2012 Polaris Ranger RZR 4 800 Robby Gordon Edition
Back to 2012 Polaris ATV Quad Models Index Page
Click photos to enlarge. They make great desktop wallpaper.
2012 Polaris Ranger RZR 4 800 Robby Gordon Edition
2012 Polaris Ranger RZR 4 800 Robby Gordon Edition
2012 Polaris Ranger RZR 4 800 Robby Gordon Edition
– 2012 Polaris Ranger RZR 4 800 Robby Gordon Edition
2012 Polaris Ranger RZR 4 800 Robby Gordon Edition Review
RANGER RZR® 4 800 – Only 4-Seat Sport
The 2012 RANGER RZR® 4 800 is the world’s first 4-seat sport Side x Side. Even with 4 people, the big-bore 800 H.O. engine delivers ultra-quick acceleration. And the extended chassis effortlessly tackles the bumps and whoops. It has razor-sharp performance and agility for 4, in the dunes, desert and wide-open spaces.
2012 Polaris Ranger RZR 4 800 Robby Gordon Edition Highlights
– Rolled Independent Rear Suspension with 12″ of Travel
– NEW! Anti-rattle passenger grab bar.
– Thick skid plate for added durability.
– NEW! Clicker knob on Fox Podium X 2.0 Shocks for tool-less compression adjustment
– Exclusive ITP 900 XCT tires – Standard on RANGER RZR 4 800 – feature a unique directional lug pattern providing exceptional cornering and straight-line traction capabilities.
– Everyone rides in comfort, thanks to adjustable and interchangeable bucket seats, plus the adjustable front passenger handrail and full rear passenger handrail. Comfortable driver operation is enhanced by tilt steering with the highest range of motion (10″).
– NEW! Convenient compression adjustment knobs on the Fox 2.0 shocks for fast no-tool tuning.
– NEW! Passenger grab bar tube with anti-rattle bushing for reduced noise.
– Passenger-side glove box has 3 gallons of space for convenient, water-resistant storage.
– Rear cargo box with 300-lb. capacity with lock & ride accessory system
– Front drive cage made from zinc, for added durability.
– Durable dual clutch inlet draws air in for low and high speed cooling.
– Side Nets designed for easy in-and-out access
– Certified Roll-Over Protective Structure (ROPS).
2012 Polaris Ranger RZR 4 800 Robby Gordon Edition Features
MASSIVE HORSEPOWER TO WEIGHT TO CARRY 4 PEOPLE
With an 800 EFI high-output engine and low total vehicle weight, the RANGER RZR 4 has an impressive HP-to-weight ratio giving it unbeatable power to quickly carry 4 people.
FAST ACCELERATION FOR FOUR
Even with 4 people, the 800 EFI high-output engine delivers ultra-fast, from 0 – 35 mph in 4.4 seconds. This is faster acceleration than most 2-seaters.
LONG WHEELBASE FOR THE BEST RIDE
The addition of a back row to carry 2 more passengers gives the RANGER RZR 4 a longer wheelbase. Paired with a rolled IRS, the extended chassis can take on those bumps and whoops to deliver the best off-road ride out there.
PREMIUM FOX 2.0 SHOCKS STANDARD
Standard on all 4 corners are premium Fox Podium X 2.0 Shocks with piggy-back reservoirs – preload adjustable; compression adjustable with a knob, featuring a steel spring retainer. Pair that with Dual-A-Arm front and rear suspensions and it soaks up the rough stuff and delivers a smooth, precise ride every time.
LONG-TRAVEL SUSPENSION FOR 4
Features long suspension travel – 12″ front and 12″ rear. Match this deep-rut absorbing suspension with an obstacle-clearing 11.5″ of ground clearance and you’ve got a smooth riding machine built to carry 4 people off-road.
LOW CENTER OF GRAVITY FOR ULTIMATE 4-PERSON AGILITY
Only RANGER RZRs have a patented engine-behind-the-seat design. Even with 4 people and 11.5″ of ground clearance, the RANGER RZR 4 has the lowest center of gravity in its class, lower than most 2-seaters.
POWER AND AGILITY FOR 4
The world’s first multipassenger sport side-by-side, and the industry’s only four-seat high-performance machine. Razor-sharp performance is enjoyed by up to four people, and everyone gets a great view.
ON-DEMAND TRUE ALL WHEEL DRIVE
True AWD gives you the ultimate grip to take you and your passengers through the corners, whoops and loose sand. It’s the easiest to use and fastest responding on-demand system, automatically engaging all four wheels when you need more forward traction and reverting back to 2WD when you don’t. This means less wear and tear, easier steering, and maximizes power when you need it most.
2012 Polaris Ranger RZR 4 800 Robby Gordon Edition – USA Specifications
US MSRP: $14,499 USD
ENGINES
Engine Type 4-Stroke Twin Cylinder
Displacement 760cc High Output (H.O.)
Fuel System Electronic Fuel Injection
Cooling Liquid
DRIVETRAIN
Transmission/Final Drive Automatic PVT P/R/N/L/H; Shaft
Drive System On-Demand True AWD/2WD
SUSPENSION
Front Suspension Dual A-Arm Fox Podium X 2.0 (comp adjust/res.) 12″ (30.5 cm) Travel
Rear Suspension Dual A-Arm Fox Podium X 2.0 (comp adjust/res.), Rolled with Anti-Sway Bar 12″ (30.5 cm) Travel
BRAKES
Front/Rear Brakes 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking Brake Park in Transmission
TIRES/WHEELS
Front Tires / Model 27 x 9-12; ITP 900 XCT
Rear Tires / Model 27 x 11-12; ITP 900 XCT
Wheels Cast Aluminum
DIMENSIONS
Wheelbase 103.0″ (261.6 cm)
Dry Weight 1,255 lbs. (569.3 kg)
Overall Vehicle Size (LxWxH) 130 x 60.5 x 75″ (330.2 x 153.7 x 190.5 cm)
Ground Clearance 11.5″ (29.2 cm)
CAPACITIES
Fuel Capacity 7.25 gal (27.4 L)
Bed Box Dimensions (LxWxH) 22 x 42 x 6.5″ (56 x 107 x 16.5 cm)
Box Capacity N.A./300 lb (136.1 kg)
Payload Capacity 900 lb (408.2 kg)
Hitch Towing Rating 1,500 lb (680.4 kg)
Hitch/Type Standard/1.25″ Receiver
FEATURES
Cargo System Lock & Ride
Lighting 55W low/ 60W high
Electronic Power Steering Equipped
Instrumentation Digital Gauge, Speedometer, Odometer, Tachometer, Tripmeter, Hour Meter, Clock, Gear Indicator, Fuel Gauge, Hi-Temp/Low-Batt Lights, DC Outlets (2)
2012 Polaris Ranger RZR 4 800 Robby Gordon Edition – Canadian Specifications
Canadian MSRP: $16,499 CDN
ENGINES
Engine Type 4-Stroke Twin Cylinder
Displacement 760cc High Output (H.O.)
Fuel System Electronic Fuel Injection
Cooling Liquid
DRIVETRAIN
Transmission/Final Drive Automatic PVT P/R/N/L/H; Shaft
Drive System On-Demand True AWD/2WD
SUSPENSION
Front Suspension Dual A-Arm Fox Podium X 2.0 (comp adjust/res.) 12″ (30.5 cm) Travel
Rear Suspension Dual A-Arm Fox Podium X 2.0 (comp adjust/res.), Rolled with Anti-Sway Bar 12″ (30.5 cm) Travel
BRAKES
Front/Rear Brakes 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking Brake Park in Transmission
TIRES/WHEELS
Front Tires / Model 27 x 9-12; ITP 900 XCT
Rear Tires / Model 27 x 11-12; ITP 900 XCT
Wheels Cast Aluminum
DIMENSIONS
Wheelbase 103.0″ (261.6 cm)
Dry Weight 1,255 lbs. (569.3 kg)
Overall Vehicle Size (LxWxH) 130 x 60.5 x 75″ (330.2 x 153.7 x 190.5 cm)
Ground Clearance 11.5″ (29.2 cm)
CAPACITIES
Fuel Capacity 7.25 gal (27.4 L)
Bed Box Dimensions (LxWxH) 22 x 42 x 6.5″ (56 x 107 x 16.5 cm)
Box Capacity N.A./300 lb (136.1 kg)
Payload Capacity 900 lb (408.2 kg)
Hitch Towing Rating 1,500 lb (680.4 kg)
Hitch/Type Standard/1.25″ Receiver
FEATURES
Cargo System Lock & Ride
Lighting 55W low/ 60W high
Electronic Power Steering Equipped
Instrumentation Digital Gauge, Speedometer, Odometer, Tachometer, Tripmeter, Hour Meter, Clock, Gear Indicator, Fuel Gauge, Hi-Temp/Low-Batt Lights, DC Outlets (2)
Specifications, appearance, and price of product are subject to change without notice.
