Good looks and great handling — that’s what the DR-Z125 and DR-Z125L are all about.
Both bikes feature aggressive new bodywork that makes them stylistic replicas of the championship-winning RM-Z machines. Their performance virtues, though, go a lot deeper than that. Both bikes set the class standard for precise, agile handling.

Beginning and more experienced riders will appreciate their controllable powerband and strong low-end and mid-range power. And larger riders can choose the DR-Z125L, featuring larger wheels and a front disc brake.

The DR-Z125 and DR-Z125L — race inspired styling with performance to match


Features and Benefits

Key Features

Aggressively styled bodywork, number plates and graphics built to look exactly like the race winning RM-Z competition models

Engine Features

Compact 124cc 4-stroke, SOHC, single-cylinder, air-cooled engine designed for ease-of operation and low maintenance

Digital-type CDI ignition system with timing set to enhance the engine’s low-rpm power characteristics

Five-speed transmission with link-type gearshift system for precise operation and positive feel

Mikuni™ VM20SS carburetor for smooth throttle response

Chassis Features

Available in Factory Suzuki Yellow

Lightweight aluminum rims for reduced weight provide agile handling and improved suspension performance

Lightweight and durable steel frame and swingarm

Long-travel, oil damped front fork and link-type rear suspension provide a smooth, compliant ride

Optimum wheel/tire combination for smaller riders: F: 70/100-17, R: 90/100-14

RM-Z inherited style front fender and number plate

Sharp off-road styling with fuel tank, radiator shrouds and frame covers patterned after the RM-Z series

Strong braking performance provided by lightweight front and rear drum brakes



2010 Suzuki DR-Z125 – USA Specifications



2010 Suzuki DR-Z125 – Canada Specifications
MSRP: $3,099 CDN

Brakes Front Drum brake
Brakes Rear Drum brake
Colour Yellow
Curb Weight 88 kg (194 lbs)
Final Drive Chain
Fuel Tank Capacity 4.8 L (1.3/1.1 US/Imp gal) – Including Reserve
Ground Clearance 260 mm (10.2 in)
Overall Length 1835 mm (72.2 in)
Overall Width 770 mm (30.3 in)
Seat Height 775 mm (30.5 in)
Suspension Front Telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Tires Front 70/100-17 40M, tube type
Tires Rear 90/100-14 49M, tube type
Transmission 5-speed constant mesh
Wheelbase 1245 mm (49.0 in)

Bore Stroke 57.0 mm (2.244 in) x 48.8 mm (1.921 in)
Compression Ratio 9.5 : 1
Engine 4-stroke, air-cooled, OHC
Fuel System MIKUNI VM20SS
Ignition Electronic ignition (CDI)
Lubrication Wet sump
Starter Primary kick

Warranty 6 Month unlimited mileage limited warranty



2010 Suzuki DR-Z125 – Australia Specifications
