wheelbase 1.491 mm
Castor 103,9 mm
Steering head angle 63,6°
Wheels Cast wheels
Rim, front 3,50 x 17″
Rim, rear 5,50 x 17″
Tyres, front 120/70 ZR 17
Tyres, rear 180/55 ZR 17
Brake, front Twin-disc brakes, diameter 320 mm, 4-piston callipers
Brake, rear Single disc brake, diameter 265 mm, double-piston floating caliper
ABS BMW Motorrad ABS
Dimensions / weights
Length 2.105 mm
Width (incl. mirrors) 920 mm
Height (excl. mirrors) 1.105 mm
Seat height, unladen weight 805 mm
Inner leg curve, unladen weight 1.785 mm
Unladen weight, road ready, fully fuelled 1) 220 kg
Permitted total weight 430 kg
Payload (with standard equipment) 210 kg
Usable tank volume 17 l
Reserve app. 3,5 L









Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).

About Michael Le Pard 2132 Articles
"Mr. Totalmotorcycle". Owner and Founder of Total Motorcycle. Supporting over Motorcyclists and Motorcycling for 19 great years. Total Motorcycle is my pride and joy and being able to reach out 300 million people has been incredible but I could not have done it without the support of my visitors, readers and members, thank you so much! You are making a difference to millions of riders worldwide. Thank you.
