CLASS LEADING PERFORMANCE.

The FX 450 offers class leading performance in a lightweight, capable package. All aspects are designed to offer exceptional performance in conjunction with rider comfort and ergonomics making the FX 450 equally appealing to amateur and professional off-road riders alike. Traction control, map select and WP AER 48 forks are just a few of the standard features which ensure the FX 450 embodies premium quality and feel.

2018 Husqvarna FX450 Totalmotorcycle.com Key Features

2018 Husqvarna FX450 Totalmotorcycle.com Features and Benefits

Engine

The SOHC engine is the perfect example of the advanced engineering techniques used by Husqvarna motorcycles offering a peak power of 63 hp at an overall weight of just 61.3 pounds. Mass-centralization is key in the engine design, enabling chassis engineers to position the engine closer to the center of gravity for optimal handling and maneuverability.

Crankshaft

The inertia produced by the crankshaft is carefully calculated to deliver optimal traction and ride-ability from the powerful 450 cc plant. The crankshaft is specifically positioned to harness the rotating mass in the ideal center of gravity resulting in a lightweight and agile handling feel. A plain big end bearing comprising of two force-fitted bearing shells ensure maximum reliability and durability, guaranteeing long service intervals of 100 hours.

Crankcase

The crankcases are designed to house the shaft arrangements and internals of the engine in the position that offers the best possible centre of gravity. Additionally, the position of the clutch shaft keeps the clutch above the oil level resulting in decreased friction and increased efficiency.

Integrated cooling system

The radiators are expertly crafted by WP Performance Systems using high strength aluminium. CFD (computational fluid dynamics) is utilized to channel air through the radiators more efficiently and provide optimal cooling in all conditions. The cooling system is integrated into the frame increasing heat dissipation by channelling coolant through the frame while eliminating the need for additional hoses. Additionally, the radiator protectors do not only protect against flying debris but also act as a brace divert any energy from an impact around the radiator and into the frame.

Chromoly steel frame

The hydro-formed, laser-cut and robot-welded frame expertly crafted by WP Performance Systems is specifically designed with calculated parameters of longitudinal and torsional flex. Aluminum engine mountings benefit suspension functionality and feeling while retaining a light, compact and strong package. The frame is finished off with a premium white powder coating and standard frame protectors guaranteeing supreme protection and durability.

Composite carbon fibre subframe

The composite subframe is a design unique to Husqvarna showcasing pioneering technologies and innovation. This 3 piece component is made up of 30 % carbon fiber making it remarkably light (1.4 kg) and also particularly strong. Specific care is taken to create a certain rigidity for optimal handling and rider ergonomics.

Magura hydraulic clutch

The reliable, high quality, German-made clutch system guarantees even wear, near maintenance-free operation and perfect modulation in every condition. Meaning that play is constantly compensated so that the pressure point and function of the clutch remain identical in cold or hot conditions, as well as over time.

WP AER 48

The 48 mm split air fork features an insulated air spring and pressurized oil chamber for progressive and consistent damping. The component is lightweight and easily adjustable via a single air pressure valve for pre-load (on the left leg) as well as easy access clickers adjusting damping with 30 clicks (on the right leg). Additionally, the air pump needed to adjust air pressure in the fork will be provided as standard.

WP rear shock

The WP DCC rear shock is designed to provide advanced damping characteristics while conforming to a compact and lightweight design. With a pressure balance inside the shock, damping is improved resulting in greater rider comfort and handling while the outer contour of the reservoir increases cooling. The component is also fully adjustable and matched to a linkage system with a specific geometry to deliver the best possible traction and progression with a rear wheel travel of 300 mm.

CNC machined triple clamps

The 22 mm offset black-anodized CNC machined triple clamps feature an integrated rubber damping system that reduces vibration and increases rider comfort. The triple clamps are expertly crafted using superior techniques and materials to provide premium quality and reliability. A 3-way handlebar adjustment is standard and allows for customizable ergonomics.

Traction control

Optimised for easy operation, apart from changing between 2 different engine maps, the map switch also activates launch control and traction control. Traction control can be selected to an on or off position from the switch and functions by analyzing throttle input from the rider and the rate at which RPM increases in the engine. If the RPM increases too quickly, the EMS will register a loss of grip and reduce the amount of power to the rear wheel ensuring maximum traction. This can be a distinct advantage in wet or muddy conditions.

44 mm throttle body

The FX 450 features the same 44 mm Keihin throttle body found on the FC 450. The injector is positioned to ensure the most efficient flow into the combustion chamber while to ensure optimal throttle response the throttle cable is mounted directly without a throttle linkage providing more immediate throttle response and feeling.

EMS

The Keihin EMS is specifically designed to be smaller, lighter and faster at processing data. It integrates launch control for perfect starts, selectable engine maps via the switch on the handlebar as well as traction control. Combined with the new gear sensor, power delivery is tailored for each gear.

Launch control

Launch control is easily engaged from the handlebar map switch. This function limits the amount of power to the rear wheel, improving traction and preventing loss of control under hard acceleration at the start line.

Electric starter

Along with the benefit of easy starting the electric starting system is combined with a compact Li-Ion battery which is 2.2 pounds lighter than a conventional battery. The wiring harness has been purposefully designed so that the rear subframe can be removed without having to remove any wiring.

2018 Husqvarna FX450 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ See Dealer for Pricing in USD

ENGINE
Design1-cylinder, 4-stroke engine
Displacement449.9 cm³
Bore95 mm
StarterElectric starter
Transmission5-speed
Primary drive31:76
Secondary gear ratio13:48
ClutchWet, multi-disc clutch, Magura hydraulics
EMSKeihin EMS
CHASSIS
Frame design25CrMo4 steel central-tube frame
Front suspensionWP-USD, AER 48, Ø 48 mm
Rear suspensionWP shock absorber with linkage
Suspension travel (front)310 mm
Suspension travel (rear)300 mm
Front brakeBrembo twin-piston floating calliper, brake disc
Rear brakeBrembo single-piston floating calliper, brake disc
Rear brake disc diameter220 mm
Chain5/8 x 1/4″
Steering head angle63.9 °
Wheelbase1485 ± 10 mm
Ground clearance370 mm
Seat height960 mm
Tank capacity (approx.)8.5 l
Weight without fuel101.6 kg

2018 Husqvarna FX450 – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See Dealer for Pricing in  CDN

ENGINE
Design1-cylinder, 4-stroke engine
Displacement449.9 cm³
Bore95 mm
StarterElectric starter
Transmission5-speed
Primary drive31:76
Secondary gear ratio13:48
ClutchWet, multi-disc clutch, Magura hydraulics
EMSKeihin EMS
CHASSIS
Frame design25CrMo4 steel central-tube frame
Front suspensionWP-USD, AER 48, Ø 48 mm
Rear suspensionWP shock absorber with linkage
Suspension travel (front)310 mm
Suspension travel (rear)300 mm
Front brakeBrembo twin-piston floating calliper, brake disc
Rear brakeBrembo single-piston floating calliper, brake disc
Rear brake disc diameter220 mm
Chain5/8 x 1/4″
Steering head angle63.9 °
Wheelbase1485 ± 10 mm
Ground clearance370 mm
Seat height960 mm
Tank capacity (approx.)8.5 l
Weight without fuel101.6 kg

2018 Husqvarna FX450 – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ See Dealer for Pricing in  GBP (On The Road inc 20% Vat)

ENGINE
Design1-cylinder, 4-stroke engine
Displacement449.9 cm³
Bore95 mm
StarterElectric starter
Transmission5-speed
Primary drive31:76
Secondary gear ratio13:48
ClutchWet, multi-disc clutch, Magura hydraulics
EMSKeihin EMS
CHASSIS
Frame design25CrMo4 steel central-tube frame
Front suspensionWP-USD, AER 48, Ø 48 mm
Rear suspensionWP shock absorber with linkage
Suspension travel (front)310 mm
Suspension travel (rear)300 mm
Front brakeBrembo twin-piston floating calliper, brake disc
Rear brakeBrembo single-piston floating calliper, brake disc
Rear brake disc diameter220 mm
Chain5/8 x 1/4″
Steering head angle63.9 °
Wheelbase1485 ± 10 mm
Ground clearance370 mm
Seat height960 mm
Tank capacity (approx.)8.5 l
Weight without fuel101.6 kg

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
