2019 Honda CB300R ABS Guide

2019 Honda CB300R ABS

2019 Honda CB300R ABS 2019 Honda CB300R ABS

NEO-SPORTS CAFE FUN.

2019 Honda CB300R ABS:

Introducing the latest member of our sportbike family: the all-new 2019 CB300R. And along with it, we’re embracing a concept that’s long been one of motorcycling’s best-kept secrets: the lightweight Neo-Sports Café motorcycle. Graceful, nimble, and most of all a blast to ride, the CB300R is full of innovative engineering to make riding fun. Plus, its styling offers a modern take on the timeless roadster design. Its single-cylinder engine makes it light and narrow, and the new chassis looks good and is the basis of its sure-footed handling. It’s even available with our optional anti-lock brakes. Best of all, the CB300R offers the kind of quality that you only get from a Honda, especially in this class. Ride it and see!

Great for beginners and experienced riders alike, the CBR300R packs a 300-class engine that delivers a strong spread of power. Thanks to a full sport fairing, dual headlights and stylish exhaust system, the CBR300R has the look of a serious sport bike. With strong power, nimble handling, an affordable price and low operating cost, the CBR300R—also available with ABS—makes every ride a fun one.









2019 Honda CB300R ABS Totalmotorcycle.com Key Features

Engine/Drivetrain

  • Engine displaces 286cc for added power throughout the rev range.
  • PGM-FI fuel injection produces crisp throttle response throughout the rev range.

Chassis/Suspension

  • High-quality full-coverage fairing with dual headlights evokes the styling of Honda’s flagship CBR1000RR supersport bike.
  • CBR500R-inspired exhaust system features large internal volume for strong performance, stylish appearance and a throaty exhaust note.
  • Narrow seat and side covers provide an easy reach to the ground.
  • Rear-view mirrors with short stalks have a sleek look.

One-year, transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.

  • Meets current EPA and CARB standards
  • California version differs slightly due to emissions equipment









2019 Honda CB300R ABS Totalmotorcycle.com Features and Benefits

Performance

Compact Engine

The CB300R’s compact 286cc DOHC four-valve, liquid-cooled, single-cylinder engine is a jewel that has won thousands of fans for its free-revving, responsive nature. The engine also works extraordinarily well in real-world road-riding conditions, providing plenty of power both around town and out on the highway.

High-Revving Performance

Bore and stroke are set at 76 x 63mm, with a compression ratio of 10.7:1. PGM-FI fuel injection—with 38mm throttle bore and a refined, straight-shot intake path—delivers crisp throttle response across the rev range.

Underslung Exhaust

The CB300R underslung exhaust features a dual-chamber design with the outlet on the right side. The high-flow design contributes to an ultra-linear throttle response.

Fine-Tuned Intake and Exhaust

The CB300R’s engine uses a new intake and exhaust design to reduce air resistance, contributing to more linear throttle response.

Handling

All-New Chassis

The concept behind a Neo-Sports Café machine strives for a perfect combination of handling, power, and athletic comfort. Great handling starts with a superior chassis, which is why the CB300R uses special frame construction designed to be both light and strong.

Tuned Steel Swingarm

In addition to the CB300R’s chassis, the steel swingarm is designed to provide high longitudinal rigidity and control torsion without being harsh or heavy. This means you get confidence-inspiring feel and feedback, especially while cornering.

Inverted Front Fork

The CB300R’s 41mm inverted fork offers a smooth ride with compliant damping. The supple spring rate is just right for a bike this size.

Perfect Balance

The CB300R features a balanced 49.6/50.4 front/rear weight bias. That means you’re set up for unmatched sport riding, balancing rear-wheel traction, front-end grip, and balanced braking forces.

Lightweight Construction

Since it’s over 30 pounds lighter than our own CB300F, the CB300R’s user-friendly, 313 pound curb weight (317 pounds with ABS) means this bike handles well, and is easier to balance at stoplights or in parking lots.

Lightweight Aluminum Wheels

Unsprung weight—the tires, wheels, and brakes—are super-important in a sportbike. The CB300R’s lightweight aluminum wheels are a critical part of the bike’s responsive handling. Plus, they look great too.

Engineering

Blacked-Out Hardware

Check out the blacked-out hardware; subtle touches like these compliment the CB300R’s traditional-meets-modern Neo-Sports Café styling.

Available ABS

Our Anti-Lock Braking System (on the CB300R ABS model) can be a big help in making controlled stops in less-than-ideal conditions, like on wet pavement or other compromised surfaces. It’s a great choice whether you’re using your new bike as a commuter or just riding it for fun, since it helps you stop with added confidence.

Inverted Front Fork

The CB300R’s 41mm inverted fork offers a smooth ride with compliant damping. The supple spring rate is just right for a bike this size.

Efficient Design

The CB300R’s engine is designed with a minimum number of moving parts. Details like low-friction piston rings, high-density core radiator and iridium spark plug help increase fuel efficiency. Thanks in part to the weight-saving measures and the new intake layout, initial acceleration has been improved by 4% compared to the CB300F.

Powerful Brakes

The CB300R’s radial-mount four-piston Nissin front brake caliper clamps down onto a 296mm floating disc to provide optimum stopping power.

LCD Instruments

The CB300R’s lightweight, full-function LCD display adds a premium feel. It’s 60-percent thinner than previous designs, and gives you readouts for engine rpm, speed and fuel level.

LED Lighting Package

Another perfect example of classic styling with a modern touch, the CB300R features an all-LED lighting package, yet still sports a timeless round headlight lens. The LED taillight is the thinnest ever mounted on a Honda motorcycle!

Comfort

Comfortable Riding Position

The CB300R’s 31.5-inch seat height puts you in an engaged, athletic riding position. You can sit up and see what’s going on around you, and you’re ready to instantly respond to the road—just like your bike.

Passenger Ready

A separate passenger seat, integrated grab rail and passenger footpegs mean you can take a friend along when you go riding—another example of the CB300R’s versatility.

Counterbalance Shaft

Because it features a counterbalancer, the CB300R engine is a smooth runner. You get the narrow overall width and power advantages of a single along with the smoothness of a multi-cylinder bike.

Tapered Rubber-Mounted Handlebar

The CB300R uses a premium tapered handlebar. The center section where it clamps to the triplecrown measures 28.6mm, while it tapers to 22.2mm at the ends under the grips. The larger diameter of the clamped area gives you a direct connection to the bike and excellent steering feedback.











2019 Honda CB300R ABS – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: starting from $4949
USD
Canada MSRP Price: $ CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

·  ENGINE

Engine Type

649cc liquid cooled in-line four cylinder

Bore And Stroke

67mm x 46mm

Induction

PGM-FI with 32mm throttle bodies

Ignition

Full transistorized

Compression Ratio

11.6:1

Valve Train

DOHC; four valves per cylinder

·  DRIVE TRAIN

Transmission

Six-speed

Final Drive

#525 Chain; 15T/42T

·  CHASSIS / SUSPENSION / BRAKES

Front Suspension

41mm fork; 4.25 inches travel

Rear Suspension

Showa Single Shock; 5.04 inches travel

Front Brake

Dual 320mm discs with radial-mount four-piston calipers

Rear Brake

Single 240mm disc

Front Tire

120/70-17

Rear Tire

180/55-17

·  DIMENSIONS

Rake (Caster Angle)

32 degrees

Trail

101mm (4.0 inches)

Wheelbase

57 inches

Seat Height

31.9 inches

Curb Weight

445 pounds (Includes all standard equipment, required fluids and full tank of fuel-ready to ride)

Fuel Capacity

4.1 gallons, including 0.8-gallon reserve

Miles Per Gallon

TBD

·  OTHER

Model ID

CB650R

Emissions

Meets current EPA standards. California version meets current CARB standards and may differ slightly due to emissions equipment.

Available Colors

Chromosphere Red

·  FACTORY WARRANTY INFORMATION

One Year Included

Transferable, unlimited-mileage limited warranty

Optional Extended

Extended coverage available with a HondaCare Protection Plan®







2019 Honda CB300R ABS – Totalmotorcycle.com Canada Specifications/Technical Details

Engine & Drivetrain

Engine Type

Liquid-cooled, single cylinder

Displacement

286 cc

Bore & Stroke

77 mm x 63 mm

Compression Ratio

10.7:1

Valve Train

Chain-driven DOHC, 4 valves per cylinder

Fuel Delivery

PGM-FI electronic fuel injection

Transmission

Six-speed

Final Drive

#520 O-ring-sealed chain

Chassis & Suspension

Front Suspension

37 mm telescopic fork; 130 mm (5.1 in.) travel

Rear Suspension

Pro-Link® single shock with spring preload adjustment; 107 mm (4.2 in.) travel

Additional Information

Tires

Front: 110/70-17 Rear: 150/60-17

Brakes

Front: 296 mm hubless floating disc with radial-mount Nissin 4-piston caliper Rear: 220 mm disc with single piston caliper. 2-channel ABS with IMU

Seat Height

799 mm (31.5 in.)

Wheelbase

1,352 mm (53.2 in.)

Curb Weight

143 kg (315 lbs.) including required fluids and full tank of gas–ready to ride

Fuel Capacity

10 litres

Colour

Candy Chromosphere Red

Warranty

12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus









2019 Honda CB300R ABS – Totalmotorcycle.com European Specifications/Technical Details

NA





2019 Honda CB300R ABS – Totalmotorcycle.com Australian Specifications/Technical Details









Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
